Unimom FORTE Bedienungsanleitung

For a period of 1 year from the date of original purchase, Blue Egg warrants this product

(excluding kit) against defects in material or workmanship. At Blue Egg's option, Blue

Egg may repair or replace that is determined to be defective buy Blue Egg and

determined to be covered by this warranty.

For warranty service, please return the product, along with dated sales receipt or other

proof of the purchase date, to Blue Egg or Local distributor.

This warranty does not cover damage caused by accident, misuse, abuse, improper

maintenance, unauthorized modification, or connection to an improper power supply. A

charge will be made for repair of such damage.

This warranty excludes all incidental or consequential damages and any liability other

than what is stated above. Blue Egg makes no other warranties regarding this product

(including warranties as to merchantability and fitness for a particular purpose) either

express or implied.

LIMITED WARRANTY

Specifications

WARNING Intended use

Overview

Pumping guide

①ALWAYS UNPLUG THIS DEVICE IMMEDIATELY AFTER USING.

②DO NOT USE WHILE BATHING.

③DO NOT PLACE OR STORE THIS DEVICE WHERE IT CAN FALL OR BE PULLED INTO A

TUB OR SINK

④DO NOT PLACE IN OR DROP INTO WATER OR ANY OTHER LIQUID

⑤DO NOT REACH FOR A DEVICE THAT HAS FALLEN INTO WATER UNPLUG THE DEVICE

IMMEDIATELY.

READ ALL INSTRUCTIONS BEFORE USING

When using electrical products, basic safety precautions should always be followed.

DANGER : To reduce the risk of electrocution

1. Relax and stimulate your let-down reflex.

2. Gently massage your breasts or apply warm compresses from the back of the breast

toward the nipple before using.

3. Express milk from each breast for 10 ~ 15 minutes and it is good to alternate breasts.

It is more effective and better for the breasts when you pump frequently than

pumping for a long time. (Every 2 ~3 hours, 8 times a day)

NOTE : EVEN WHEN YOU ARE USING THE BREAST PUMP, BREASTFEED YOUR BABY.

1. Relieving engorgement

2. Expressing breastmilk while away from your baby

How to use

1. Assemble the kit followed by How to assemble.

2. Start with low vacuum.

3. Set the nipple in the center of the breast shield A and plug into the outlet.

4. Turn the unit on.

5. Adjust the vacuum properly by vacuum control knob.

6. Turn the unit off after use.

NOTE : CLEAN YOUR HANDS AND SANITIZE THE KIT IN BOILING WATER FOR 2-3

MINUTES EXCEPT THE AIR TUBE BEFORE USING THE BREAST PUMP.

WARNING : USE THE BREAST PUMP AFTER CONSULTING A DOCTOR IN CASE

OF HAVING HEART TROUBLE.

①THIS DEVICE SHOULD NEVER BE LEFT UNATTENDED WHEN PLUGGED IN.

②

CLOSE SUPERVISION IN NECESSARY WHEN THIS DEVICE IS USED NEAR INFANTS OR CHILDREN.

③USE UNIMOM ACCESSORIES ONLY.

④USE THIS DEVICE ONLY FOR ITS INTENDED USE AS DESCRIBED IN THIS

INSTRUCTIONS FOR USE.

⑤NEVER OPERATE THIS DEVICE IF IT HAS A DAMAGED CORD OR PLUG, IF IT IS NOT

WORKING PROPERLY, IF IT HAS BEEN DROPPED OR DAMAGED, DROPPED INTO

WATER, OR IF ANY PARTS ARE BROKEN OR MISSING.

⑥KEEP THE DEVICE AWAY FROM HEATED SURFACES.

⑦NEVER USE WHILE SLEEPING OR DROWSY.

⑧

THE POWER CORD SHOULD BE UNPLUGGED FROM THE OUTLET WHEN NOT IN USE.

⑨DO NOT DISASSEMBLE OR REMODEL THE DEVICE.

⑩DO NOT USE WHERE AEROSOL SPARAY PRODUCTS ARE BEING USED OR WHERE

OXYGEN IS BEING ADMINISTERED.

WARNING : To reduce the risk of burns, electrocution, fire, or injury to persons

Manufacturer : Blue Egg Co.

216-5, Yongmoon-Dong, Seo-Ku, Daejon, Korea

Tel : +82-42-532-9226 Fax : +82-42-533-9225

Weight : 1.5kg Fuse : 3.15AL250VP

MADE IN KOREA

①

②

③

④

⑤

⑥

WARNING : DO NOT CURL THE AIR TUBE.

DO NOT OVERFILL THE BOTTLE MORE THAN 4OZ. LEVEL.

