TEW-753DAP User’s Guide Product Overview

Product Overview

Package Contents

TEW-753DAP package includes:

• TEW-753DAP

• Mul-Language Quick Installaon Guide

• CD-ROM ( User’s Guide)

• Network cable (1.5 m/5 .)

• Power adapter (12 V DC, 1.25 A)

• Installaon screws

If any package contents are missing or damaged, please contact the

retail store, online retailer, or reseller/distributor from which the

product was purchased.

TEW-753DAP

Features

TRENDnet’s N600 Dual Band PoE Access Point, model TEW-753DAP, is

a feature rich business class access point with proven concurrent 300

Mbps dual band wireless technology. A variety of installaon scenarios

are supported with Access Point, WDS AP, WDS Bridge, and Repeater

modes. Save installaon me and costs with PoE.

Quick Setup

Get up and running in minutes with the intuive guided setup

Low Prole

O white low prole smoke detector shape blends into most

environments

Power over Ethernet (PoE)

Save installaon me and costs with a PoE (Oponal power port for

non-PoE installaons)

LED Control

Disable diagnosc LEDs to further reduce visual aenon

Concurrent Dual Band

Proven concurrent 300 Mbps* dual band wireless n

Gigabit Port

Gigabit port maintains high performance connecon to network

Wireless Coverage

Increased coverage with MIMO technology

Backward Compable

Compable older wireless g devices

TEW-753DAP User’s Guide Product Overview

Operaon Modes

Independently set each band to Access Point, WDS AP, WDS Bridge,

WDS Staon, Client Bridge or Repeater mode

IPv6

IPv6 support

AP Scan

Integrated wireless scan funcon helps opmize wireless setup

SSIDs

Up to 8 SSIDs per band (16 total) with isolaon support

Trac Shaping

Allocate bandwidth to each wireless SSID

System Logs

Eight system log lters aid network troubleshoong

Spanning Tree

Congurable spanning tree controls

SNMP

Extend network monitoring to this device with SNMP support

Encrypted Wireless

Support for encrypon up to WPA2

VLAN Management

Up to eight SSIDs per band with VLAN management support

Network Access

Create MAC lter tables to reduce network access risk

*Maximum wireless signal rates are referenced from IEEE 802.11

theorecal specicaons. Actual data throughput and coverage will vary

depending on interference, network trac, building materials and other

condions.

TEW-753DAP User’s Guide Product Overview

Front Panel

Wireless Network Power

Mounng Holes

Connectors

DC Power 12V DC 1.25A

(Oponal)

Gigabit PoE Port

Mounng holes

Kensington

security slot

Reset

Buon

Reset Buon • Push and hold for 2 seconds to reset TEW-753DAP

• Push and hold for more than 10 seconds to reset

conguraon to factory default

Power LED OFF Powered o or LED display is disabled

ON Powered on

Network LED

Orange: 10/100

Green: Giga bit

OFF No network connected through Ethernet port

(PoE) or LED display has been disabled

ON Network connected through Ethernet port (PoE)

Flashing Network acvies are detected on Ethernet

(PoE) port

Wireless LED

Orange: 2.4GHz

Green: 5GHz

OFF No wireless network connecon or LED display is

disabled

Flashing Wireless network acvies are detected

TEW-753DAP User’s Guide Product Overview

Product Preset Informaon

There are two preset product labels comes with the package. The rst

label is located on plasc wrapping of TEW-753DAP. The second label

is located on the boom of the TEW-753DAP. You can nd default SSID,

wireless key, administrator account, and administrator password there.

The default stac management IP is 192.168.10.100.

0123456#

TRENDnet753_2.4GHz_XXXX

http://tew-753dap

Made in Taiwan

Mounng Accessories

The mounng accessories are provided for easier hardware installaon,

including two sets of T-Bar clippers, two sets of screws, and a set of

spacers�

P2�6 * 25 Screws

Spacers

P2�6 * 10 Screws

15/16” T-Bar Clips 9/16” T-Bar Clips

TEW-753DAP User’s Guide Installation

Hardware Installaon

Mount on Wall or Ceiling

Use two P3.5 pan head screws to hold the TEW-753DAP. The distance

between mounng points is 2 3/4” (7cm)

Mount on T-Bar

Two addional bronze screw holes are provided for T-Bar mounng.

