tws EVE 1 Bedienungsanleitung
User Manual
TWS EARBUDS
Package Contents
After unpacking, please confirm that it contains the following contents
1/10
▲EVE 1 TWS gaming earbuds
▲Charging case
▲User Manual
▲USB charging cable
Key Function
2/10
Manual operation
(Outside the charging case)
Automatic operation
Power on
Long press for 2 sec
Open the charging case
Power off
Long press for 7 sec
Put in the charging case and close
Short press twice
Long press
on the left
Long press
on the right
Audio is playing
Play/Pause
Enter & exit game mode
Music/Movie
Sound effect switch
(ringtone：Gaming mode/Gaming mode off) (ringtone：Music mode/Movie mode )
Note: You can switch between Music/Movie sound effects only after you exit the game mode
Short press once
Short press twice
Long press for 2 sec
Incoming call
Answer the call
Hang up the call
Incoming call rejection
/switching call
Touch sensor
Light status
3/10
Light Color
System Status
Ice blue light and pink light
flashing alternately
Ready to pair
Ice blue light flashes slowly
Paired successfully
Ice blue breathing light
Play audio
Green breathing light
Enter game mode
Red light flashes slowly
Low battery
Light Color
System Status
The corresponding power LED is on,
and the next power LED flashes
Charging the charging case
LED lights off
When the charging case is fully charged
Blue light flashes slowly
When the earbuds are charging
LED lights off
When the earbuds are fully charged
Earbuds light display
position
Charging case light display
The position of the earbuds light
The position of the charging case light
How to pair Bluetooth
After booting up and automatically forming a team,
enter the "pairing mode"
Open the phone "Settings" →"Bluetooth"
Search "EVE 1" for pairing
4/10
EVE 1
How to charge
Note: 1. Open the charging box, take out the earbuds,
and tear off the insulating film on the earbuds
2. The charging voltage of this product: 5V
5/10
Warning: The rechargeable battery contained in this product must be
properly disposed of in order to be recycled. Please do not put the battery in
the fire to avoid explosion.
Recommendation: If the lithium battery product is not in use, it needs to be
charged once every three months.
Product parameter
6/10
Brand name：GAMODIO
Product name：True Wireless Stereo gaming earbuds
Product number：EVE 1
Bluetooth name：EVE 1
Bluetooth version：VER5.1
Bluetooth distance：> 10 m
Sound effect mode：Music/Movie/Gaming
Low latency：≤ 60 ms
Frequency response：20 Hz –20 kHz
Speaker parameters：13 mm, 32Ω
The battery capacity of the earbuds：45 mAH
The battery capacity of the charging case：500 mAH
Charging time of the earbuds：≤ 2 hr
Charging time of the charging case：≤ 2 hr
Product size：6.5*6.2*2.4 mm
Product weight：58 g
Warranty description
Warranty content
1 Unable to turn on;
2 Unable to charge when connected to a power source;
3 No sound from the speaker;
4 The function is not operating normally;
5 Bluetooth cannot be connected
Warranty scope
1 From the date of receipt, within 7 days after the product has the
performance failures listed in the "warranty content", the product can be
returned and exchanged after identification, and the seller shall bear the
freight back and forth.
2 From the date of receipt, within 8-15 days if the product has the
performance failures listed in the "warranty content", the product can be
exchanged after identification, and the return freight will be borne by
each.
3 From the date of receipt, if the product has performance failures listed
in the "warranty content" within 12 months, it can be repaired free of
charge after identification, and the buyer pays the return shipping fee.
7/10
The following are not covered by the warranty
1 The product is damaged due to its own reasons;
2 Unauthorized dismantling by non-designated service providers;
3 Damage caused by force majeure such as natural disasters
4 Does not meet the above "warranty content"
5 Exceeded the warranty period
Manufacturer：深圳璽睿科技有限公司 G&O Audio Co.,LTD.
Address：shenzhen baoan district xinan sea prosperous street community
N23 excellence in times square C building Haitian road 15-3, 3005
Consulting telephone：008675586088656
8/10
Common solutions
9/10
Problem
What to do
The earbud is manually triggered
to turn on, and the left and right
earbuds are not connected to
turn on
⚫Since the left and right earbuds are not in a
team state after shutting down, manually
triggering the power on is a non-linked power
on. The single earbuds need to be turned on
separately, and they will automatically form a
team after being turned on.
⚫After putting back the charging case, closing
the lid, and then out of the case, the earbuds
will automatically turn on to form a team.
Earbuds don’t pair with mobile
device
⚫Turn off the earbuds manually or put it in the
charging case and close the cover, then turn
it on again.
⚫Turn off the power of your mobile device and
turn it on again.
No sound
⚫Increase the volume of earbuds and mobile
devices.
⚫Confirm the connected mobile device and
make sure that the correct device is used.
⚫Use different music sources.
⚫Pair with another mobile device.
⚫If you connect two mobile devices, pause the
audio of the first mobile device, and then play
the audio from the other mobile device.
⚫Move the mobile device within the Bluetooth
range of the earbuds (10m).
Poor sound quality
⚫Use different music sources.
⚫Move the mobile device to a position further
away from the earbuds and away from any
interference or obstacles.
⚫Remove debris and earwax on the earbuds
and the sound holes of the earbuds.
