DisplayPort over Cat6 Extender
and Receiver Kit, 4K/60 Hz
DisplayPort over Cat6 Model: B127A-1A1-BDBD
DisplayPort to HDMI over Cat6 Model: B127A-1A1-BDBH
Español 13 • Français 24 • Русский 35 • Deutsch 46
20-09-170-Book.indb 120-09-170-Book.indb 1 4/6/2021 3:50:06 PM4/6/2021 3:50:06 PM
Package Contents
Product Features
B127A-1A1-BDBH
• DisplayPort 1.2a to HDMI over Cat6 Power over Cable (PoC)
Extender Kit
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal, as specified in HDMI
2.0, up to 230 ft. (70 m) from the source.
• Built-in local HDMI port supports 4K @ 60 Hz signal
• Remote receiver unit features built-in equalization (EQ) control
and auto EDID image adjustment
• Supports up to 7.1-channel surround sound audio
• Receiver features built-in Toslink port for audio extraction function
• HDCP 2.2 compatible
• Plug-and-play - no software or drivers required
• Supports bi-directional IR and USB 1.1 function by DIP switch selection
• Includes mounting hardware that enables both the local transmitter and
remote receiver units to be wall-mounted, rack-mounted or pole-mounted
2
• Transmitter and Receiver Units
• External Power Supply Plug Adapters: NEMA 1-15P North America;
AS/NZS 3112 Australia; BS 1363 U.K.; CEE 7/16 Schuko
• Mounting Hardware
Optional Accessories:
• N202-Series Cat6 24 AWG Solid-Wire Patch Cables
• P569-XXX-CERT or P568-XXX-2A Series High-Speed HDMI 2.0 Cables
• P580-Series DisplayPort Cables with Latches
20-09-170-Book.indb 220-09-170-Book.indb 2 4/6/2021 3:50:06 PM4/6/2021 3:50:06 PM
3
Product Features
B127A-1A1-BDBD
•
DisplayPort 1.2a over Cat6 extender and receiver kit with Power over Cable (PoC)
• Extends a 4K x 2K (3840 x 2160) @ 60 Hz signal up to 230 ft. (70 m)
from the source
• Built-in local HDMI port supports 4K x 2K (3840 x 216) @ 60 Hz resolutions
• Remote receiver unit features built-in equalization (EQ) control and audo
EDID image adjustment
• Supports up to 7.1-channel surround sound audio
• Receiver features a Toslink port for audio extraction
• Supports DisplayPort 1.2a and is HDCP 2.2 compatible
• Plug-and-play - no software or drivers required
• Supports bi-directional IR and USB 1.1 function by DIP switch selection
• Includes mounting hardware that enables both the local transmitter and
remote receiver units to be wall-mounted, rack-mounted or pole-mounted
20-09-170-Book.indb 320-09-170-Book.indb 3 4/6/2021 3:50:06 PM4/6/2021 3:50:06 PM
4
Disclaimer
Before installation, check the following settings of your source(s)
and TV/monitor(s):
1. Set to display 60 Hz. Double-check factory settings, in case the default
is set to a lower frequency (Hz) than advertised.
2. Ensure the input setting of your monitor is set at HDMI 2.0. Some
displays may have default setting at HDMI 1.4
Note: This is only important for the B127A-1A1-BDBH model; the B127A-1A1-
BDBD
will need DP 1.2a settings.
3. Verify your monitor has the HDR feature enabled. Some displays
may have this feature disabled as a factory setting.
4. Check if the Ultra HD (UHD) Deep Color setting is enabled on your TV/
monitor. Confirm with your TV/monitor manufacturer which HDMI ports
support UHD Deep Color.
Note: Only for the B127A-1A1-BDBH model.
5. Check the USB/IR DIP switch, as the default setting is set to "IR".
Note: To connect a local monitor to your installation, the UHD Deep Color setting
may need to be disabled on your local TV/monitor (depending on the make/
model) to achieve 4K/60 Hz resolution.
