Before you begin…

Check the box contents!

The retail motherboard package should contain the following:

1x Thunder HEsl-T motherboard

1x 34-Pin floppy drive cable

1x Ultra-DMA-100/66/33 IDE cable

1x Ultra160 SCSI cable (for optional SCSI if included onboard)

1x Cable set: 9-pin Serial

1x Thunder HEsl-T user’s manual

1x TYAN driver CD

1x Adaptec 7899W NT Ultra160 SCSI driver diskette (if optional SCSI included)

1x I/O shield with 2 LAN ports

If any of these items are missing, please contact your vendor/dealer for replacement before

continuing with the installation process.

http://www.TYAN.com

Chapter 1: Introduction

1.1 Congratulations!

You are now the owner of the TYAN Thunder HEsl-T motherboard, the most reliable, high

performance motherboard for dual Pentium III processing. Designed to be portable as well as

flexible, the Thunder HEsl-T can fit into standard ATX chassis and 2U rackmount chassis. This

platform utilizes ServerWorks’ high-performance ServerSet III HE-SL chipset, enabling next

generation application and platform support. Intel Pentium III processors between 500MHz and

1.266GHz* are supported in single and dual configuration. *Please see TYAN’s website for

updates and information concerning CPU information and support:

http://www.tyan.com

This integrated performance board is supported in an ATX form factor. Features of the Thunder

HEsl-T include onboard UltraDMA-33 (Ultra160SCSI with onboard Adaptec controller) and

multiple boot options.

With both I/O and drive controller support onboard, dual 64-bit PCI slots provide upgrade solutions

for future add-in cards. Integrated 2D/3D graphics provided by the onboard ATI RAGE XL

controller enables ease of use into 2U and larger, chassis. Dual onboard LAN ports provide

connectivity without add-in overhead.

The Thunder HEsl-T supports up to 6GB of Registered ECC PC133 SDRAM.

Remember to visit TYAN’s Website at http://www.tyan.com. There you can find information on all

of TYAN’s products with FAQs, distributors list and BIOS setting explainations.

1.2 Hardware Specifications

Processor

•Dual PGA370 ZIF sockets

•Supports up to two Intel Pentium III

processors

•Supports Intel’s Pentium III Processor DP

•One onboard VRM (VRM 8.5) supports 2

CPUs

•Front-side bus support for 100/133MHz

Chipset

•ServerWorks ServerSet III HE-SL

•Integrated I/O APIC

•CSB5 south bridge

•CIOB north bridge

•National 87417 Super I/O ASIC

Memory

•Four 3.3v 168-pin DIMM sockets

•Supports up to 6GB of Registered

PC133/100 SDRAM

•Supports ECC (72-bit) memory

Integrated LAN

•Dual Intel 82559 LAN controllers

•10/100Mbps max data rate per controller

Integrated 2D/3D Graphics

•ATI RAGE XL graphics controller

•4MB frame buffer (SDRAM)

•Standard 15-pin analog VGA port

Integrated SCSI (manufacturing option)

•Adaptec AIC-7899W controller

•Dual-channel Ultra160 SCSI support

•160MB/sec max data throughput per

channel

•Supports up to 4 LVD SCSI devices per

channel

Hardware Monitoring

•Winbond W83782D hardware monitoring

ASIC

•CPU Temp, voltage and fan monitoring

http://www.TYAN.com

Expansion Slots

•4 64-bit/66MHz (three 5v, one 3.3v) PCI

slots

•2 32-bit/33MHz PCI slots

Integrated PCI IDE

•Dual-channel master mode

•Up to four E-IDE drives

•Support for DMA/ATAPI devices

Integrated I/O

•One floppy connector supports up to two

drives (second one via optional slim FD

connector)

•Two 9-pin 16550-based serial ports (one via

optional cable)

•One 25-pin SPP/ECP/EPP parallel port (via

optional cable)

•Four USB ports (two via optional cable)

