Tru-Test S3 Bedienungsanleitung
1
This guide provides basic instructions for setting up and using the S3 indicator. For
more information, visit www.tru-test.com
Before you start.................................................1
Setting up the indicator .....................................2
Installing the indicator .......................................5
Changing indicator settings with Data Link ........6
Weighing an animal ..........................................9
Maintenance and care .......................................9
Compliance .....................................................10
1
Before you start
Check that you have all of these items. If anything is missing, contact your supplier.
2
2
Setting up the indicator
It is recommended that you set up the indicator at home before you begin weighing
animals.
Charging the battery
Fully charge the indicator overnight by plugging it into a computer or charging it with
a USB power adaptor, such as supplied with most mobile phones.
Setting unit weights
When you first power up the indicator, you will need to select whether you will be
weighing in kg or lb before you can begin weighing.
1. Press to choose between the flashing kg or lb units.
2. Press to select the flashing units you will use.
The units you select will remain selected even after you power the indicator off and
on again. If you need to change the units, hold down for 3 seconds to swap
between kg or lb.
The indicator is now ready to be installed.
3
Record weigh sessions and change the indicator settings (such as units or
Resolution) from your phone using the MiHub Data Link app, or from your
Windows* computer, using Data Link for PC. Then, track your animals’
weights and average daily gains towards your targets, using MiHub
Livestock Management.
MiHub Data Link for mobile
The MiHub Data Link mobile app is the easiest way to record weights and change the
settings of the S3 indicator. You can weigh animals individually or in groups.
Afterwards, weigh session data will be available in MiHub Livestock where you can
monitor your animals’ weights and average daily gains, and forecast their growth to
ensure you meet your weight targets.
Download the app from the App Store* or Google Play*:
Supported devices:
iPhone* (iOS 9 and above)
iPad* (iOS 9 and above)
Android* smartphone (Android 4.4 and above)
To connect your mobile device to the S3 indicator:
1. Open MiHub Data Link, and at the prompt create a MiHub
Livestock account.
2. Choose the S3 indicator from the list of devices that appear.
3. Connect to the S3 indicator to record weights or to change
settings.
Learn more about MiHub Data Link at livestocksupport.mihub.tru-test.com
4
Data Link for PC
Data Link for PC enables you to connect your Windows computer to the S3 indicator
to change settings on the indicator, record weights and upload your sessions to
MiHub Livestock.
Download the Data Link for PC software from tru-test.com
1. Open Data Link for PC on your Windows
computer.
2. Plug the indicator into your computer with
the USB cable supplied.
3. Wait for the indicator to connect to record
weights or to change settings.
Learn more about Data Link for PC at livestocksupport.mihub.tru-test.com
MiHub Livestock
If you have recorded your weights using Data Link you can view your data online,
anywhere, with MiHub Livestock Management.
MiHub Livestock helps you to track your animals’ weights and average daily gains,
and forecast their growth, to ensure you meet your weight targets.
You can monitor your animals in groups and act early if they fall behind target, or if
you record visual ID’s you can individually track and identify top performers and slow
growing stock.
1. Visit mihub.tru-test.com to create an
account or log in.
2. Add animals to a group to track their
weights and average daily gains
towards your target weights.
Learn more about MiHub Livestock at livestocksupport.mihub.tru-test.com
5
3
Installing the indicator
Ensure the indicator is fully charged before use.
1. Mount the indicator onto a post or
crush/chute using the mounting bracket
and mounting kit.
2. Plug the load bar cables into the
indicator, and secure the cables with
cable ties.
3. Power on the indicator.
To install the load bars, refer to the manual that shipped with your load bars.
6
4
Changing indicator settings with
Data Link
You may want to change the indicator settings depending on your weighing scenario.
MiHub Data Link for mobile makes this a quick and simple process on your mobile
device. Alternatively, launch Data Link for PC on your Windows* computer.
Selecting non-Tru-Test load bars
The S3 indicator is pre-calibrated to work with leading non-Tru-Test load bars.
