Uniden WDECT3355 Bedienungsanleitung

WDECT3355

WDECT3355+1

WDECT3355+2

Series Owner’s Manual

OWNER’S MANUAL

[ i ]

•This symbol

indicates important

operating and

servicing instructions.

•The earcap of this

telephone may attract

and retain small

metallic objects.

INSTALLATION & SAFETY

AVOID -

connecting

more than

phones as ringing

may be impaired

AVOID -

multi power boards.

CHARGE -

the new phone

for 15 - 20 hrs.

AVOID -

Moisture

Don’t -

overload the

power outlet.

AVOID -

moisture

AVOID -

Television

sets and other

electronic

appliances AVOID -

Microwave ovens

AVOID -

Computers

AVOID -

other cordless

telephones

Note: Ringing will not be impaired by

adding extra cordless handsets.

For detailed installing method,

please refer Set-Up Guide.

Choosing the best location for your phone.

When choosing a location for your phone there are a number of appliances the

phone should not be near, and areas you should avoid.

CHOOSE -

a central location

[ ii ]

CONTENTS

INSTALLATION & SAFETY i

CONTENTS ii

Controls and Functions 1

Welcome 3

Features 3

Terminology 4

Mounting the Base Unit on a Wall 5

Battery Maintenance 6

Installing the Beltclip 7

Headset Installation 8

Display and Icons 8

About the Menu Options 9

Setting up the Menu 13

BASICS 21

Making and Receiving Calls 21

Keypad Lock 22

Placing a Call on Hold 22

Redialing a Call 23

Adjusting the Handset Ringer,

Earpiece and Speaker Volume 24

Do Not Disturb (DND) 25

Mute Microphone 25

Tone Dialing Switch-Over (Australia Only) 26

Traveling Out-of-Range 26

Clarity Booster 26

Privacy Mode 27

3-way Conferencing 27

Find Handset 28

Flash and Call Waiting 28

New Message LED 28

PHONEBOOK 29

Phonebook 29

Storing Phone Numbers, Names,

Distinctive Rings, and Speed Dial 29

Steps for Entering Names and Special Characters 31

Viewing the Phonebook 33

Making Calls Using the Phonebook 34

Speed Dialing 34

Editing or Erasing a Stored Name,

Phone Number, Distinctive Ring, and Speed Dial 35

Chain Dialing 36

Memory Dialing (Base Only) 36

CALLER ID 37

Caller ID 37

Viewing the Caller ID List 38

Deleting a Caller ID Message 39

Using the Caller ID Message List 40

THE INTEGRATED ANSWERING DEVICE 41

The Integrated Answering Device 41

Turning the Answering System On/Off 42

Setting up your Answering System 43

Using your Answering System 49

Remote Operation 52

EXPANDING YOUR PHONE 55

Expanding your Phone 55

Using Two Way Communication between the

Handsets Anywhere without the Base (DirectLink)57

Room Monitor 57

4-Way Conferencing 58

Intercom/Call Transfer Feature 58

Replacing the Base 59

ADDITIONAL INFORMATION 60

Changing the Digital Security Code 60

Note on Power Sources 61

TROUBLESHOOTING 62

INDEX 65

WARRANTY 68

GETTING STARTED

[ 1 ]

CONTROLS AND FUNCTIONS

Repeat Key

Delete Key Stop Key

Play Key

Skip Key

Select/ Key

1. Handset Antenna

2. Headset Jack Cover

3. Beltclip Hole

4. Hands-Free Speaker

5. Handset Battery Compartment

6. New Message LED

7. Handset Earpiece

8. LCD Display

9. /del Key

10. /vol/ / Key

a. ringer volume control

b. scroll keys for display

screen

11.

tone

Key

12. redial/pause Key

13. speaker Key

14. Key

15. Key

16. Key

17. Key

18. Key

19. phonebook Key

20. /transfer/int’com Key

21. Handset Microphone

22. Handset Charging Contacts

Handset Remote Operation (P. 53)

(Review ITAD messages from handset)

[ 2 ]

