ASSEMBLY & OPERATING INSTRUCTIONS

ALUMINUM LOADING RAMP

1200 LBS. CAPACITY

94057

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

or any artwork contained herein may be reproduced in any shape or form without the

express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

Page 2SKU 94057 For technical questions, please call 1-800-444-3353.

THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please

complete the owner’s record below:

Model______________ Serial No._____________ Purchase Date_______________

SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the

entire manual to become familiar with the unit BEFORE you begin assembly.

The Aluminum Loading Ramp can convert into a single load ramp or two single load ramps by

removing the hinges.

Technical Speciﬁcations

Construction: Extruded Aluminum ridged platform and side railings

Overall Dimensions: 72” L x 30-1/4” W x 2-13/16” H

Angle Approach: 15-18 degree upward

Approach Length: 2-3/4”

Hinge Dimensions: 3-7/8” L x 3-1/8” W x 5/8” H x 3/32” Thick

Bolt Length: 4-3/8” x 5/16” Diameter

Hardness: 8.8 metric or Grade SAE 5

Chain (QTY = 2): 37” with 1-1/8” links, 0.155” OD. with “S” type hooks

Maximum Weight Capacity: Rated at 1200 Lbs. (combined ramps, evenly distributed)

Net Weight: 34-1/2 Lbs.

Safety Warnings and Precautions

WARNING: When using product, basic safety precautions should always be followed to

reduce the risk of personal injury and damage to equipment.

Read all instructions before using this product!

1. Keep work area clean. Cluttered areas invite injuries.

2. Observe work area conditions. Keep work area well lighted.

3. Store idle equipment. When not in use, the Ramp must be stored in a safe and clean location.

Always lock up products and keep out of reach of children.

4. Use the right product for the job. There are certain applications for which the Loading

Ramp was designed. Do not modify the Loading Ramp and do not use the Loading Ramp for a

purpose for which it was not intended.

5. Check for damaged parts. Before using any product, any part that appears damaged should

be carefully checked to determine that it will operate properly and perform its intended function.

Check for any broken or damaged parts and any other conditions that may affect its operation.

Replace or repair damaged or worn parts immediately. Note: Dents or other imperfections in

the Aluminum Ramp may lead to a weakening of the structural strength of this product; do not

use this ramp if this type of damage is noted.

6. Replacement parts and accessories. When servicing, use only identical replacement parts.

Use of any other parts will void the warranty.

REV 08e

Page 3SKU 94057 For technical questions, please call 1-800-444-3353.

7. Do not operate product if under the inﬂuence of alcohol or drugs. Read warning labels on

prescriptions to determine if your judgment or reﬂexes are impaired while taking drugs. If there

is any doubt, do not operate the product.

8. Use eye protection. Always wear ANSI approved impact safety goggles during assembly.

9. Do not exceed the product’s maximum load capacity of 1200 Lbs (combined ramps).

10. Make proper ground contact. Only use on a ﬂat, solid, dry surface capable of supporting

the Aluminum Ramp and its maximum capacity load of 1200 Lbs. (combined ramps).

Make certain that the tongue edge fully contacts the tailgate of the vehicle and that both safety

chains are secured in place.

11. Support the Ramp. Make certain that the Ramp Safety Chains are attached to the vehicle

before placing a load on the Ramp.

12. Dress properly. Do not wear loose clothing or jewelry as they can be caught in moving parts.

Non-Skid footwear is recommended when assembling and when using the Loading Ramp.

Wear restrictive hair covering to contain long hair.

13. Do not force this product. Do not use inappropriate attachments in an attempt to exceed the

ramp’s capacity.

14. Keep children away. Children must never be allowed in the work area.

15. Keep the Ramp clean. Prior to each use, clean dirt, oil, or any debris off the ramp.

16. Make certain that no persons or pets are under the Ramp or vehicle during loading.

17. Be aware of dynamic loading! If a weight drops onto or bounces on the Loading Ramp, it will

create, for a brief instant, an excess load, which may result in damage to the Ramp, the vehicle

and/or may result in personal injury.

18. Contact between the tongue of the Ramp and the tailgate of the vehicle, may result in

damage to the vehicle’s body ﬁnish.

19. Tailgate must be able to support the Loading Ramp and any vehicle or object loaded into

the vehicle.

20. Never attempt to drive one side of a four wheel vehicle up the ramp in order to use the

Ramp as a vehicle lifting device.

Warning: The warnings, cautions, and instructions discussed in this instruction manual cannot

cover all possible conditions and situations that may occur. It must be understood by

the operator that common sense and caution are factors which cannot be built into

this product, but must be supplied by the operator.

Unpacking

When unpacking your Aluminum Loading Ramp, make certain that all parts on page 6 of this

manual are included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at

1-800-444-3353.

Page 4SKU 94057 For technical questions, please call 1-800-444-3353.

