Uniden FP099 Bedienungsanleitung

MANUAL

OWNERS

FP099

LCD Display

Caller ID

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Included in your package. . . . . . . . . . . . . . . . . . . . . . . . . . .

Location and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setup

Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Connecting Line Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Setting Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

LDS Code Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Telephone Key Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Display Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Receiving Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Caller ID Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CONTENTS

When using your telephone equipment, these basic safety precautions

should always be followed to reduced the risk of fire, electrical shock,

and injury:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Use a damp (not

wet) cloth. Never use abrasive or strong cleaners or solvents.

4. Do not use this product near water; for example, near a bathtub, shower,

washbowl, kitchen sink or laundry tub, in a wet basement or near a

swimming pool.

5. Do not place this product on an unstable stand or table. The telephone

may fall, causing serious damage to the unit.

6. Never spill liquid of any kind on the product.

7. Do not disassemble this product. Take it to qualified service personnel when service

or repair work is required. Opening or removing covers may expose you to dangerous

voltages or other risks. Incorrect reassembly can cause electric shock when the appliance

is subsequently used.

8. Unplug this product from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

A. If liquid has been spilled into the product.

B. If the product has been exposed to rain or water.

C. If the product does not operate normally when following the operating

instructions.

IMPORTANT SAFETY INSTRUCTIONS

Features

Caller display

80 memory caller display

Out of area / Private / Repeat indicator

NEW CALL light

Battery Low indicator

Last number redial

Last 5 numbers redial

FLASH button

Message waiting icon (New Zealand Only)

Visual ringer

Mute button

Timer

Included in your package

1 - Handset with curly cord and phone base

1 - Telephone line cord

4 - AAA size 1.5V batteries

1 - Owner's manual

INTRODUCTION

1 - Wall mounting bracket

To get the most from your

phone, please read the

Owner’s Manual thoroughly.

Be sure to complete and mail

the product registration form.

LOCATION OF CONTROLS

This unit is not waterproof.

Do not expose this product

to rain, water, moisture or

any other liquid.

NOTE

pause

ÅTER

45 6

mno

78 9

abc def

ghi jkl

pqrs tuv wxyz

mute flash

redial

TOTAL CALLS 10

9:52 12/30

AM NEW 02

LOW

new

call

dn review up

call back

del

1. mute button

2. redial button

3. pause button

4. flash button

5. del button

6. call back button

7. new call button

8. review up button

9. review dn button

10. Visual ringer

ring

Australian Customers:

Setting the LDS code is not

required.

SETUP

NOTE

1.While holding down the del button, press the review dn button once.

2.Use review up or dn buttontoselectthecorrectnumber - HH : MM MM / DD

3.Press call back buttontoconfirmandmovetothenextdigit.

4.Press del buttonto store and exit.

Setting Time and Date

With handset in cradle follow these steps:

NOTE

If you have subscribed to the

Caller ID service, the Time

and Date will automatically

be set when you receive a

call.

NOTE

Match the + / - symbols in

the battery compartment

with each battery.

Battery Installation

Connecting Line Cords

The Caller ID phone requires four 1.5V AAA size batteries for the LCD

display to operate.

1. Remove the screw and open the battery compartment under the base.

2.Insertfour1.5VAAAsizebatteries.

3. Position the batteries in the compartment and replace the

batterycompartmentcover.

Plug one end of the supplied modular cord into the telephone line wall jack. Then

plugtheotherendinto the telephonelinejack located under the base.

Digit Insert Caller ID (LDS Code)

To correctly display and dial Call ID numbers, you may need to insert a digit at the

beginning of your telephone number. (eg: in New Zealand, Telecom requires a ‘0’ to be

inserted.)

New Zealand:

If you subscribe to Telecom New Zealand, this code has already been set for you to ‘0’.

If you subscribe to another telephone company, please set the LDS code as blank ‘ ’.

If this phone is used with a business PABX - consult the PABX manufacturer for the

correct setting.

Australia:

For private household telephone lines, it is not necessary to set this code.

If this phone is used with a business PABX - consult the PABX manufacturer for the

correct setting.

8:06 2/27

SET TIME

(hours : minutes) (month/day)

1. While holding down the del button, press the review up button once.

2. Press review up or dn to select the correct number to be inserted, press

call back to set the next digit, then press del to store and exit.