20-09-170-Book.indb 420-09-170-Book.indb 4 4/6/2021 3:50:06 PM4/6/2021 3:50:06 PM
5
Mounting Instructions
The B127A-1A1-BDBH and B127A-1A1-BDBD include mounting hardware
that allows for a variety of mounting methods. The following images
illustrate how the included mounting brackets can be attached for different
installations.
19” Rack-mount Pole-mount
Wall-mount
Note: The model shown in the below images is for illustrative purposes only. Your
product may vary by model number, size or port orientation. The mounting options
for all over IP units are the same.
20-09-170-Book.indb 520-09-170-Book.indb 5 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
6
Standard Extender Kit Installation
Model B127A-1A1-BDBH
Notes:
1. Test to ensure the entire installation works properly before pulling cables through
ceilings/walls.
2. To achieve maximum distance and performance, use 24 AWG solid wire Cat6
cable. Using stranded-wire Cat6 cable or cable with a gauge (AWG) size higher
than 24 AWG will result in shorter extension distance. Higher gauge cabling,
such as 26 AWG, has a more limited transmission capability than lower gauge
cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid-wire
cabling.
3. The installation diagram shows a B127A-1A1-BDBH unit.
4. External power is not required for remote receiver units due to Power over Cable
(PoC) technology incorporated in the transmitter units.
1. Make sure all equipment in the installation—such as monitors, the
DisplayPort source and the transmitter—is powered OFF.
B127A-1A1-BDBH extender kit
LOCAL / TRANSMITTER REMOTE / RECEIVER
Micro-USB cable
Toslink cable
Up to 230 ft. Cat6 solid cable at 4K/60 Hz
Up to 15 ft. DisplayPort cable at 4K/60 Hz
Up to 15 ft. HDMI 2.0 cable at 4K/60 Hz
DisplayPort
Source
Monitor TV
Up to 230 ft. (70 m) at 4K/60 Hz
IR Control
Pad
IR
SENSOR
IR Control
Pad
IR
SENSOR
USB
MOUSE
USB
KEYBOARD
20-09-170-Book.indb 620-09-170-Book.indb 6 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
7
Standard Extender Kit Installation
2. Using a DisplayPort cable, connect the DisplayPort source to the
INPUT port on the local transmitter unit.
3. Optional for B127A-1A1-BDBH: Using an HDMI cable (such as
Tripp Lite P569-XXX-CERT or P568-XXX-2A Series cables), connect
a local monitor to the LOCALOUT port on the B127A-1A1-BDBH local
transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit
to the RJ45 port on the remote receiver unit.
5. Using an HDMI cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect the remote receiver unit’s HDMI
port to a monitor.
6. Turn the power on to your connected TVs/monitors. The LOCAL (orange)
LED will illuminate to indicate the local port has been connected to
a display.
7. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED on the local transmitter unit
will illuminate to indicate the unit is receiving power from the external
power supply. The POWER (green) LED on the remote receiver unit
will illuminate to indicate the unit is receiving power from the local
transmitter unit through PoC technology.
Note: The external power adapter can be plugged into either the transmitter
or receiver unit.
8. Turn on the power to the DisplayPort source. The OUTPUT (orange)
LED on the local transmitter unit will illuminate to indicate a signal is
being received from the source.
9. The (orange) RJ45 LED will illuminate on both the local transmitter and
remote receiver units to indicate a signal is being received from the
source to display. The screen should now display on the connected
monitor.
20-09-170-Book.indb 720-09-170-Book.indb 7 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
8
Standard Extender Kit Installation
Model B127A-1A1-BDBD
Notes:
1. Test to ensure the entire installation works properly before pulling cables through
ceilings/walls.
2. To achieve maximum distance and performance, use 24 AWG solid wire Cat6
cable. Using stranded-wire Cat6 cable, or cable with a gauge (AWG) size higher
than 24 AWG, will result in shorter extension distance. Higher gauge cabling,
such as 26 AWG, has a more limited transmission capability than lower gauge
cabling. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid-wire
cabling.