•PS/2 keyboard and mouse ports

BIOS

•AMI 4Mb BIOS Flash ROM

•Auto-configure IDE drive types

•Multiple boot options

•DMI 2.0 compliant

Form Factor

•ATX footprint (12” x 9.6”, 304.8mm x

243.84mm

•One 20-pin ATX power connector

•One Serial port and one VGA port

•Stacked USB (two) ports

•Side-by-side LAN (two) ports

•Stacked keyboard and mouse ports

Regulatory

•FCC DoC (declaration of Conformity)

•European Community of CE (declaration of

Conformity)

1.3 Software Specifications

OS Windows NT/2000

http://www.TYAN.com

Chapter 2: Board Installation

Installation

You are now ready to install your motherboard. The mounting hole pattern of the Thunder HEsl-T

matches the ATX system board specifications. Your chassis should support a standard ATX

motherboard form factor.

How to install our products right… the first time

The first thing you should do is read this user’s manual. It contains important information which will

make configuration and setup much easier. Here are some precautions you should take when

installing your motherboard:

(1) Ground yourself properly before removing your motherboard from the antistatic bag.

Unplug the power from your computer power supply and then touch the power supply.

For the safest conditions, TYAN recommends wearing a static safety wrist strap.

(2) Hold the motherboard by its edges and do not touch the bottom of the board.

(3) Avoid touching the motherboard components, IC chips, connectors, and leads.

(4) Avoid touching memory module contacts and IC chips

(5) Place the motherboard on a grounded antistatic surface or on the antistatic bag from

which it came in.

Having reviewed the precautions above, the next step is to take the motherboard out of the

cardboard box and static bag, hold it by its edges and place it on a grounded antistatic surface,

component side up. Inspect the board for damage.

NOTE DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED

http://www.TYAN.com

2.1 – Jumper Section

Pin outs for certain connectors are available on the TYAN website: http://www.TYAN.com

2.2 – Front Panel Connector (J26)

17 15 13 11 9 7 5 3 1

18 16 14 12 10 8 6 4 2 1,3: HD LED

2,4: Power LED

5,7: Reset Switch

6,8: Power Switch

2.3 – CMOS Reset (JP8)

1 2 1,2: Connect these two pins together to reset the CMOS settings in case an incorrect

setting causes system instability or you have forgotten your system/setup password.

-Power off the system and disconnect the power supply.

-Close pins 1 and 2 on JP8

-Wait about 5 seconds

-Open pins 1 and 2 on JP8

-Reconnect the power supply and power on the system

2.4 – Force 33MHz Click for PCI Bus 1 (JP12)

1 2 Closed: All devices on PCI Bus1 (slots J31, J32, J33) will run at 33MHz Only.

Open (default): PCI Bus1 can run at 66MHz or 33MHz. Actual speed is determined

by the PCI card(s) plugged into J31/J32/J33. If any card is only 33MHz capable, all

cards in Bus1 will run at 33MHz. If all cards support 66MHz, or if no cards are

installed, then Bus1 will run at 66MHz.

http://www.TYAN.com

2.5 – Force 33MHz Click for PCI Bus 2 (JP13)

1 2 Closed: All devices on PCI Bus2 (slots J35 and onboard SCSI) will run at 33MHz

Only.

Open (default): PCI Bus1 can run at 66MHz or 33MHz. Actual speed is determined

by the PCI card plugged into J33. If any card is only 33MHz capable, all cards in Bus1

will run at 33MHz. If all cards support 66MHz, or if no cards are installed, then Bus1

will run at 66MHz.

2.6 – Host Bus (FSB) Clock Frequency Select (JP5)

Closed: Host Bus clock frequency is fixed at 100 MHz, regardless of processor type.

Use this setting to force Host Bus clock to 100 MHz when using 133 MHz FSB

CPU(s).