8:06 2/27

SET LDS CODE

TELEPHONE KEY FUNCTION

Ringer Select Switch

If you do not wish the phone’s ringer to interrupt you, move the Ringer Selector Switch

(located under the base) to OFF.

Regular dialling

Lift the handset and listen for dial tone. Then enter the telephone number you wish to

call. The dialled number will appear on the LCD screen whenever you make a call.

Redial function

To redial the previous number you called. Lift the handset and press the redial button.

Pause function

To insert a temporary pause. press the pause button during a dialling sequence. For

example, in some cases when dialling an international number you need to place a pause

between the clusters of numbers to allow the telephone company, relaying the call, time

to process it. The number 011-886-22-795-1234 would need to be dialled 011 (pause) 886

(pause) 22 (pause) 795 (pause) 12345.

Mute button

For privacy when you are required to consult with a person standing next to you and do

not wish the party on the line to hear your conversation, press and hold the mute button.

The call resumes on releasing the button.

Flash button - Call Waiting

If the call Waiting tone sounds while you are on a call -

New Zealand: Press the flash button to switch between callers.

Australia: Press flash then 2to switch between callers.

For ‘Call Waiting’ to operate

you must subscribe to this

service through your local

telephone company.

If you do not have this

service, then pressing the

flashing button during a call

may disconnect the caller.

NOTE

Message Waiting (New Zealand Only) MSG

If you have arranged a voice mail service with your telephone

company, the LCD screen will display MESSAGE WAITING

for a few seconds after a call is received. The screen will then

display MSG in the upper left corner until you retrieve the

message from the voice mail service.

Total & New Calls

This displays the total calls received and which of those are

new calls. This example shows 10 calls which include 2

new calls.

No Calls

When all calls have been deleted the screen will display NO

CALL.

Private

If a caller has exercised the option which prevents the caller’s

name and number from being sent, the screen will display

PRIVATE.

MSG

TOTAL CALLS 10

9:52 30/12

AM NEW 02

NO CALL

PRIVATE

Repeat Calls

If a call is received repeatedly, REPEAT will be displayed

in the top right of the LCD screen.

End of List

This is displayed when you use the review up or dn and

have reached the top end of the call history list. If there are

no calls in the list the LCD screen displays NO CALL.

Out of Area

This will be displayed when the caller’s telephone company

does not provide caller ID services or does not provide name

and number services via the long distance network.

09 273 8383

REPEAT

END OF LIST

9:52 30/12

OUT OF AREA

Battery Low Indicator

This icon is displayed when the batteries require replacing.

LOW

TOTAL CALLS 10

9:52 30/12

AM NEW 02

LOW

DISPLAY MESSAGES

For LCD messages to operate,

you must first subscribe to the

caller ID service through your

local telephone company.

A caller ID record consists of the following information:

Number of call records received

Time and Date of the call

TOTAL CALLS 04

9:52 30/12

AM CALL# 02

9:52 30/12

AM CALL# 02

122-7461-2345

Caller's name (if available)

Caller's number

Total calls

RECEIVING CALL RECORDS

The LCD display will not

operate if the batteries are flat

or not installed.

New Call Indicator

The red indicator light of your phone will flash when you have New Calls. It will continue

to flash until you have reviewed the calls displayed on the LCD screen.

Review Call Records

Use the review up or dn buttons to scroll through the caller list. At the end of the call

record list, END OF LIST will be displayed.

Call Records

Your phone stores up to 80 Call records. When the list is full a new incoming call will

automatically delete the oldest call record.

Using the CALL BACK feature

You can automatically dial the number of a person who has recently called.

1) Lift the handset and listen for dial tone.

2) Select the caller that you wish to call back by pressing the review up or dn button.

3) Press call back to automatically dial the number of the person displayed in the LCD

screen.

Last 5 Numbers Redial

1) With the handset on the cradle, press the callback button once..

2) Use the review up or dn buttons to select one of the last 5 numbers you have dialled.

3) Pick up the handset and press callback, the number you have chosenwill automatically

be dialled.

Del button - for deleting Caller ID records

To delete numbers from your Caller ID number memory.