3. The installation diagram shows a B127A-1A1-BDBD unit.
4. External power is not required for remote receiver units due to Power over Cable
(PoC) technology incorporated in the transmitter units.
1. Make sure all equipment in the installation—such as monitors, the
DisplayPort source and the transmitter—is powered OFF.
B127A-1A1-BDBD extender kit
LOCAL / TRANSMITTER REMOTE / RECEIVER
Micro-USB cable
Toslink cable
Up to 230 ft. Cat6 solid cable at 4K/60 Hz
Up to 15 ft. DisplayPort cable at 4K/60 Hz
Up to 15 ft. HDMI 2.0 cable at 4K/60 Hz
DisplayPort
Source
Monitor TV
Up to 230 ft. (70 m) at 4K/60 Hz
IR Control
Pad
IR
SENSOR
IR Control
Pad
IR
SENSOR
USB
MOUSE
USB
KEYBOARD
20-09-170-Book.indb 820-09-170-Book.indb 8 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
9
Standard Extender Kit Installation
2. Using a DisplayPort cable, connect the DisplayPort source to the
INPUT port on the local transmitter unit.
3. Using an HDMI cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect a local monitor to the LOCALOUT
port on the B127A-1A1-BDBD local transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit
to the RJ45 port on the remote receiver unit.
5. Using a DisplayPort cable, connect the remote receiver unit’s
DisplayPort port to a monitor.
6. Turn the power on to your connected TVs/monitors. The LOCAL (orange)
LED will illuminate to indicate the local port has been connected to
a display.
7. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED on the local transmitter unit
will illuminate to indicate the unit is receiving power from the external
power supply. The POWER (green) LED on the remote receiver unit
will illuminate to indicate the unit is receiving power from the local
transmitter unit through PoC technology.
8. Turn on the power to the DisplayPort source. The OUTPUT (orange)
LED on the local transmitter unit will illuminate to indicate a signal is
being received from the source.
9. The (orange) RJ45 LED will illuminate on both the local transmitter and
remote receiver units to indicate a signal is being received from the
source to display. The screen should now display on the connected
monitor.
20-09-170-Book.indb 920-09-170-Book.indb 9 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
10
USB/IR/Toslink Controls
The extender kit provides the following functional controls:
• USB 1.1 – One USB Micro-B input at transmitter, dual USB-A outputs
at receiver
• Bi-Directional IR – Dual 3.5 mm jacks at both the transmitter and receiver
• Toslink output at receiver and transceiver
(Optional) Connect the included IR-OUT cable to the transmitter unit’s
IR-OUT port. Place the sensor on the IR-OUT cable in an unobstructed
area within clear view of the device being controlled. Then connect the
included IR-IN cable to the receiver unit’s IR-IN port. The IR-IN cable will
communicate the desired command via the transmitter’s IR-OUT cable.
Note: The IR-OUT cable receives the signal from the remote control and
sends it to the device being controlled (e.g. Blu-ray™ player, etc.).
(Optional) With a user-supplied USB Micro-B cable (such as Tripp Lite
U050-XXX Series USB cable), connect to the transmitter’s Micro-B port.
Then connect a keyboard and mouse to the available USB-A ports on the
receiver unit.
(Optional) Connect a Toslink cable (such as Tripp Lite's A102-XXM Series
cables) to a set of speakers, an audio receiver or other audio system
equipped with Toslink digital outputs.
20-09-170-Book.indb 1020-09-170-Book.indb 10 4/6/2021 3:50:07 PM4/6/2021 3:50:07 PM
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Sprachen:
Andere Tripp Lite Sender Handbücher
Beliebte Sender Handbücher anderer Marken
Dejero
Dejero EnGo 3x Bedienungsanleitung
Rosemount
Rosemount 4600 Bedienungsanleitung
Speaka Professional
Speaka Professional 2342740 Bedienungsanleitung
trubomat
trubomat GAB 1000 Bedienungsanleitung
Teledyne Analytical Instruments
Teledyne Analytical Instruments LXT-380 Bedienungsanleitung
Rondish
Rondish UT-11 Bedienungsanleitung
