U-Line CO29BTP Bedienungsanleitung

COMBO ICE MAKER/REFRIGERATOR

FEATURES BENEFITS

1. Manual Defrost Ice Maker Greater daily ice production capacity. Less affected by warmer ambients.

Produces up to 18 lbs. of ice per day in a 70° ambient temperature.

2. Stainless hinges and mounting hardware Corrosive resistant.

3. Travel pin – Factory installed Helps keep the door secure when en route. Pre-installed at factory.

4. 2.1 cubic feet of refrigeration Ice making and refrigeration in one compact unit.

5. Front vented for built-in installation No need for extra fans, air space, or special venting to the outside of the

cabin. Do not obstruct front grille.

6. No drain required for water Easy and inexpensive to install. Only needs 1/4" outside diameter water

line connection.

7. Conserves on water Only 2-1/4 gallons of water needed to produce approximately 18 lbs. of ice.

8. Field reversible door with integrated door Flexible installation capabilities to ensure easy access. With left hand door

handle swing installation, allow for 145° door opening to ensure easy removal of

ice bin.

9. Accepts custom door panel Match surrounding cabinets.

10. In-door storage 2 door shelves with clear bottle retainers for greater storage and easy

access.

11. Tempered glass shelves Generous amount of shelving space, easy to clean, helps contain spills.

ADDITIONAL FEATURES:

• See through, removable ice bucket, stores 13 lbs. of ice

• Available in 110/115V – 60 cycle or 220/230 – 50/60 cycle

• Shipping weight: 97 lbs.

• Black vinyl clad steel cabinet and door panel

• Door panel size: H 21-13/32" x W 19-13/16"

All specifications subject to change without notice.

8900 N. 55th Street

Milwaukee, Wisconsin 53223

(414) 354-0300

FAX (414) 354-7905

www.u-line.com

* WATER

VALVE

LOCATION

* POWER CORD

* ON BACK OF UNIT

4-1/2

(11.4)

21-7/16 (54.5)

24 (61.0)

20-13/16 (52.9)

1-7/16

(3.7)

1-9/16

(4.0)

3-5/16

(8.4)

3-5/16

(8.4)

28-1/2

(72.4) WATER INLET

VALVE

INCHES (CENTIMETERS)

KCC Printed in U.S.A. P/N COMBO 29BTP

Model COMBO 29BTP