With the handset in its cradle, press review up or dn buttons to select the number you

wish to delete. Now press the del button. The LCD screen will show DEL?. To confirm

the number chosen is to be deleted, press del again. The number will be deleted.

Timer

During a call, press the del button to start and stop the timer.

For call ID features to

operate you must first

subscribe to this service

throughyourlocal telephone

company.

CALLER ID OPERATION

TROUBLESHOOTING

Blank or faint screen

Check the line cord.

Connect telephone cord.

Replace batteries.

Caller ID will not work properly

Call your telephone company to verify that your caller ID service is active.

Phone will not ring

You may have too many communication devices connected to a single line. A

communication device can be a phone, a modem or fax machine. Disconnect some

devices.

No dial tone

Verify that you are using the correct line cord and that it is plugged in correctly.

No data sent

If you have an answering machine or fax connected to this phone, ensure it is set to

answer after at least two rings.

You have answered the call before two rings.

Contact your telephone company if the problem continues for more than 24 hours.

The telephone company may be experiencing a temporary line fault.

No response on LCD display

If you have experienced a power failure when using the optional AC adaptor, the batteries

for memory backup may have become weak or dead. If the power is restored and the

display screen does not respond then you need to replace the batteries.

Please refer to our website for further information and frequently asked questions.

New Zealand -

www.uniden.co.nz

Australia -

www.uniden.com.au

Inhaltsverzeichnis

Andere Uniden Telefon Handbücher

Uniden

Uniden 1100 Series Bedienungsanleitung

Uniden

Uniden DS 825 Bedienungsanleitung

Uniden

Uniden 1100 Bedienungsanleitung

Uniden

Uniden EXP7241 Series Bedienungsanleitung

Uniden

Uniden XDECT SSE37 Series Bedienungsanleitung

Uniden

Uniden 1035 Series Bedienungsanleitung

Uniden

Uniden EXA2245 Bedienungsanleitung

Uniden

Uniden SSE34 Series Bedienungsanleitung

Uniden

Uniden DXI5586-3 Series Bedienungsanleitung

Uniden

Uniden DXAI4588-2 Bedienungsanleitung

Uniden

Uniden DECT 2145 Series Bedienungsanleitung

Uniden

Uniden 1360BK Service-Handbuch

Uniden

Uniden FP104 Bedienungsanleitung

Uniden

Uniden DECT 2005 Series Bedienungsanleitung

Uniden

Uniden D3288-2 Bedienungsanleitung

Uniden

Uniden DXAI5588-3 Series Bedienungsanleitung

Uniden

Uniden TRU9488 - TRU 9488 Cordless Phone Base... Service-Handbuch

Uniden

Uniden XDECT 6145BT Series Bedienungsanleitung

Uniden

Uniden DECT 6015 Bedienungsanleitung

Uniden

Uniden D3288 Bedienungsanleitung

Uniden

Uniden EXA2245 Bedienungsanleitung

Uniden

Uniden DECT 3015 Bedienungsanleitung

Uniden

Uniden D3098S Bedienungsanleitung

Uniden

Uniden D2998 Bedienungsanleitung

Beliebte Telefon Handbücher anderer Marken

GE 2-9480 Bedienungsanleitung

Geemarc

Geemarc PHOTOPHONE 155 Bedienungsanleitung

D-Link

D-Link DWR-720/PW Bedienungsanleitung

Interquartz

Interquartz Gemini IQ333 Bedienungsanleitung

SSS Siedle

SSS Siedle HT 840-0 Bedienungsanleitung

Motorola

Motorola TITANIUM Bedienungsanleitung

Panasonic

Panasonic ICX Bedienungsanleitung

LG H870DS Bedienungsanleitung

Samsung

Samsung GT-I9500 Bedienungsanleitung

AT&T

AT&T Trimline 205 Bedienungsanleitung

Selta

Selta zenyth 600 Bedienungsanleitung

Doro

Doro AFTI 20 Bedienungsanleitung

UNIQCELL

UNIQCELL A1 Bedienungsanleitung

Panasonic

Panasonic KX Series Bedienungsanleitung

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Bedienungsanleitung

BT Decor 425 Bedienungsanleitung

NEC

NEC SV8500 Bedienungsanleitung

Teledex

Teledex PEARL Bedienungsanleitung