Operation

Your Aluminum Loading Ramp comes completely assembled. It is important that you read the entire

manual to become familiar with the product BEFORE you use the Loading Ramp.

Warning: All persons not involved in the loading process must stand clear of the

Loading Ramp. ESPECIALLY KEEP CHILDREN AWAY. At least one assistant is

required to safely use this ramp.

Warning: Never exceed the 1200 Lb. maximum capacity (combined Ramps). Load the

vehicle slowly. Do not drive a load onto the vehicle.

Warning: Make certain the vehicle you are attaching the Loading Ramp to has its engine

off, its transmission in gear or park, and its emergency brake engaged.

Warning: Before attempting to use this product, make sure the Ramp is completely open

and both sides are laying ﬂat on the tailgate and that the Safety Chains and

hooks are correctly in place.

Note: Walking up or down the Ramp is not recommended. If you must walk on the Ramp,

read and adhere to all safety warnings and instructions provided in this instruction manual.

1. Make certain that the tailgate the Ramp will sit on is dry and clean. Set the tongue of the

Ramp on the tailgate. The tailgate must be strong enough to support the Loading Ramp and

any weight placed onto the Loading Ramp. Stretch the Chain (1) on each side of the Ramp

up into the inside of the truck bed. Attach both Chains (1) to a secure location on the truck

bed. Truck beds will usually have built in hooks or grommets for securing the Chain. The

Chains (1) should be taut so that the Ramp’s tongue can not slip off of the tailgate-see

Figure 1.

2. Very slowly, push the vehicle that you wish to load up onto the Loading Ramp. Get help from

your assistant(s). Never sit on a vehicle while the vehicle is being moved up or down the

ramp.

Caution: If walking up or down the ramp, be extremely careful of your footing.

Only walk on the innermost vertical beams. Never attempt to walk on the outside

edge of the Ramp.

Chains (1)

Truck Bed

Aluminum Loading

Ramp

Secure Chains (1) to

hooks in vehicle

Set Loading Ramp tongue

securely on vehicle tailgate

Figure 1

Be extremely careful not to get your feet or ﬁngers caught between the Left-Ramp (5)

and Right-Ramp (6).

Page 5SKU 94057 For technical questions, please call 1-800-444-3353.

3. Make sure no persons or pets are near or under the Ramp or vehicle. Have an assistant

monitor the Ramp tongue to make sure that no slippage occurs on the tailgate as you slowly

move the vehicle into the truck bed.

4. When you are ﬁnished using the Loading Ramp, remove the Chain hooks from the truck bed

and carefully lift the Loading Ramp away from the truck bed.

Warning: Contact between the tongue of the Loading Ramp and the tailgate of the

vehicle, may result in damage to the vehicle’s body ﬁnish.

5. After use, the Loading Ramp can be folded up. Make certain to lock the latches to secure

the two parts of the Ramp together. Wrap the safety chains around the ramp to secure

them. - see Figure 2.

Converting the Aluminum Loading Ramp into Two Single Ramps

1. To create two single ramps, separate the Left-Ramp (5) from the Right-Ramp (6).

Remove each of the three Bolts (9) and Nuts (10) from the Hinges (8) located in the center

of the Ramp-see Figure 3. After removing the Bolts (9) and Nuts (10), you will have two

single ramps.

2. To assemble the Loading Ramp back into one single Loading Ramp, set the Left-Ramp (5)

and Right-Ramp (6) together with the holes in the Hinges (8) aligned as in Figure 3. Insert

a Bolt (9) through each Hinge (8) and thread on Nut (10).

Note: When using as two single ramps, each single ramp Maximum weight capacity is

600 Lbs.

Maintenance

1. Clean the Ramp after each use. Make certain any dirt, debris, oil or grease are cleaned off

the Ramp.

2. Check the Ramp, Chain Rungs, and hinges for cracks, signs of stress, deformation,

or breakage. Do not use the Ramp if any faults are discovered. Take the Ramp to an

authorized service technician if repairs are required.

3. Before each use, check each hinge Bolt (9) and Nut (10) for tightness.

Figure 2

Latch

Bolt (9)

Nut (10)

Figure 3

Hinge (8)

REV 08e

Page 6SKU 94057 For technical questions, please call 1-800-444-3353.

Parts List

Part # Description Quantity Part # Description Quantity

1 Chain 2 6 Right-Ramp 1

2 Bolt M6 x 40 2

3 Nut M6 4 8 Hinge 3

4 Bolt M6 x 25 2 9 Bolt 3

5 Left-Ramp 1 10 Nut 3

Note: Some parts are listed and shown for illustration purposes only and are not available

individually as replacement parts.

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL

ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO

THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO

REPLACE ANY PARTS OF THE PRODUCT. IN FACT,THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL

REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSEDTECHNICIANS AND NOT BYTHE

BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT

OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Parts/Assembly Diagram
