TTI KR-120M Bedienungsanleitung

Digital Electronic Cabinet Lock

Model KR-120M

NOTE: Please read this entire User Guide very carefully before using the

lock and keep the guide in a safe place for future reference. Thank you!

User Guide

View of Lock Rear Panel:

Section 1: Product Overview

Key code

Front Lock Panel:

Battery: requires 1 button cell battery (CR-2032 / 3V)

Battery Life: >5,000 cycles or approximately 1 year in stand-by mode.

Working Temperature Range: 5° F (-15℃) to 149 ° F (+65℃)

Working Humidity Range: 5% - 95%

•1 Management Override Code

•15 User Codes (entry only)

•2 Mechanical keys

[1234][OK] is the factory default User Code

IMPORTANT NOTICE!

BEFORE attempting to program any codes for the lock, please carefully read

the following information:

Section 2: Specifications

Section 3: Operation

Lock Installation Diagram:

To unlock the Tool Chest:

•Enter a valid 4-digit code plus [OK] on the keypad, the lock will make a long beep

sound, the green light will flash, and the digital lock’s turn knob will immediately

unlock and remain unlocked.

•Turn the digital lock turn knob clockwise ¼ turn to disengage the Tool Chest’s

mechanical lock system. Note: the turn knob will be in the vertical position

To lock the Tool Chest,

•Ensure the drawers and chest lid are completely closed

•Turn the digital lock knob counterclockwise ¼ turn to engage the Tool Chest’s

mechanical lock system. Note: the turn knob will be in the horizontal position

•Ensure all the drawers and lid are secured and locked

•Enter a valid 4-digit code plus [OK] on the keypad, the lock will make a long beep

sound, the green light will flash, and the turn knob will now be locked

Programming Your Digital Lock

A valid code is 4 digits plus the [OK] button.

Be sure to test the lock to ensure proper working order before programming the codes.

When changing a code, the replacement code must be entered while the lock is

unlocked.

It is recommended that all codes be prepared in advance for reference while

programming the initial lock codes.

Store these codes in a secure location for future reference after the initial lock

programming is completed.

Management Override Code

This code overrides and erases all of the user codes. It consists of 4 digits plus the [OK]

button. After using the Management Override Code, the digital lock is restored back to

the factory default user code of [1234][OK]. You will need to reprogram your User

Codes thereafter. For this reason, it is recommended to program your Management

Override Code before programming your User Codes.

•[2222][OK] is the factory default Management Override Code

•Please change your Management Override Code immediately after initial use

following the directions given in this manual

•Record your new Management Override Code in a secure location for future

reference.

To Change Management Override Code:

•Input [OK] [OK] [2] [OK] on the keypad GREEN light blinks

•Input [OLD Management Override Code] and [OK] on the keypad

•Input [NEW Management Override Code] and [OK] to change the code

successfully

User Code

User Codes provide entry only

Up to 15 User Codes can be programmed

•[1234][OK] is the factory default User Code

•Please change the User Code to your preferred 4-digit code immediately after you

have finished assembly of the tool chest and set the Management Override Code.

•Record the User Code in a secure location for future reference.

To Set the 1st User Code

•Input [OK] [OK] [1] [OK] on the keypad

•GREEN light blinks

•Input [Default User Code]and [OK] on the keypad

•Input [NEW User Code] and [OK] to change the code successfully

•A long beep will sound and the light will flash green for a couple seconds

To Set 2nd – 15th User Code

•Input [OK] [OK] [1] [1] [OK] on the keypad

•GREEN light blinks

•Input [Management code] and [OK] on the keypad

•Input [User Code] and [OK] to add the code successfully

To Change Programmed User Codes

•Input [OK] [OK] [1] [OK] on the keypad

•GREEN light blinks

•Input [OLD User Code] and [OK] on the keypad

•Input [NEW User Code] and [OK] to change the code successfully

•A long beep will sound and the light will flash green for a couple seconds

Code Protection

You can input any random string of numbers including the [ * ]button directly before

and/or after entering the correct user access code to engage the lock as long as the

correct 4-digit user code is entered sequentially.

•This step can be done for added security if you do not want a by-stander to watch

you enter the lock code.

•This code protection should be less than 20 digits in all—but it has to contain the

string of numbers in your User Code in its exact order.

•For example, if your user code is [1234][OK] and you wish to use the code

protection, you can enter any random pattern of numbers such as

[2513*][1234][6*52][OK] to engage the lock.

•A short beep will sound when each key is pressed and the light will flash green.

•Correct Code: A long beep will sound and the light will blink green.

•Incorrect Code: 3 short beeps will sound and the light will blink red

•Successful programming of access code: a long beep will sound and the light will

blink green

•Lock reset: 2 short beeps will sound and the light will blink green

•Low Battery: 6 short beeps will sound and the light will blink blue

The Lock Reset button erases all User codes and Management Override Codes and

restores them to the factory default codes listed in Section 3 - Operation.

•Press the [OK] button on the keypad

•Using the tip of a pen or similar, press the reset button on the back of the lock for 2

seconds until it sounds with 2 short beeps. The light will blink green after the

successful reset.

Lock Reset Button

Section 4: Indicator Sounds and Lights

Section 5: Lock Reset

Forgot User Code

•Use Management Override Code to unlock

oLock returns to the factory default user code

oProgram a new User Code

-OR-

•Use Mechanical Key to unlock

oPress the Reset button on the back side of the lock to restore to factory default

codes

oProgram a new Management Override Code and User Code

Forgot Management Override Code

•Use Mechanical Key or the User Code to unlock

oPress the Reset button on the back side of the lock to restore to factory default

codes

oProgram a new Management Override Code and User Code

Lock has No Power

•RED light blinks, keypad has no reaction

•Open the battery compartment by carefully removing the two small screws and

replace the old battery with a new “CR2032” 3V cell battery.

•Replace the battery cover and screws. Be careful not to over-tighten the screws

•Re-test the lock function.

•Keep the keypad clear of dirt, grease, and solvents

•Use a damp cloth to wipe clean

•Do not spray with lubricants or oils

Section 6: Troubleshooting

Section 7: Care and Use Information
