U-Line ADA SERIES Installationshandbuch

USER GUIDE & SERVICE MANUAL

SAFETY •INSTALLATION & INTEGRATION •OPERATING INSTRUCTIONS •MAINTENANCE •SERVICE

ADA Series •BI98 •15" Crescent Ice Maker

RIGHT PRODUCT. RIGHT PLACE. RIGHT TEMPERATURE. SINCE 1962.

USER GUIDE & SERVICE MANUAL

u-line.com

Table of Contents

Installation

Integrated Panel Dimensions

Integrated Panel Installation

Grille / Plinth Installation

USER GUIDE u-line.com

Introduction

WELCOME TO U-LINE

Congratulations on your U-Line purchase. Your product comes from a company with over ve decades of premium modular ice

making, refrigeration, and wine preservation experience. U-Line creates products focused on functionality, style, and inspired

innovations — paying close attention to even the smallest details. Applications include residential, outdoor, ADA height

compliant, marine, and commercial. Complete product categories include Beverage Centers, Wine Refrigerators, Ice Machines,

Refrigerators, Freezers, and Dispensers.

Our advanced refrigeration systems, large and exible capacities, and Built-In to Stand Out®clean integrated look allow you

to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby

family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products

are available worldwide.

PRODUCT INFORMATION

Looking for additional information on your product? User Guides, Spec Sheets, CAD Drawings, Compliance Documentation,

and Product Warranty information are all available for reference and download at u-line.com.

PROPERTY DAMAGE / INJURY CONCERNS

In the unlikely event property damage or personal injury is suspected related to a U-Line product, please take the following

steps:

1. U-Line Customer Care must be contacted immediately at +1.414.354.0300.

2. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been

altered or repaired in the eld without prior written approval from U-Line, claims will not be eligible.

GENERAL INQUIRIES

U-Line Corporation

8900 N. 55th Street

Milwaukee, Wisconsin 53223 USA

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.414.354.0300

Email: sales@u-line.com

u-line.com

CONNECT WITH US

SERVICE & PARTS ASSISTANCE

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.800.779.2547

Service Email: onlineservice@u-line.com

Parts Email: onlineparts@u-line.com

Designed, engineered and assembled in WI, USA

USER GUIDE

Integrated Panel Dimensions 1

u-line.com

SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE

Integrated Panel Dimensions

DOOR PANEL INSTALLATION

Door Panel Preparation

A custom door panel may be inserted into the door frame.

Custom door panels can be flat or raised, as long as the

maximum panel thickness, where inserted into the door

reveal (channel), is no more than 1/4" (6 mm) thick. For

raised panels, the depth of the reveal is 1/4" (6 mm) on

all four sides.

NOTICE

Raised panels will reduce the door’s 90° swing/

zero clearance if the unit is installed next to a

wall or similar type of structure.

Panel Dimensions

The door panel must not weigh more than 5 lbs.

Width Height

13-15/16" (354 mm) 15-15/16" (405 mm)

USER GUIDE

Integrated Panel Installation 1

u-line.com

SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE

Integrated Panel Installation

This model accepts a 1/4" insert panel.

INSERT PANEL INSTALLATION

Install the insert as follows:

CAUTION

Use care when handling the insert. Insert edges

may be sharp.

1. Remove top hinge screw pin

with Phillips head screwdriver.

Remove door by tilting forward

and lifting off bottom hinge pin.

2. Pull door gasket out of groove

(top edge of door only). Start in

the middle and pull outward,

moving toward the edge. This

may take some force.

3. Remove two outside screws

holding door handle. Slightly

separate door handle from door.

4. Pull handle up and off.

5. Slide custom door panel insert into 1/4" (6 mm)

channel in door front.

NOTICE

Use care not to damage magnet, located on door

bottom when installing door insert. Do not set

door on bottom edge when pushing insert into

place.

6. Holding door gasket out of the way, replace handle on

door, making sure it is seated properly on insert and

that screw holes line up.

7. Install two small screws removed in Step 3.

8. Starting at the corners and working inward, push door

gasket into place on door.

9. Place door on bottom hinge pin and install upper hinge

screw.

USER GUIDE

Grille - Plinth Installation 1

u-line.com

SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE

Grille - Plinth Installation

REMOVING AND INSTALLING GRILLE

WARNING

Disconnect electric power to the unit before

removing the grille.

When using the unit, the grille (plinth strip/base

fascia) must be installed.

WARNING

DO NOT touch the condenser fins (4). The

condenser fins are SHARP and can be easily

damaged.

Removing the grille

1. Disconnect power to the unit.

2. Loosen the screw (1).

3. Remove grille (2) from unit.

Installing the grille

1. Align cabinet and grille holes and secure, but do not

over tighten grille screw (1).

2. Reconnect power to the unit.
