U.S. General 70320 Montageanleitung

72" TRIPLE BANK

TOP CHEST

Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the

back of the manual near the assembly diagram (or month and year of purchase if product has no number).

Keep this manual and the receipt in a safe and dry place for future reference. 22l

When unpacking, make sure that the product is intact

and undamaged. If any parts are missing or broken,

please call 1-888-866-5797 as soon as possible.

No portion of this manual or any artwork contained herein may be reproduced in

any shape or form without the express written consent of Harbor Freight Tools.

Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein.

Tools required for assembly and service may not be included.

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. 72" Top Chest

SAFETY OPERATION MAINTENANCESETUP

IMPORTANT SAFETY INFORMATION

Use Precautions

TO PREVENT SERIOUS INJURY AND DEATH FROM TIPPING:

1. Do not have more than one

drawer open at a time.

2. DO NOT SIT, STAND OR CLIMB ON THIS ITEM.

DO NOT STEP IN OR ON DRAWERS.

3. Do not allow children to play with or near this

item. This item is NOT children’s furniture.

4. Do not exceed drawer weight capacity, 120 lb per

connected pair of slides. Evenly distribute load

from bottom up. Uneven loading causes tipping. Be

aware of dynamic loading! Sudden load movement

may briefly create excess load causing tipping.

5. Close and lock drawers before moving.

Do not pull, push to move.

6. Center securely within lip on top of cabinet.

7. Place on top of matching cabinet only.

8. Have assistant help place on cabinet.

9. Do not lift while loaded.

10. Close lid when not in use. Lid must be

open for drawers to be unlocked.

11. Use as intended only.

12. Inspect before every use;

do not use if parts are loose or damaged.

13. Maintain product labels and nameplates.

These carry important safety information.

If unreadable or missing, contact

Harbor Freight Tools for a replacement.

Page 3For technical questions, please call 1-888-866-5797.72" Top Chest

SAFETYOPERATIONMAINTENANCE SETUP

Specifications

Drawer Capacity 120 lb per connected pair of slides

Operation Instructions

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document

including all text under subheadings therein before set up or use of this product.

1. Empty all Drawers.

2. Close all Drawers and lock them.

3. If stacked on Bottom Cabinet, to

prevent tipping, push/pull using supplied

handle on Bottom Cabinet only.

4. If using separately from Bottom Cabinet, get

an assistant to help move the Chest.

5. Place only on a flat, level, hard and smooth surface

capable of safely supporting a fully loaded Chest.

6. Unlock Drawers and fill Chest evenly, from bottom

to top. Do not exceed weight capacities.

Page 4 For technical questions, please call 1-888-866-5797. 72" Top Chest

SAFETY OPERATION MAINTENANCESETUP

Maintenance and Servicing

Procedures not specifically explained in this manual must

be performed only by a qualified technician.

TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:

Do not use damaged equipment. If any part becomes damaged,

have the problem corrected before further use.

1. PERIODICALLY, inspect the general

condition of the Chest. Check for:

• loose hardware,

• misalignment or binding of moving parts,

• cracked or broken parts,

• any other condition that may

affect its safe operation.

2. Wipe external surfaces of the Chest with clean cloth.

3. Lubricate Drawer Slides as needed.

Page 5For technical questions, please call 1-888-866-5797.72" Top Chest

SAFETYOPERATIONMAINTENANCE SETUP

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM

IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS

QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE

ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY

ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS

THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Record Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only, and are not available

individually as replacement parts. Parts may not be interchangeable.

Specify UPC number when ordering:

Black: Item 70320, UPC 193175495815

Blue: Item 70321, UPC 193175495822

Gray: Item 70322, UPC 193175495839

Green: Item 70323, UPC 193175495846

Orange: Item 70324, UPC 193175495853

White: Item 70325, UPC 193175495877

Yellow: Item 70326, UPC 193175495884

Red: Item 58708, UPC ,193175444905

Page 6 For technical questions, please call 1-888-866-5797. 72" Top Chest

SAFETY OPERATION MAINTENANCESETUP

Parts Lists and Diagrams

Parts List

Part Description Qty

1Drawer Trim 8

2 Drawer Latch 8

3 Trim Screw, ST4.8 x 7.2 28

4Drawer Trim 4

5 Drawer Latch 4

6 Drawer Mat 8

7 Drawer Mat 4

8Top Tray Mat 1

9 Drawer Slide 15

10 Gas Strut 2

11 Lock 1

Part Description Qty

12 Key 4

13 Lock Link 1

14 Lock Lever 1

15 Grommet Cover 2

16 Grommet 1

17 Grommet Screw, M6 x 20 1

18 Grommet Nut, M6 1

A Drawer 3

B Drawer 6

C Drawer 1

D Drawer 2

Page 7For technical questions, please call 1-888-866-5797.72" Top Chest

SAFETYOPERATIONMAINTENANCE SETUP

Diagram

15 16

26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797

Limited 90 Day Warranty

Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,

and warrants to the original purchaser that this product is free from defects in materials and workmanship for the

period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,

to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper

installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries

to persons or property, or for incidental, contingent, special or consequential damages arising from the use of

our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the

above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transportation charges

prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.

If our inspection verifies the defect, we will either repair or replace the product at our election or we may

elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will

return repaired products at our expense, but if we determine there is no defect, or that the defect resulted

from causes not within the scope of our warranty, then you must bear the cost of returning the product.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
