Owner’s Manual
WARRANTY
REGISTRATION
Visit www.tripplite.com/warranty
today to register the warranty for
your new Tripp Lite product. You’ll be
automatically entered into a drawing for a
chance to win a FREE Tripp Lite product!
SmartRack™Accessories
Models: SRCABLETRAY, SRCABLETRAYEXP
1 – Introduction
3 – SRCABLETRAY Installation
1-2 Tools Required
4-1 One Expansion Section
5 – Storage and Service
1-1 Parts List
4 – SRCABLETRAYEXP Installation
2 – Important Safety Instructions
4-2 Two Expansion Sections
6 – Warranty and Warranty Registration
1111 W. 35th Street, Chicago, IL 60609 USA
+1.773.869.1234 • www.tripplite.com
2
2
2
2
3
3
3
4
4
4
Copyright © 2008 Tripp Lite. All trademarks are the sole property of their respective owners.
2
1 – Introduction
2 – Important Safety Instructions
SRCABLETRAY provides roof-mounted cable routing and power/data cable segregation for Tripp Lite’s SmartRack Enclosures.
SRCABLETRAYEXP provides vertical expansion for SRCABLETRAY. (SRCABLETRAY also provides secure mounting points for Tripp
Lite’s SRCABLELADDER accessory, sold separately. SRCABLELADDER allows cable bundles to span aisles and/or spaces between
enclosures. See the SRCABLELADDER manual for more information.)
• Install in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids and gasses, conductive
contaminants, dust and direct sunlight.
• Provide suitable grounding in accordance with all applicable electrical wiring regulations.
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life
support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a
flammable anesthetic mixture with air, oxygen or nitrous oxide.
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation and operation of the products described in this
manual. Read all instructions and warnings thoroughly before attempting installation. Failure to comply may invalidate the warranty and
cause property damage and/or personal injury.
• Phillips Screwdriver
• 13 mm Open-End Wrench or Crescent Wrench (For SRCABLETRAY installation only.)
If anything is missing, call Tripp Lite for assistance at +1.773.869.1234. Note: SRCABLETRAY and SRCABLETRAYEXP are sold separately.
SRCABLETRAY
Trough Section (1)
Support Sections (2)
#8-32 x 1/4 Phillips Screws (8)
M6 Lock Washers (4)
M6 Hex Nuts (2)
24-inch Ground Cable (1)
SRCABLETRAYEXP
Expansion Sections (2)
#8-32 x 1/4 Phillips Screws (8)
1-1 Parts List
1-2 Tools Required
A1 A2
C1
E1
E1
F1
B1
B1
B2
A2
D1
D1
F1
C1
B2
A1
3
3 – SRCABLETRAY Installation
Note: You can remove the roof panel to aid installation, but this step is not required.
Assemble the cable tray by attaching the support sections Ato
the trough section Bwith the included screws. Note: The support
sections should be attached inside the flanges of the trough
section, not outside.
Insert the tabs Cat one side of the cable tray into the matching
roof panel slots D. (Several sets of slots are compatible, allowing
you to adjust the cable tray’s position to match your preference.)
Compress the unattached cable tray support section Auntil you
can insert the remaining tabs Einto the matching roof panel
slots F. When you release pressure from the cable tray support
sections, they will expand to provide a secure fit.
Use the included hex nut Gand lock washers Hto connect one
end of the included ground cable Ito a grounding post Jat
the corner of the cable tray. Connect the other end of the ground
cable to the metal frame of the rack enclosure. (Follow the ground
wires connected to the rack enclosure’s doors to locate several
convenient ground connection points on the frame.)
1
1
2
3 4
A
C
C
DD
A
B
E
E
F
F
G
J
I
4 – SRCABLETRAYEXP Installation
Note: You must install SRCABLETRAY before installing SRCABLETRAYEXP. SRCABLETRAYEXP includes two expansion sections; you may
install one or both, depending on your needs.
4-1 One Expansion Section
Attach the expansion section Ato the cable tray Bwith the
included screws.
1
1
A
B
34
2
H
H
TO
4
5 – Storage and Service
6 – Warranty and Warranty Registration
4-2 Two Expansion Sections
Place the first expansion section Aon the cable tray Bas shown. Place the second expansion section Con the first expansion
section Aas shown. Align the screw holes of the cable tray and
expansion sections, then connect the expansion sections to the
cable tray with the included screws.
12
12
4 – SRCABLETRAYEXP Installation (continued)
Storage
The unit must be stored in a clean, secure environment with a temperature less than 40° C (104° F) and a relative humidity less than 90% (non-
condensing). Store the unit in its original shipping container if possible.
Service
The unit is covered by the limited warranty described in this manual. For more information, call Tripp Lite Customer Service at +1.773.869.1234.
Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 5 years from the date of initial purchase.
If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES
OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES
OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND
CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)
Tripp Lite; 1111 W. 35th Street; Chicago IL 60609; USA
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great
variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.
Warranty Registration
Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Made in China.
1111 W. 35th Street, Chicago, IL 60609 USA
+1.773.869.1234 • www.tripplite.com 200804131 93-2807
