U-Prox IP500 Montageanleitung

1.006

Wireless access control panel

U-Prox IP500

Smart Handle

Installation and programming manual

http://u-prox.com

About this document

This manual covers installation, adjustment and use of U-Prox IP500 Smart Handle

Smart Handle (hereinafter panel) wireless single door access control panel. Smart

Handle can be mounted on any type of door from 38-59mm wide. It is specially

designed to accommodate the 3570 and 3580 series of Australian Lock-Wood

Mortise Locks.

Read this manual carefully prior to installing the system.

Characteristics, Intended use and parameters of the panel are described in the

section "Summary". Section "Terms" provides an explanation of terms found in this

document.

The look of the panel, the pins and the mode of work are described in the

"Description section". Order of installation, adjustment of external devices and panel

configuration are described in "Working with the device" section.

Technical support

To get warranty and technical support you can apply to authorized service centers,

situated on the territory of countries, enlisted in the warranty card.

Warranty and technical support are performed on the territory of the country, where

the customer applied for warranty or free service.

Technical information is available on the system website

www.u-prox.com

Attention! Read this manual carefully prior to installing the system.

Installation, adjustment and utilization of panel is allowed only to persons or

organizations with the appropriate authority from the manufacturer

http://u-prox.com

Contents

Brief description of the panel.................................................................................................4

Intended use.........................................................................................................................4

Summary ..............................................................................................................................5

Terms ...................................................................................................................................6

Description and operation.....................................................................................................8

Panel.................................................................................................................................8

Assignment of the access control panel contacts ............................................................10

Sound and light panel indication is on reader light emitting diode (LED) of reader..........10

Panel operation...................................................................................................................10

"Normal" mode................................................................................................................ 10

Opening door with RF ID.................................................................................................11

Exit from premises...........................................................................................................11

Access denial upon entering RF ID .................................................................................11

“Alarm” Mode...................................................................................................................11

"Free Pass” Mode............................................................................................................11

“Blocking" mode .............................................................................................................. 12

RF ID properties (cards)..................................................................................................12

The communicator.............................................................................................................. 12

Wireless lock system architecture.......................................................................................14

Wireless lock system deployment.......................................................................................15

Server addresses automatic configuration for U-Prox IC L..............................................16

U-Prox IC L addresses automatic configuration for repeaters .........................................17

U-Prox IP500 Smart Handle automatic configuration ......................................................18

How to work with the device................................................................................................18

Changing the locking side ...............................................................................................21

Installation sequence.......................................................................................................22

Door contact connection..................................................................................................24

Request-To-Exit contact connection................................................................................24

Service maintenance ..........................................................................................................25

Battery replacement ........................................................................................................25

Return to factory settings.................................................................................................25

Factory settings...............................................................................................................25

Emergency unlock...........................................................................................................25

http://u-prox.com

Brief description of the panel

U-Prox IP500 Smart Handle panel - a device designed to control access to

residential and business premises, including time of passage of and events. Smart

Handle can be mounted on any type of door from 38-59mm wide. It is specially

designed to accommodate the 3570 and 3580 series of Australian Lock-Wood

Mortise Locks, and can be retrofitted in just 10 minutes. Smart Handle is compatible

with all U-Prox IP door and elevator controllers and available with a high security

range of card technologies. It can be specified in a variety of environments including

health, education, public, commercial, hotels and leisure.

Panel operates built-in reader of ASK and FSK cards.

U-Prox IP500 Smart Handle processes the information received from the reader, and

unlocks door. The internal handle operates freely.

Panel has end-of-line supervised input for door position supervision.

The panel can work offline or as part of the network. To add it to access control

network, U-Prox IC L control panel used. U-Prox IC L panel communicates with U-

Prox IP 500 via ISM band radio and via Ethernet (wired computer network) with

access control system server.

To extend the range of wireless system U-Prox HE and U-Prox HW repeaters are

used, communicating with U-Prox IC L over Ethernet (wired computer network) or

Wi-Fi (wireless computer network).