Use two P2.6 screws to secure the TEW-753DAP on T-Bar clip and then

clip on the T-Bar.

TEW-753DAP User’s Guide Installation

Wireless Performance Consideraons

There are a number of factors that can impact the range of wireless

devices. Adjust your wireless devices so that the signal is traveling in

a straight path, rather than at an angle. The more material the signal

has to pass through the more signal you will lose. Keep the number of

obstrucons to a minimum. Each obstrucon can reduce the range of

a wireless device. Posion the wireless devices in a manner that will

minimize the amount of obstrucons between them.

Building materials can have a large impact on your wireless signal. In

an indoor environment, try to posion the wireless devices so that

the signal passes through less dense material such as dry wall. Dense

materials like metal, solid wood, glass or even furniture may block or

degrade the signal.

Antenna orientaon can also have a large impact on your wireless

signal. Use the wireless adapter’s site survey tool to determine the best

antenna orientaon for your wireless devices.

Interference from devices that produce RF (radio frequency) noise

can also impact your signal. Posion your wireless devices away from

anything that generates RF noise, such as microwaves, radios and baby

monitors.

Any device operang on the 2.4GHz frequency will cause interference.

Devices such as 2.4GHz cordless phones or other wireless remotes

operang on the 2.4GHz frequency can potenally drop the wireless

signal. Although the phone may not be in use, the base can sll

transmit wireless signal. Move the phone’s base staon as far away as

possible from your wireless devices.

Adjust the wireless power seng on your AP if you have more than one AP

covering a large area. Covering only the neighbor hop APs in wireless range

is a good design. Covering more than neighbor APs will experience wireless

interference and slow down the communicaon.

Operaon Modes

There are four operang modes provided by TEW-753DAP, Access Point, Client

Bridge, WDS and Repeater. Congure the TEW-753DAP to dierent operaon

mode which service the best in your network.

Access Point

This is the default operaon mode. TEW-753DAP service wireless end points

in this mode. You can setup local or remote wireless authencaon, setup up

to 8 sets of SSIDs in 2.4GHz band and 5GHz band, total 16 SSIDs and separate

SSID or STA trac.

Access Point

Multiple SSID

SSID/STA isolation

TEW-753DAP User’s Guide Installation

Client Bridge

When Client Bridge mode is set to 2.4GHz or 5GHz interface of TEW753DAP,

this interface funcons as a wireless client connecng to any AP dynamically

(channels and encrypons). The interface bridges the trac to the Ethernet

and the other wireless interface.

• Connects to any 802.11

wireless AP

• Connects two networks

wirelessly

WPS

Client Bridge

Repeater

When Repeater Mode is selected, the selected wireless interface funcons

as a wireless repeater and is able to repeat the wireless signal of an access

point. This feature is used to expand your exisng wireless network on places

your current access point is unable to reach. Make sure all the sengs on

selected interface of the TEW-753DAP matches the wireless access points you

want to repeat in same wireless sengs including SSID, channel and wireless

encrypon sengs.

Repeater

TEW-753DAP User’s Guide Installation

Wireless Distribuon System

Deploy ONLY mulple TEW-753DAPs in a single DS

(distribuon system). WDS may not work with other

products due to its non-standard nature�

WDS mode is a non-standard extension to the IEEE 802.11 standard to allow

transparent Ethernet bridging on the staon and to implement seamingless

hand-over for wireless clients roaming between dierent access points.

Transparent bridge is also one of the requirement to some layer 2 services

such as DHCP and 802.1X authencaon. Because the WDS implementaon

dierent from product to product, not all WDS enabled products are

interoperable. You have to use mulple TEW-753DAP to build your mesh

wireless DS or transparent bridge.

You can setup TEW-753DAP on dierent WDS modes for your dierent

network planning.