1. Plug your load bars into the indicator.
2. Connect to the indicator using Data Link on your mobile device or Windows*
computer.
3. Select to open Settings, and go to the Load bar type menu.
4. Select your load bars from the list that appears.
If your load bars are not on the list, you need to perform a span calibration.
Span calibration
If your load bars are not available for selection on Data Link, you will need to perform
a span calibration to ensure that your animals are weighed correctly.
1. Connect to the indicator using Data Link on your mobile device or Windows*
computer.
2. Select to open Settings, and choose Span calibration.
3. Follow the steps to complete the span calibration.
7
Auto power down
By default, the indicator will power down after 15 minutes of inactivity, unless it is
plugged in and charging.
On
Indicator powers down after 15 minutes of inactivity
Off
Indicator remains powered on until battery runs out, or it is powered off
manually
The default Auto power down setting is On.
Auto zero
Auto zero promotes rapid weighing between animals, and removes the need to press
the Zero button after each animal has been weighed.
On
Rapid weighing between animals is enabled
Off
Press zero after each animal is weighed
The default Auto zero setting is On.
You may want to remove Auto zero if you are weighing grain or produce
that takes time to come to full weight on the load bars.
8
Resolution
The resolution is the number of kg (or lb) the scale will increment by as weight is
added.
For example, if the animal weighs under 200 kg (or under 500 lb), the weight will be
displayed in the nearest 0.5kg (or 1 lb). If the animal weighs between 200-500 kg
(or 500-1000 lb), the weight will be shown in the nearest 1 kg (or 2 lb). The default
resolutions are listed below; however, you can change the minimum weighing
resolution.
Changing the resolution may cause the scale to take longer to stabilise on a weight.
Small resolutions on large weights may not stabilise. Ensure that you have set the
correct resolution for your weighing environment.
Weight range (kg)
Resolution
Weight range (lb)
Resolution
0-200 kg
0.5 kg
0-500 lb
1 lb
200-500 kg
1 kg
500-1000 lb
2 lb
500-1000 kg
2 kg
1000-2000 lb
5 lb
1000-capacity
5 kg
2000-capacity
10 lb
Learn more about the S3 indicator settings at
livestocksupport.mihub.tru-test.com
9
5
Weighing an animal
Check that the indicator is zeroed before you begin weighing. If not, press
on the indicator.
If you are using Data Link to record weights, open the app on your mobile device or
PC and connect to the indicator.
1. Start a new session and name it.
2. Move the animal onto the platform.
3. When the weight has stabilised, press to record the
weight.
4. When the weight is recorded, move the animal off the
platform and wait for the weight to return to zero.
If the indicator is not displaying 0 kg (0 lb) between animals or there are
problems with inaccurate or unstable weights, make sure that the bars
are firmly secured to the concrete floor and free from stones or dirt, and
that the load bars are properly connected to the indicator.
6
Maintenance and care
Do not leave the indicator or indicator connectors immersed in water.
Remove dust and moisture from the plugs using methylated spirits, ethyl alcohol,
or a suitable electrical contact cleaner. Stronger spirits must not be used, as they
may react with the plastic.
10
Europe - Instructions for disposal of product
This symbol on the product or its packaging indicates that this product
(and its battery) must not be disposed of with other waste. Instead, it is
your responsibility to dispose of your waste equipment by handing it
over to a designated collection point for the recycling of waste electrical
and electronic equipment. The separate collection and recycling of your
waste equipment at the time of disposal will help conserve natural
resources and ensure that it is recycled in a manner that protects human
health and the environment. For more information about where you can
drop off your waste equipment for recycling, please contact your local
city recycling office or the dealer from whom you purchased the
product.
This product has a lithium-ion ( IFpR20/71, 4.8 Wh) rechargeable battery.
For instructions on how to dismantle this product for recycling, email
7
Compliance
FCC notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
- Any changes or modifications not expressly approved by Datamars could void the user's authority to operate the equipment