U-Prox IP500 Smart Handle has advanced hardware capabilities and intellectual

functions to control access point (AP) and reader in the U-Prox access control

system. U-Prox IP500 Smart Handle has enough non-volatile memory to store

access database for 3,000 users and up to 6,000 events.

Intended use

Panel U-Prox IP500 Smart Handle is designed for operation in access control

systems (ACS) of diverse scale in small offices as well as on large enterprises.

Panels are incorporated in ACS via ISM band radio and computer network Ethernet

or wireless Wi-Fi.

The panel provides access to one room.

http://u-prox.com

Summary

Power 3 AAA alkaline batteries

32000 openings after battery replacement

2 years operation after battery replacement

Built-in ASK and FSK reader

Direct operation with U-Prox IC L panel at 915.5-927.5 MHz

oGuaranteed range 6 - 20 m

oU-Prox HE and U-Prox HW repeaters for range extension

Door contact input

Request-to-exit on inner door handle

Adjusted with U-Prox IP software

Real-time clock

Non-volatile memory:

IDs

3000

Permanent

1000

Temporary

2000

Events

6000

Time zones

250

Weekly schedules

250

Holidays

250

Temperature range: 0 - +55 0C at 80% relative humidity.

Maximum relative humidity 80% without condensation

http://u-prox.com

Terms

Identifiers

In access control systems each user has a unique RF ID. Identifiers can take the

form of a plastic card, key FOB etc.

Reader

The information on the identifiers is read with READERS, connected or built-in to the

ACS control panel. U-Prox IP500 Smart Handle has built-in reader.

Access point (AP)

Access point is a logical concept of the access control system implying control of

passing through a door in one direction. It consists of reader, access control panel

(or its part), door supervision devices (like door contact, RTE button etc.) and door

locking device. For instance, the turnstile with two-way passes has two Access

points –one for entrance and the other one for exit, door of this type is called

double-sided door. A door with a reader on one side has only one Access point –

Entry point, and it is called single-sided door.

Direction of passage

Passageway - is a logical unit of ACS, controlling passage through the access point

in one direction. It includes reader, access control panel (or part of access control

panel), actuator. So, tourniquet with double-sided control has two passageways, and

the door, having single-sided reader - only one passageway. Access point, which

consists of two passageways, is called double-sided, and the point of access, which

consists of one direction of passage - single- sided.

Door contact

Properly designed ACS is used to supervise door status (opened or closed), such as

magnetic door sensor, sensor of the turnstile rotor position, inductive sensor of the

road barrier, etc.

This ensured that the system prevents situations when several users access the

door with one RF ID or door left open after user’s access and so on. For these

purposes the magnetic sensor of door closing, position sensor of the turnstile rotor

and the position sensor of boom barrier are connected to the input of access control

panel. The input used to connect these sensors, is called the input of sensor of

passage (or Door Contact)

Normally panel supplied with Door Contact switched off. To use Door contact install

Request-To-Exit microswitch and turn Door contact supervision ON.

RTE (request to exit)

To unlock the door and exit from the premises turn the inside handle.

Normally panel supplied without installed Request-To-Exit sensor. In this case you must

adjust Request-To-Exit microswitch as shown in paragraph "Request-To-Exit contact

connection"

http://u-prox.com

Opening the door with the key or the cylinder handle generates an event FORCED

ENTRY (if the door contact is connected).

Door time

If door sensor is open, corresponding access point goes into “Alarm” mode (refer to

“Alarm» mode below). Alarm is not invoked, if contact is opened during Door Time

interval. This interval starts when access is granted and lasts for the programmed

time or terminates on opening and subsequent closing of door contact.

Schedules

Date and time of valid access are indicated when setting user access rights.

Depending on modification, control panel stores up to 250 time zones. 250 week

schedules can be combined from these time zones. Moreover, control panel can

store up to 250 holidays, which happen once a year.

Time zones

Time zones are a part of schedule. This is a way to organize a range of days and

times and associate it with access levels.

Time zones are utilized by the application to validate, authorize, or perform various

functions based on schedules.