Open (default): Host Bus clock frequency is determined by the type of processor(s)

installed. For CPUs that support 133 MHz Front Side Bus (FSB), Host Bus clock will

be automatically set at 133 MHz, but can be over-ridden to 100 MHz if JP5 is closed.

For CPUs that are only capable of operating at 100MHz FSB, Host Bus frequency will

be auto-configured to 100MHz, and 133 MHz is NOT possible.

2.7– CPU Core-to-Bus Frequency Multiplier Select (JP1-4)

These jumpers allow you to adjust the processor core multiplier. However, retail processors will

not allow multiplier adjustment.

JP1 JP2 JP3 JP4 JP1 JP2 JP3 JP4 Ratio

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

Open

Short

4.0x

4.5x

5.0x

5.5x

6.0x

6.5x

7.0x

7.5x

8.0x

8.5x

9.0x

9.5x

10.0x

10.5x

11.0x

11.5x

12.0x

4.0x is the default setting.

Note: Whatever the multiplier is set to, the setting will apply to both CPUs. These settings only

affect non-retail (engineering sample, Q-spec) CPUs. For a production (S-spec) CPU, the

multiplier is fixed inside the CPU, and these jumpers will not have any affect regardless of their

setting.

http://www.TYAN.com

2.8 – Add-in Drive Controller Activity LED (J27)

2Connect your chassis front panel IDE LED to this jumper for activity monitoring of all

drives connected to the onboard IDE controllers.

2.9 – External PC Speaker (J28)

Connect your chassis speaker to these pins for speaker functionality.

2.10 – TYAN Server Management Daughter Card (SMDC) connector (J29)

You may use this connector for the server management card (purchased separately).

2.11 – USB Port 2, 3 Connectors (J24, J22)

1 1

2 2

3 3

4 4

5 5

JP24 JP22

You may use these connectors for front panel USB connectors if your chassis

allows.

2.12 – COM Port 2 (J18)

1 1

2 2

3 3

4 4

You may use the included COM2 cable in this connector if you wish to use the

second serial port.

2.13 LAN Activity LED (J9)

You may use the following pins for LAN activity LED.

Pins 1 and 2 are for LAN1 activity

Pins 3 and 4 are for LAN2 activity

Inhaltsverzeichnis

Andere TYAN Hauptplatine Handbücher

TYAN

TYAN 1.00 Bedienungsanleitung

TYAN

TYAN Thunder K8WE S2895 Bedienungsanleitung

TYAN

TYAN AST2150 IPMI Bedienungsanleitung

TYAN

TYAN S5221 Bedienungsanleitung

TYAN

TYAN TOMCAT I875P Bedienungsanleitung

TYAN

TYAN TIGER I7322DP Bedienungsanleitung

TYAN

TYAN THUNDER LE S2510 Bedienungsanleitung

TYAN

TYAN S3227 Bedienungsanleitung

TYAN

TYAN S7065 Bedienungsanleitung

TYAN

TYAN TOMCAT IVS D Bedienungsanleitung

TYAN

TYAN Tiger i7501 Bedienungsanleitung

TYAN

TYAN Tempest i5100T Bedienungsanleitung

TYAN

TYAN S5630 Bedienungsanleitung

TYAN

TYAN S5517 Bedienungsanleitung

TYAN

TYAN Thunder n4250QE-S4985G3NR-E Bedienungsanleitung

TYAN

TYAN THUNDER K8QW Bedienungsanleitung

TYAN

TYAN S5501 Bedienungs- und Wartungshandbuch

TYAN

TYAN Tiger 100 S1832DL Bedienungsanleitung

TYAN

TYAN S7100 Bedienungsanleitung

TYAN

TYAN Tomcat i925X S5130 Bedienungsanleitung

TYAN

TYAN THUNDER I7500 Bedienungsanleitung

TYAN

TYAN TYAN S1471 Bedienungsanleitung

TYAN

TYAN TIGER 230 Bedienungsanleitung

TYAN

TYAN THUNDER 2400 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