49 50

46 47 48

23 24 25 26 27 28 29 30 3231

23. Base Speaker

24. Clock/MENU Key

25. repeat/SELECT Key

26. delete Key

27. Charge LED

28. Message Counter Display

29. In use LED

30. play/stop Key

31. skip/SELECT

Key

32. SET Key

33. Memo record Key

34. Ans on/off Key

35. Greeting Key

36. Mem Key

37. Redial/pause Key

38. Flash Key

39. Base Charging Contacts

40. Intercom Key

41. Mute/find handset Key

42. Hold Key

43. /volume /Key

44. Key/speaker LED

45. Base Antenna

46. Do not disturb Key/DND LED

47.

tone

Key

48. Microphone

49. DC IN 9V Jack

50. TEL LINE Jack

51. Charging Contacts

52. Charge LED

53. DC IN 9V Jack

CHARGER BASE

for +1, +2 models only

Main Base

[ 3 ]

Great features of this cordless phone include:

• Designed and Engineered in Japan

• Wide Band Digital Technology

• Multi (4) Handset Capable

• Digital Duplex Speakerphone on Handset

Advanced Alpha Display Caller ID Features:

• Alpha Memory Dialing

• POP ID - Caller Name Identification*

• 20 Individual Caller Tone Allocation*

• 100 Caller ID * Memories with Phonebook

• 3 Line Backlit Full Dot Matrix LCD Display with Clock

• Maxi-Sound - Extra Loud Handset Volume Control

• Intercom/Announce Call Transfer

• Handset Conferencing (2 Handsets + Outside Call)

• Two-Way Communication between Handsets Anywhere without the Base

• Dual Keypad at Base

• Integrated Answering Device

• DND Feature (Do Not Disturb)

• Remote Message Retrieval

• Personal or Factory Pre-recorded Greeting Message

• And More!

FEATURES

* Caller ID, POP ID and Individual Caller Tone Allocation (Distinctive Ring) features work only if you subscribe

to the service provided by your local telephone company. There is usually a fee for this service.

#Range may vary depending on environmental and/or topographical conditions.

Congratulations on your purchase of the Uniden Multi-Handset Cordless System telephone. This unit is different from

conventional cordless telephones. When the base unit is connected to AC power and a telephone line, it can support up

to 4 handsets. Using extra handsets, you can establish a 3-way conference call (2 handsets and an outside line), while two

other handsets are making an intercom call. You can now place a fully featured cordless handset anywhere in your home

or office where AC power is available to connect the handset chargers.

Note: The illustrations in this manual are intended as a guide and may differ from actual unit.

WELCOME

[ 4 ]

Throughout this manual, terms such as Standby and Talk Mode are used. Below is the terminology

explanation.

Standby Mode - The handset is not in use, is off the cradle, and or speaker, or has not

been pressed. A dial tone is not present.

Talk Mode - The handset is not in the cradle and or speaker, or has been pressed

enabling a dial tone. “Talk” appears on the handset display.

DirectLink - Two way communication between the handsets anywhere without the base.

TERMINOLOGY

[ 5 ]

MOUNTING THE BASE UNIT ON A WALL

3mm

100mm

35mm

You can mount your base directly to the wall. Before doing this, consider the following:

• Avoid electrical cables, pipes, or other items behind the mounting location that could cause a hazard

when inserting screws into the wall.

• Mount your phone within distance of a working phone jack.

• Make sure the wall material is capable of supporting the weight of the base and handset.

• Use screws with anchoring devices suitable for the wall material where the base unit will be placed.

1) Insert two mounting screws into the wall (with their

appropriate anchoring device), 100mm apart. Allow about

3mm between the wall and screwheads for mounting

the phone.

2) Snap the wall mount adapter into the notches on the base

top.

3) Plug the AC adapter into the DC IN 9V jack on the telephone

and then into a Standard AC wall outlet.

4) Plug the telephone cord into the TEL LINE jack on the

telephone and route the cord through the molded wiring

channel. Then plug into the telephone socket on the wall.

5) Raise the antenna to a vertical position.

6) Align the mounting slots on the base with the mounting

posts on the wall.

7) Then push in and down until the phone is firmly seated.

This phone also can be mounted on any standard telephone

wall plate (for Australia).

Attaching wall mount adapter and Routing the telephone cord

[ 6 ]

BATTERY MAINTENANCE

Cleaning the battery charging contacts

To maintain a good charge, it is important to clean the

charging contacts on the handset once a month. Use a dry

cloth or pencil eraser to clean.

Battery use time (per charge)

Fully charged

• Up to 7 hours continuous use

• Up to 10 days when the handset is in the standby mode (up to 15 hours when in DirectLink mode)

Recharge your phone on a regular basis by returning the handset to the charger after each phone call.