Voltage

Rated current

Remark

Frequency

100V~

110V~

120V~

220V~

230V~

240V~

50/60Hz

60Hz

50/60Hz

0.9/0.65A

0.5/0.40A

0.63A

0.42/0.33A

0.25/0.20A

0.24/0.18A

: Type B

: Class II Dispose of through separate collection

route for waste electrical equipment

①

Handle

②

Vacuum control knob

③

Single connector

④

Fuse holder

⑤

Power cord

⑥

Switch

:ON :OFF

Cleaning and sterilization

Components

Trouble shooting

How to thaw

How to assemble

How to store breast milk

1. Place frozen milk in the refrigerator for several hours before use.

2. Before feeding, hold milk under warm running water until the milk is room

temperature.

3. Shake it well when the milk fat may separate.

How to transport and store

Clean all parts thoroughly and wipe main body with a clean damp cloth after each use.

NOTE : WHEN UNIT IS NOT TO BE USED FOR AN EXTENDED PERIOD, STORE CAREFULLY

IN A COOL, DRY PLACE.

NOTE : COOL BREAST MILK IN THE REFRIGERATOR FOR TWO HOURS BEFORE

FREEZING.

WARNING : LABEL REFRIGERATED BREAST MILK WITH THE DATE AND TIME

THE MILK WAS EXPRESSED. DO NOT MIX FRESH MILK WITH REFRIGERATED

MILK.

WARNING : DO NOT THAW FROZEN MILK IN MICROWAVE OVEN.

DO NOT REFREEZE MILK ONCE IT HAS BEEN DEFROSTED.

Room temperature

Refrigerator

Freezer

It’s best if you can directly feed your baby, If you can’t, the storage would be better.

Up to 3 hours

Up to 1 day

Up to 3 months

DO NOT

STORE MILK

IN HOT WEATHER.

Condition

Checks Solutions

Possible

Causes

NOTE : WHEN THE MAIN BODY PRODUCES AN ABNOMAL NOISE OR WHEN THE

BREASTMILK IS OVERFLOWN INTO THE MAIN BODY, CONTACT THE

LOCATION WHERE YOU PURCHASED THE PRODUCT OR THE

MANUFACTURER. WHEN THE BREASTMILK IS OVERFLOWN ONLY TO THE

AIR TUBE, REMOVE IT FROM THE MAIN BODY AND CLEAN IT.

Low

suction

Pain

suction

Fuse

Switch

Air tube

Valve head

Membrane

Defective

assembly

Breast

shield

Check if the fuse has

become disconnected

Check if the switch is

turned on.

Check if the air tube is

connected to the main body

Check if they are

assembled to the breast

shield properly

Check the connection of

the kit.

Check if there is a problem

with the breast shield.

See how to assemble and

connect the air tube properly

Disassemble and reassemble

them properly.

Disassemble and reassemble

them.

Purchase and replace the

breast shield.

Membrane

Too high

suction

Check if there is space

between valve head and

membrane.

Check the suction level Start with low vacuum

Consult your lactation

consultant or physician.

Remove any foreign

substances

Replace the correct fuse

followed by specification.

Power cord Check if the power cord

is plugged Plug into the outlet

If the pump does not function

when the switch is turned on,

please contact the location

where you purchased the

product or the manufacturer.

1. Single pumping

2. Double pumping

1. Fit the membrane L into the

valve head K.

3. Screw the bottle B into the

breast shield assembly.

2. Push the valve head

assembly into the bottom

of the breast shield A.

4. Hold the bottle assembly

into the bottle stand F.

Follow the above until 5

6. Connect the other end of

the air tube G to the single

connector D

5. Connect one end of the air

tube G to the breast

shield assembly.

1. Remove valve head and membrane from the breast shield.

2. Clean and sterilize it in boiling water for 2~3 minutes.

3. Pull out the air tube carefully and clean it with washing agent.

4. Clean it at least once a week, but when breast milk gets inside, clean immediately.

NOTE : TO ELIMINATE CONDENSATION OR MILK IN THE AIR TUBE, WASH AND DRY IT

IMMEDIATELY. TO CLEAN MAIN BODY, WIPE MAIN BODY WITH A CLEAN

DAMP CLOTH.

WARNING : NEVER IMMERSE MAIN BODY IN WATER.

DO NOT SANITIZE THE KIT IN MICROVAVE OVEN.

6. Connect the

double

connector M to

the single

connector D.

7. Connect the

other end of the

air tube G to the

double

connector M.

3 4

5 6

Breast shield 2EA

Bottle 2EA

Bottle cover 2EA

Single connector 1EA

Main body 1EA

Bottle stand 2EA

Air tube 2EA

Cap 2EA

Disk 2EA

Nipple 2EA

Valve head 2EA

Membrane 2EA

Double connector 1EA

Accessory name Accessory name

Kit : A + B + C + G + H + I + J + K + L

Symbols

: Date of

manufacture

: Serial number

: Alternating

current

: ON

: OFF

Disposal

Use your local collection and return systems for old electronic equipment. If old

electronic equipment is not disposed of correctly, this can have harmful effects on the

environment and on public health.
