U-Line Echelon 2175BEV Betriebsanleitung

eatures Beneﬁts

8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: 414-354-0300 • Fax: 414-354-7905

www.u-line.com

BEVERAGE CENTER

MODEL 2175BEV

Capacity: 6 cubic feet

Defrost Type: Automatic (cycle) Defrost

Color: Stainless Steel and Custom Overlay Frame

Feature Benefit

Touch Control Digital

Technology

• Full-featured, easy-view command center - right at your

fingertips

• Easy to set and see temperatures

• Manages key model functions and provides user alerts

Multiple temperature zones • Top two wine racks - approximately 45°

• Middle to lower refrigeration shelves - approximately 38°

- Store and serve beverages at their best-suited

temperatures

- Soda, water and beer at cooler temperatures

• Wine at a warmer temperature - up to 16 (0.75 L) bottles

Black interior Elegant visual appearance

Adjustable on/off interior light • Automatically illuminates when the door is opened

• May be manually turned on when door is closed for

viewing contents

• Auto shut-off after four hours

• Recessed so as not to interfere with access to wine

Open door alarm Audible alert when door is left open

Two tempered glass shelves Allows for flexible storage space.

Full extension slide-out vinyl-

coated wine racks

Allow for easy access to all wine bottles and prevent bottles

from slipping. Up to sixteen (16) wine bottle capacity (0.75 L).

Contoured maple-trimmed wine

racks

Wood can be stained or replaced with a solid surface

material to match surrounding décor.

Tinted, thermal glass door • Allows for effective product presentation

• Protects wine and other products from potentially

harmful ultraviolet light rays

Stainless steel model • Offers a seamless stainless steel-trimmed glass door with a

sculpted stainless steel handle and a full wrap stainless

cabinet, and a stainless-like grille

• Must order right- or left-hand hinged

• Optional bold commercial-style stainless steel handle

available for purchase

Overlay model • A custom overlay frame must be installed

• Black vinyl-clad cabinet, resistant to scratching, peeling

and flaking, and black grille

• Field-reversible doors for flexible installation

Self-closing door • Engages when the door is open 8-10"

• Ensures a positive door seat and prevents bounce-back

Built-in or freestanding Provides custom look when built-in with no additional

venting clearance needed on sides, top or rear. Do not

obstruct the grille.

Leveling legs More precise undercounter fit, durable, factory-installed

Sabbath or “Black Out” mode Easily turn off all lights and control displays.

Contemporary grille design Integrates seamlessly with surrounding cabinetry

imensions Speciﬁcations

8900 North 55th Street • Milwaukee, Wisconsin 53223

Phone: 414-354-0300 • Fax: 414-354-7905 • www.u-line.com

Beverage Center Model 2175BEV

Specifications Capacities

(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.

Stainless steel model: Must be ordered right- or left-hand hinged.

Stainless steel model: Allow 2-1/2" clearance on the hinge side for 90° door opening when against a wall.

To prevent potential interior liner damage, please consult the Installation Guide if you choose to stain the wood trim on the

wine racks.

Please visit www.U-Line.com for Installation Guide.

All specifications subject to change without notice.

(53.3)

22-1/2

(57.2)

23-1/4

(59.1) WITH 3/4"

OVERLAY FRAME

34-1/8

(86.7)

FULL

RETRACT

HEIGHT

35-1/8

(89.2)

FULL

EXTEND

HEIGHT

23-15/16

(60.6)

5-7/8

[14,9]

2-7/8

(7.3)

(53.3)

23-1/4

(59.1)

25-3/4

(65.4)

* ON BACK OF UNIT INCHES [CENTIMETERS]

2175BEV

* POWER CORD

(Stainless Steel) (Overlay)

Shipping Weight:

Overlay Model

Stainless Steel Model

125 lbs (57 kg)

(1) Running Amps 2.4

(1) Maximum Start-up Amps 9.8

Refrigerator volume 6 cubic feet

Freezer volume N/A

Approximate daily ice production N/A

Ice storage N/A

Wine bottle storage (0.75 L) Up to 16