Low battery alert

When the batteries are very low and need to be charged, the phone is programmed to eliminate

functions in order to save power.

The batteries need to be charged when:

- The empty battery icon appears.

- “Low Battery” appears in the display.

If the phone is in the standby mode, none of keys will operate. If you are

on a call, complete your conversation as quickly as possible, and return

the handset to the cradle.

Low Battery

[ 7 ]

INSTALLING THE BELTCLIP

To attach the beltclip

Insert the beltclip into the holes on each side of the handset. Press down until

it clicks into place.

To remove the beltclip

Pull either side of the beltclip to release the tabs from the holes.

Battery replacement and handling

When the operating time becomes short, even after a battery is recharged, please replace the

battery. With normal usage, your battery should last about one year. Please contact your place

of purchase or the Uniden Parts Department for a replacement battery.

Caution

• Use only the specified Uniden battery pack (BT-446).

• Do not remove the batteries from the handset to charge them.

• Never throw the battery into a fire, disassemble them, or heat them.

• Do not remove or damage the battery casing.

To avoid the risk of personal injury or property damage from fire or electrical shock, only

use the Uniden battery model and Uniden adapter model specifically designated for this

product.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Uniden Schnurloses Telefon Handbücher

Uniden

Uniden XS 910 Bedienungsanleitung

Uniden

Uniden DECT2185 Bedienungsanleitung

Uniden

Uniden EXP1240 Bedienungsanleitung

Uniden

Uniden EXS 2050 Bedienungsanleitung

Uniden

Uniden EXI5660 - EXI 5660 Cordless Phone Bedienungsanleitung

Uniden

Uniden DECT 1811 Bedienungsanleitung

Uniden

Uniden ANA9620 Bedienungsanleitung

Uniden

Uniden EXa15580 Series Bedienungsanleitung

Uniden

Uniden XDECT SSE05 Bedienungsanleitung

Uniden

Uniden CXAI5698 - Cordless Phone Base Station Service-Handbuch

Uniden

Uniden EXT 176 SERIES guide Bedienungsanleitung

Uniden

Uniden EXI5560 - EXI 5560 Cordless Extension... Benutzerhandbuch

Uniden

Uniden WDECT 2310 Bedienungsanleitung

Uniden

Uniden EZX290 - Cordless Extension Handset Bedienungsanleitung

Uniden

Uniden EXS 9800 Bedienungsanleitung

Uniden

Uniden DCT648-2 Series Bedienungsanleitung

Uniden

Uniden ANA 9320 Bedienungsanleitung

Uniden

Uniden TRU 3455 Bedienungsanleitung

Uniden

Uniden TRU8888 Series Bedienungsanleitung

Uniden

Uniden DECT 3135 Bedienungsanleitung

Uniden

Uniden T R U 346 Bedienungsanleitung

Uniden

Uniden TRU9466 - TRU 9466 Cordless Phone Bedienungsanleitung

Uniden

Uniden CLX 485 Series Bedienungsanleitung

Uniden

Uniden DCT6485 Series Bedienungsanleitung

Beliebte Schnurloses Telefon Handbücher anderer Marken

3Com

3Com NBX Bedienungsanleitung

Panasonic

Panasonic KX-TGK210HK Bedienungsanleitung

Panasonic

Panasonic KX-TCA181EX Bedienungsanleitung

BT FREESTYLE 3200 Bedienungsanleitung

AT&T

AT&T CL84102 Bedienungsanleitung

BREZZICNI

BREZZICNI CL-3622 Bedienungsanleitung

Panasonic

Panasonic KX-TG1831NZ Bedienungsanleitung

Panasonic

Panasonic KX-TG7301E Bedienungsanleitung

Furuno

Furuno FM-4721 Bedienungsanleitung

Sanyo

Sanyo CLT-J70 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 201 Bedienungsanleitung

GE 26992 Bedienungsanleitung

AT&T

AT&T E1812B Bedienungsanleitung

Sanyo

Sanyo CLT-670 Bedienungsanleitung

GE 15432970 Bedienungsanleitung

Curtis

Curtis TC595 Bedienungsanleitung

Gigaset

Gigaset Gigaset 3000 Micro Bedienungsanleitung

Poly

Poly VVX D230 Einrichtungshandbuch
