FAN HEATER

MODEL: UHF-847

USER INSTRUCTIONS

WARNING

While using any electrical appliance specific

precautions must be followed. Read the

instructions carefully and keep them for further

reference

This product is only suitable for well insulated

spaces or occasional use.

IMPORTANT SAFEGUARDS

When using any electrical appliance basic

precautions should be followed. Please read the

following instructions as they are for your benefit

and safety:

1. Make sure the power supply used corresponds to

the rating label.

2. Never obstruct or block any openings of the

heater.

3. Use the heater only on a flat surface.

4. Always disconnect the appliance from the main

power supply when not in use and when

cleaning.

5. Do not leave the heater “ON” unattended.

6. Never cover the heater as this may lead to risk of

fire.

7. Keep the appliance a distance of at least 90 cm

from any combustible material such as furniture,

curtains, bedding, clothes or papers.

8. Do not use this heater in the immediate

surrounding of a bath, a shower or a swimming

pool.

9. Do not immerse the heater in water or allow for

water to come into contact with the plug or

control device.

10. Keep this heater clean. Do not allow objects to

enter the ventilation opening as this may cause

electric shock, fire of damage to the heater.

11. Close supervision is require when any

appliance is used near or by children.

12. Never allow the cord to touch wet or hot

surfaces, become twisted or be within the reach

of children.

13. Do not use outdoors

14. Do not place on or near a hot gas electric

burner.

15. If the supply cord is damaged, it must be

replaced the manufacture or its service agent or a

similarly qualified person must replace it in

order to avoid a hazard.

16. Do not use the appliance for other than its

intended use as described in this instruction

book.

17. Do not place the heater immediately below a

socket outlet.

18. This appliance is intended for household use

only.

19. Do not leave the heater on overnight.

20. While cleaning, make sure not to use a wet

cloth or use water on any part of the unit, as this

may cause a short circuit or electrical shock.

21. Do not use this unit in any area where water

present.

22. Make sure the power cord is placed at the

back away from the front panel of the heater.

23. This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have

been given supervision or instruction concerning

use of the appliance by a person responsible for

their safety.

24. Children should be supervised to ensure that

they do not play with the appliance.

25. Caution: Do not cover anything on your heater

when in use.

26. The fan-heater must not be placed near a

socket and the following hint: This fan-heater

must not be used near a bath, shower or

swimming-pool

27. Children of less than 3 years should be kept

away unless continuously supervised. Children

aged from 3 years and less than 8 years shall

only switch on/off the appliance provided that it

has been placed or installed in its intended

normal operating position and they have been

given supervision or instruction concerning use

of the appliance in a safe way and understand the

hazards involved. Children aged from 3 years

and less than 8 years shall not plug in, regulate

and clean the appliance or perform user

maintenance.

28.

NOTE: Should the unit overheat, this heater is

fitted with a safety with overheating device which

will switch the off automatically. (If the air vent is

blocked or if the fan function is not blowing air). If

this should happen, all you need to do this:

Disconnect the plug from the electrical socket for a

few minutes. Ensure the heater is not covered and

nothing is obstructing any of the vents. Plug the

heater back into the electrical socket and switch the

heater back ON.

HOW TO OPERATE

1. Remove the unit from the box and take off any protective wrapping.

2. Place the heater on a smooth level surface and least 30cm away from any obstacles.

3. Plug your fan heater into the power supply. Make sure your power supply corresponds to

the power indicated on the rating label.

4. Turn the thermostat knob (right) in a clockwise direction until it reaches the maximum

setting.

- Summer service (ventilation only): turn the knob to setting

- Heating at reduced power: turn the knob (right) to setting I (1000W).

- Heating at full power: turn the (right) to setting II (2000W).

- Switching off: turn the knob (left) to setting O

- To use the oscillation function press the button on the base of the unit. The appliance will

start rotating left and right.

5. When the room has reached the required temperature turn the right thermostat knob (where

included). In an anti-clockwise direction up to the point where the appliance switches off and

not beyond. The temperature fixed in this way will be automatically regulated and kept at a

constant level by the thermostat.

OVERHEATING SAFETY DEVICE

Your heater is fitted with a safety device that switches off the heater in the event of

overheating.

Should the heater stop working, turn the heater off and inspect of blockage of inlet or outlet.

Wait at least 5 minutes of the protection system to reset before attempting to restart the heater.

If the heater fails to operate the safety device switches the heater off again, return the heater to

your nearest service center for examination or repair.

CLEANINGYOUR FAN HEATER

1. Always disconnect the appliance from the main supply before cleaning.

2. Clean the outside of the heater by wiping with damp cloth and guff with a dry cloth.

3. Do not use Benzine or any other detergents/solvents or chemical agents to clean the

heater.

SERVICE

Hints before returning the appliance:

Is your household socket working properly?

Are all required switches in the “ON” position?

Ensure that the plug is firmly in the socket and switched on.

Ensure the heater if standing on an even surface.

NOTE: If the power supply cord, or plug is damaged, an Amalgamated Appliance service

center or an official agent must replace it.

If service becomes necessary with the warranty period the appliance should be returned to an

approved service center. Servicing outside the warranty period is still available, however it

will be chargeable.

Model

identifier(s):

UHF-847

Item

Symbol

Value

Unit

Heat output

Nominal heat out-put

Pnom

1.8-2

Minimum heat output

(indicative)

Pmin

0.015

Maximum continuous heat

output

Pmax,c

Auxiliary electricity consumption

At nominal heatoutput

elmax

At minimum heatoutput

elmin

In standby mode

elSB

Type of heat input, for electric storage local space heaters only (single select)

manual heat charge control, with integrated thermostat

Yes No

manual heat charge control with room and/or outdoor temperature feedback

Yes No

electronic heat charge control with room and/or outdoor temperature feedback

Yes No

fan assisted heat output

Yes No

Type of heat output/room temperature control (single select)

single stage heat output and no room temperature control

Yes No

Two or more manual stages, no room temperature control

Yes No

with mechanic thermostat room temperature control

Yes No

with electronic room temperature control

Yes No

electronic room temperature control plus day timer

Yes No

electronic room temperature control plus week timer

Yes No

Other control options (multiple selections possible)

room temperature control, with presence detection

Yes No

room temperature control, with open window detection

Yes No

with distance control option

Yes No

with adaptive start control

Yes No

with working time limitation

Yes No

with black bulb sensor

Yes No

Contact details

Kalliopi Karyda & CO LP

87A, 17is Noemvriou str, P.C. 55535

Pylea, Greece

T: +302316006600, F: +302316006650

NOTICE ABOUT RECYCLING

Your product is designed and manufactured with high quality materials and

components which can be recycled and reused.

This symbol means that electrical and electronic equipment, at their

end-of-life,

should be disposed of separately from your household waste. Please dispose

of this equipment at your local community waste collection/ recycling centre.

In the European Union there are separate collection systems for used electrical and electronic

products.

Please help us to conserve the environment we live in!

DECLARATION OF CONFORMITY

Herewith, Kalliopi Karyda & Co, LP. states that this product, complies with the requirements

of below directives:

EMC-Directive: 14 / 30 / EU

Low Voltage Directive: 14/ 35 / EU

ErP Directive 09 / 125 / EC

CE Marking Directive: 93 / 68 / EEC

RoHS Delegated Directive 15/863/EU

The detailed declaration of conformity can be found at www.united-electronics.gr

Exclusive importer in Greece:

Kalliopi Karyda & Co LP.

87A, 17is Noemvriou str, P.C. 55535

Thessaloniki – Greece

T: +302316006600 | F: +302316006650

www.united-electronics.gr
