01
EN
T7 V20.7
USER MANUAL
KULLANIM KILAVUZU
MANUAL DE USUARIO
MANUEL DE L’UTILISATEUR
MANUALE UTENTE
BENUTZERHANDBUCH
01
EN
TABLE OF CONTENT
CHAPTER 1 - Preface.......................................................... 02
1.1 Regulations Information.........................................................02
FCC Information...............................................................................03
1.2 Safety Information..................................................................04
1.3 Conventions For This Manual ...............................................05
CHAPTER 2 - Getting To Know The Basics........................05
2.1 Product Specifcation................................................................05
2.2 Preparing your Computer .....................................................07
2.3 Product Overview....................................................................08
CHAPTER 3 - Getting Started.............................................15
3.1 AC Adapter ...................................................................................15
3.2 Knowing The Keyboard ..........................................................16
3.2.1 For Keyboard Users...............................................................16
3.3 Using the touchpad / clickpad ............................................. 18
CHAPTER 4 - BIOS Setup....................................................19
4.1 About BIOS Setup.....................................................................19
4.1.1 When To Use BIOS Setup? ..................................................19
4.1.2 How to Run BIOS Setup ?....................................................19
4.2 BIOS Setup Menu ....................................................................20
4.2.1 Main Menu ..............................................................................20
4.2.2 Advanced Menu.....................................................................21
4.2.3 Security Menu.......................................................................22
4.2.4 Boot Menu..............................................................................23
4.2.5 Exit Menu................................................................................24
T7 V20.7
USER MANUAL
EN
02
CHAPTER 1
1.1 Regulations Information
Preface
•CE compliance
This device is classed as a technical information equipment (ITE) in class B
and is intended for use in living room and ofce. The CE-mark approves the
conformity by the EU-guidelines:
- EMC Directive 2014/30/EU,
- Low Voltage Directive 2014/35/EU(equals A2 : 2013),
- RF Directive 2014/53/EU
Rechargeable Battery Notice
Do not
1. Throw into fire or a hot oven, or mechanically crush or cutting of a BATTERY
2.Throw or immerse into water
3.Heat to more than 60°C
4.Repaire or disassemble
5.Leave in an extremely low air pressure environment
6.Leave in an extremely high-temperature environment
A power cord is connected to a socket-outlet with earthing connection.
The unit can be operated at an ambient temperature of max. 35°C (95°F). Do not
subject it to temperatures below 5°C (41°F) or above 40°C (104 °F).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
PREVENTION OF HEARING LOSS
CAUTION: Listening to music at high volume levels and for extended durations
can damage one’s hearing. In order to reduce the risk of damage to hearing, one
should lower the volume to a safe, comfortable level, and reduce the amount
of time listening at high levels. Headsets should comply with EN 50332-2
requirements.
03
EN
FCC Information
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guar-
antee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CAUTION: Any changes or modifications not expressly
approved by the grantee of this device could void the
user’s authority to operate the equipment.
EN
04
1.2 Safety Information
Do not apply heavy pressure to the computer
or subject it to any form of strong impact as
this can damage the computer’s components or
otherwise cause it to malfunction.
1
Never cover or block the air vents including
those located at the base of the computer.
Never cover your computer or AC adaptor with
any object.
Do NOT expose to or use near liquid, rain, or
moisture.
Do NOT use the modem during electrical storms.
Do not use or expose this device around
magnetic felds as magnetic interference may
aect the performance of the device.
To keep your computer in prime operating
condition, protect your work area from direct
sunlight.
2
3
4
5
05
EN
1.3 Conventions For This Manual
2.1 Product Specification
This message contains important information
that must be followed for safe operation.
CAUTION:
NOTE: This message contains information for special situations.
CHAPTER 2
Getting To Know The Basics
This User’s Manual provides technical information of instructions and illustra-
tions on how to operate this notebook for the customer. Please read this manual
carefully before using this notebook.
Physical Characteristic
Processor - CPU
Graphic Card - GPU
I/O Port
Dimension 395.7*263.6*30.05mm
Support Processor i7-12650H
Graphic Card 8 GB RTX 4060
DC-in x 1
USB USB Type A @Right side x2
USB 3.2 (Gen1) (Power o mode support USB power, but w/o bc1.2 protocol)
USB Type A @Left side x1: USB 2.0
USB Type C @Rear side x1
USB 3.2 (Gen2) (Power o mode support USB power,but w/o bc1.2 protocol)
Weight 2.5kg +/- 5%
RAM DDR4 3200MHz
LCD 17.3” 1920x1080, IPS/72% 144Hz
Memory
Display
EN
06
CAUTION: MODEL IS DESIGNED TO USE WITH THE DC INPUT: 230 Watts
(19.5V/11.8A)3 Pins
Audio
Input
Power
Webcam
Communication Port
Codec: Realtek ALC256 Azalia standard support, D3 mode support
Speaker/Mic Build-in 2 speakers, Speaker : 2W/each
Digital Microphone support
Keyboard Membrane single zone RGB backlight support,
340*109.2*3.6mm
Pointing Device TD1470 TP mylar, Enable/Disable area :10mmx10mm, Palm
Rejection: Support Controller IC change to 1836, support
Windows update
AC Adapter Automatics Voltage adjustment between 100 and 240VAC
50/60Hz, 230 Watts (19.5V/11.8A)3 Pins
Battery Li- polymer Battery, SW Gas Gauge IC, soft pack
4 cells (4s1p 4100 mAh) 62Wh
HD Webcam HD webcam with D-MIC*1
LAN Supports 10/100/1000 Mb/sec, PCI-E interface, Power Down
Mode D1~D3 support, PCIe ASPM L1.1, L1.2 support, UI for
network package management
Wireless LAN +BT INTEL AX201
I/O Port
RJ45 x 1
HDMI x 1 (HDMI 2.1)
Mini DP x 1
Mic / Audio Combo x 2
Card Reader x 1 USB 3 interface, SD/SDHC/SDXC, UHS-I speed
Connecter: Full SD size
07
EN
2.2 Preparing your Computer
Connect the AC adaptor’s DC output plug to the DC IN jack.
The display panel can be opened to a wide range of angles for optimal viewing.
Press the power button to turn on your notebook computer.
A
B
C
EN
08
2.3 Product Overview
Please become familiar with each component before you operate the computer.
Top-Open View
The product’s color/ LED color, I/O port, indicator location, and specication
will depend upon the actually shipping product.
NOTE
09
EN
CAUTION: When you are not using the computer, keep the LCD screen closed to
protect it from dust.
Webcam
A device that allows you to record video or take photographs with
your computer.
1
Camera Status LED
The Camera Status LED shows the Camera status.
2
Microphone
Built-in microphone
3
LCD Screen
Displays of your notebook computer.
4
Caps Lock Status LED
Default: ON (White)
Charging / Battery Indicator
Charging (Power On): White
Charging (Power o): White
Battery low (<6%): White (3 Sec/Cycle)
Charging nish: O
Power o: O
5
Power Button
Press this button to turn the computer’s power on or o.
6
Turbo / Balance / Oce Mode Switch
Oce mode: OFF (Default)
Balance mode: White (Bottom light)
Turbo mode: Both white (All lights)
7
