Uclear WT300 Bedienungsanleitung

WT300

User Manual

Bluetooth Communication Adapter

WT300 Bluetooth Audio Adaptor User Manual

Contents of the retail box

Welcome to

Stereo cable

Remote Control

Charging Cables

Walkie Talkie Cables

User Manual

Rubber grip

AC/USB Charger

WT300 Audio Adaptor

Contents of the Retail Box -------------------------------- 2

Contents ---------------------------------------------------- 3

Overview

General -------------------------------------------------- 4

WT300 at a Glance ------------------------------------- 5

PTT Remote Control at A Glance----------------------- 7

Walkie-talkie Cables ------------------------------------ 8

Rubber Grip --------------------------------------------- 9

Pairing WT300 with UClear Headset

Advanced Communication Mode ---------------------10

Linking Walkie Talkie to the WT300 ------------------11

Walkie Talkie Mode Operations -----------------------12

WT300 MMI Table--------------------------------------14

PTT Remote Control MMI Table -----------------------15

UCLEAR Headset MMI Table---------------------------16

Pairing with Non UCLEAR Headsets

Pairing with Bluetooth Headset using HFP -----------17

Linking Walkie Talkie to the WT300 ------------------18

Walkie Talkie Operations using HFP------------------19

WT300 MMI Table using HFP--------------------------21

PTT Remote Control MMI Table using HFP -----------22

Music streaming Mode

Pairing as Music Adaptor (A2DP) ---------------------23

WT300 MMI Table in Music streaming Mode ---------25

Walkie Talkie Volume Setting -----------------------------26

Aux Input Mode

Aux Input Mode for GPS/Radar Detector -------------27

Remote Control Pairing------------------------------------28

Technical Data for WT300 Bluetooth Adaptor -----------29

Technical Data for Remote Control PTT ------------------30

Notices -----------------------------------------------------31

FCC/IC/NCC Warning -------------------------------------36

CONTENTS

WT300 as Universal Bluetooth Adaptor Kit

The UCLEAR WT300 is capable of connecting non-Bluetooth

audio devices eg. Two-way radios, PTT/iDEN phones, GPS/

Radar Detector or mp3 players to Bluetooth headsets wirelessly.

Compatible Bluetooth devices include any Bluetooth headsets

which support HFP or A2DP (Advanced Audio Distribution

Profile) Bluetooth profiles.

The WT300 can start in 3 modes:

a) Advanced communication mode with UCLEAR headsets

b) HFP (Hands Free Profile) communication mode

c) A2DP music streaming mode

The device will power up based on the previous successful

pairing mode. If the WT300 is previously paired to a HFP

Bluetooth headset, then it will always power up in HFP mode.

To change the operation mode, eg from HFP mode to A2DP

music mode, you need to re-initiate the pairing in A2DP mode,

after pairing is successful, WT300 will then power up in A2DP

music streaming mode.

The WT300 also includes a PTT remote control unit. In

communication mode, you can use the remote control to

activate the PTT button on the two-way radios, PTT/iDEN

phones wirelessly.

OVERVIEW

General

Before using the device, please charge it first!

Charging

oPlease use the mini-USB charging cable to connect the device

to a USB port.

oThe LED indicator would show solid red during charging and

turns solid blue when it is fully charged.

oThe charging time is normally less than 2 hours.

Multi-function

Button

Stereo Audio-in/

Aux-in

Charging/

Walkie Talkie

Port

Reset

Button

LED Status

Indicator

Front View

Reverse

OVERVIEW

WT300 At A Glance

Power On

oPress and hold the Multi-function button for 2 seconds and

the light indicator will flash blue while device powers up.

oIn idle mode, pressing the Multi-function button once will

trigger the device to attempt to connect to the last paired

device in the range.

Power Off

oPress and hold Multi-function button for 5 seconds.

oThe LED indicator will blink red 5 times as device powers off.

Low Battery Indicator

oWhen the battery level is low, the LED indicator blinks red 3

times every 3 seconds. If it is connected to a headset, you

will hear 4 beep tones at 1 minute intervals.

Reset

oIf the WT300 locks up or the unit cannot be powered off

properly, press Reset button located at the back of the device.

The device will be forced to shutdown immediately.

OVERVIEW

WT300 at A Glance

Before using PTT Remote control, please charge it first!

Charging

oPlease use the micro-USB charging cable to connect the

device to a USB port.

oWhile charging, the LED status indicator will show solid red.

oWhen fully charged, the indicator light will go off.

Low Battery Indicator

oWhen the LED indicator blinks red 3 times at 3-second

interval, the PTT remote control needs to be charged.

oYou will also hear 4 beep tones at 1 minute intervals in your

headset if you are connected.

Power On/Off

oIt is not necessary to Power On/Off the PTT remote control.

Connecting to the Bluetooth Adaptor

oPressing the PTT button once will connect the remote control

to the Bluetooth adaptor if the link has not been established.

oThe indicator will blink blue rapidly while busy making a

connection.

oIf the link with the WT300 adaptor is established, the status

indicator will show solid blue when the PTT button is pressed.

Using PTT

oPress and hold PTT button to talk.

Reset

oUpon charging, the device will be reset

Walkie-talkie Cables

Charging Socket

PTT Button

OVERVIEW

PTT Remote Control at A Glance

LED Indicator

Walkie-talkie cables have different audio plug, they can be

identified by the model number imprinted on it.

Model Number

Walkie-talkie

WC-10

Motorola compatible

WC-11

Uniden compatible

WC-12

Motorola compatible

Charging Cables

There are 2 type of charging cable included in the package.

Cable with micro-USB plug is for charging the remote control

whereas mini-USB plug is for the WT300 adaptor.

Stereo Audio Cable

Stereo cable has both terminals molded with 3.5mm stereo plug.

It is needed for music streaming mode operation.

For PTT/iDEN phones, the cable is not included.

3.5mm plug

to WT300

to walkie-talkie

Model num

Mini-USB

Micro-USB

OVERVIEW

Cables

The rubber grip can be used to install the remote control unit on

the motorbike handle bar.

Rubber grip

Remote control PTT

Motorbike handle bar

OVERVIEW

Rubber Grip

If you have a UCLEAR helmet communicator, you can select the

Advanced Communication Mode on your WT300 to enjoy the

special features below:

a) Walkie Talkie Mode

b) Additional way to activate PTT from the UCLEAR

headset

c) Connecting your UCLEAR headset to a cell-phone and

intercom (another UCLEAR headset) at the same time.

Advanced Communication Mode Pairing

Please make sure your UCLEAR headset and WT300 are turned

off. The stereo cable must be unplugged from the adaptor.

Put the UCLEAR headset control unit into pairing mode by

pressing both Answer and Down buttons for 5 seconds.

*This pairing process is not in the HBC100 manual.

With your WT300 in power off mode, press and hold the

Multi-function button for 5 seconds. It will go to pairing

mode with the UCLEAR headset.

The status indicators of both devices will blink blue and red

simultaneously (purple color) during pairing.

Wait till the LED indicators of both devices blink blue lights

slowly upon successful pairing.

It is recommended to restart your WT300 and UCLEAR

headset after the pairing process.

UCLEAR HEADSET [COMMUNICATION MODE]

Pairing