Downloading

Control panel is to be downloaded after all parameters are set –modes of inputs,

outputs, access rights and others. During downloading parameters are rewritten into

access control panel.

http://u-prox.com

Description and operation

Panel The look of the access control panel is shown in Fig. 1 (a and b)

1. Outer escutcheon

2. RF ID reader

3. Light emitting diode

4. Card presence Detector

5. Locking Cylinder

6. Outer handle

7. Door contact (optional)

8. Mortise lock

9. Cover plate

10. Inner escutcheon

11. Inner handle

Fig. 1a. U-Prox IP500 Smart Handle panel installed on the door. Model for

Lockwood 3582 Mortise Lock (89.9 mm)

http://u-prox.com

1. Outer escutcheon

2. RF ID reader

3. Light emitting diode

4. Card presence Detector

5. Locking Cylinder

6. Outer handle

7. Door contact (optional)

8. Mortise lock

9. Cover plate

10. Inner escutcheon

11. Inner handle

Fig. 1. U-Prox IP500 panel installed on the door. Model for Lockwood 3582 Mortise

Lock (89.9 mm)

http://u-prox.com

Assignment of the access control panel contacts

Name

Assignment

Fig. 2. U-Prox IP500 Smart Handle

back board

Door Contact for door

position supervision

FactSet

Return to factory

setting button

Sound and light panel indication is on reader light emitting diode (LED) of reader

Siren sound and LED blinks reds on identifier presentation –low battery,

replace

Long beep and LED lights red constantly –access denied

Short beep and LED lights green constantly –access granted

One beep and LED alters green and yellow light –free pass mode

One beep and LED blinks red –door blocked mode

Three beeps and LED blinks red –panel download in progress

Tapping sound signals - within range of infrared sensor entered obstacle.

Siren sound and LED blinks reds sounds - within range of the infrared sensor

obstacle is more than a minute. Control panel also sent event "Reader sensor

trouble"

Panel operation

The panels supplied unloaded with factory settings below in document. To make the

panel work in access control system (ACS) you have to add it to the system using

the automatic adjustment mode or manually and download the program settings

from U-Prox Software.

Panel goes to mode “Normal” after downloading program settings if door contact is

in normal state. Panel can supervise one access point with request-to exit operated

with inner door handle. There are four different modes of access point: "Normal",

"Alarm", "Blocking" and "Free pass". Mode "Free pass" has the highest priority, as

this mode is activated in the event of a fire, followed by modes of "Blocking", "Alarm"

and "Normal" in decreasing order of priority.

"Normal" mode

This is the main mode of panel. In this mode the panel grants or denies access to

RF ID owners.

FactSet

Andere Handbücher für IP500

Inhaltsverzeichnis

Andere U-Prox IP-Zugriffskontrollsysteme Handbücher

U-Prox

U-Prox IP500 Bedienungsanleitung

Beliebte IP-Zugriffskontrollsysteme Handbücher anderer Marken

ZKTeco

ZKTeco SpeedFace-V5L Bedienungsanleitung

Jantar

Jantar REX A-1-9 Bedienungsanleitung

2N Access Unit Merkblatt

Kedacom

Kedacom KSCA120 Series Bedienungsanleitung

H3C

H3C WX2880X Bedienungsanleitung

G4S

G4S S870-EX Leitfaden

PRASTEL

PRASTEL M2000PE Bedienungsanleitung

Allegion

Allegion interflex IF-281 Cylinder Bedienungsanleitung

TECOM

TECOM TS1067E Bedienungsanleitung

Fermax

Fermax Memokey 100C Benutzerhandbuch

Fermax

Fermax CITYLINE MEMOKEY Bedienungsanleitung

Software House

Software House iSTAR Pro 2U RM Bedienungsanleitung

AKCP

AKCP SP+ Bedienungsanleitung

Bpt

Bpt HNA/102 Bedienungsanleitung

Civintec

Civintec CV9601T-T-1F Bedienungsanleitung

BioMax

BioMax N-X90W Bedienungsanleitung

ZKTeco

ZKTeco OP-200 Bedienungsanleitung

FingerTec

FingerTec s-Kadex Bedienungsanleitung