WDS Bridge: In this mode, the selected interface wirelessly communicate to

other WDS bridges to make a wireless backbone. You can make a simple mesh

network with these WDS bridges. To build a WDS link, you have to list the

neighbor’s BSSID (the MAC address) as next hop packet forwarding. Your neig,

vice versa, has to list your BSSID (the MAC Address) as its next hop. Make sure

all access points are congured with the same SSID as a single DS (distribuon

system), wireless channel and wireless encrypon sengs have to be the

same as well.

WDS

Bridge

WPS

Wireless Distribution System

WDS Access Point: WDS AP is an outlet of a DS. Pairing with a WDS Staon

you can build a transparent bridge between two DS or from DS to STA. (See

more informaon in “Appendix” on page 53 )

WDS Staon: Pair with WDS AP, you can build a transparent bridge for layer 2

requirements. (See more informaon in “Appendix” on page 53 )

WDS AP WDS Station

Transparent Bridge

Andere Handbücher für TEW-753DAP

Inhaltsverzeichnis

Andere TRENDnet Drahtloser Zugangspunkt Handbücher

TRENDnet

TRENDnet TEW-670APB Bedienungsanleitung

TRENDnet

TRENDnet TPL-310AP Bedienungsanleitung

TRENDnet

TRENDnet TEW-841APBO Bedienungsanleitung

TRENDnet

TRENDnet TEW-510APB Bedienungsanleitung

TRENDnet

TRENDnet TEW-815DAP Bedienungsanleitung

TRENDnet

TRENDnet TEW-430APB - Wireless Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-638PAP Bedienungsanleitung

TRENDnet

TRENDnet TEW-435BRM - 54MBPS 802.11G Adsl Firewall M Bedienungsanleitung

TRENDnet

TRENDnet TEW-450APB - Wireless Super G Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-430APB - Wireless Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-638PAP Bedienungsanleitung

TRENDnet

TRENDnet TEW1750ACV2 Bedienungsanleitung

TRENDnet

TRENDnet TEW-740APBO Bedienungsanleitung

TRENDnet

TRENDnet TPL-410AP Bedienungsanleitung

TRENDnet

TRENDnet TEW-230APB Bedienungsanleitung

TRENDnet

TRENDnet TEW-738APBO Bedienungsanleitung

TRENDnet

TRENDnet TEW-450APB - Wireless Super G Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-637AP - 300Mbps Wireless Easy-N-Upgrader Bedienungsanleitung

TRENDnet

TRENDnet TEW-510APB Bedienungsanleitung

TRENDnet

TRENDnet TPL-210AP Bedienungsanleitung

TRENDnet

TRENDnet TEW-735AP Bedienungsanleitung

TRENDnet

TRENDnet TEW-430APB - Wireless Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-430APB - Wireless Access Point Bedienungsanleitung

TRENDnet

TRENDnet TEW-455APBO - 9dBi High Power Wireless Outdoor PoE Access... Bedienungsanleitung

Beliebte Drahtloser Zugangspunkt Handbücher anderer Marken

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Bedienungsanleitung

Ubiquiti

Ubiquiti NanoStation NSM2 Bedienungsanleitung

Cisco

Cisco Aironet 1550 Series Bedienungsanleitung

Aruba

Aruba IAP-335 Bedienungsanleitung

Advantek Networks

Advantek Networks AWN-AP-54MR Bedienungsanleitung

IP-COM

IP-COM AP355 Bedienungsanleitung

Buffalo

Buffalo AirStation WLA-L11G Bedienungsanleitung

EnGenius

EnGenius EnStationACv2 Bedienungsanleitung

D-Link

D-Link DAP-3662 Bedienungsanleitung

xG Technology

xG Technology xMax CN1300 Bedienungsanleitung

Widelink

Widelink ezWave WAP-1100 Series Bedienungsanleitung

Edimax

Edimax CAP1200 Bedienungsanleitung

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Bedienungsanleitung

Aruba

Aruba AP-203R Bedienungsanleitung

LuXout Shades

LuXout Shades LUXSHADE MOTION Bedienungsanleitung

CreatComm

CreatComm TB5F Bedienungsanleitung

SineDigital

SineDigital MW-1500AP(H) Bedienungsanleitung

TP-Link

TP-Link AP9650 V1 Bedienungsanleitung
