17.0” Panel Mount PC

Model VTPC170P / PSS

User’s Guide

Read these instructions completely before attempting to operate your new Panel Mount PC

Revision History

Date Rev No Summary Page

8/11/08 00 First Issue

10/07/08 01 Revised panel mounting drawing 6

12/08/08 02 Identify ports on bottom panel view 7

17.0 Panel Mount PC 486-0003-01-01

Safety Instructions

•Read the Safety Instructions carefully and keep it for use later.

•The chassis metalwork of the module must be installed properly to the main earthing termination

for Class 1 equipment.

•Care must be exercised in the application of the system to prevent overheating. Ensure that the

ambient temperature around the system does not exceed 60°C and provide adequate means of

ventilation to achieve this.

•When cleaning cut off the electrical supply at all times. Never use liquid or aerosol detergent,

use a soft damp cloth instead.

•Never insert anything metallic into the chassis openings. This may create an electric shock

hazard or hazard from rotating fan blades.

•To avoid electric shock, never touch the inside of the system. There are no user adjustable

components inside, only a qualified technician should open the system’s case.

•Openings in the system enclosure are to allow for ventilation. To prevent overheating, these

openings should not be blocked or covered.

•If the system does not operate normally – in particular, if there are any unusual sounds or smells

coming from it – disconnect it immediately.

•Do not put pressure on the LCD panel screen because it is very fragile.

•Always handle the system with care when moving it.

•Take care that the system is disposed of correctly at the end of its life. If in doubt refer to your

local ordinances or regulations for proper disposal.

Cleaning the LCD monitor

To clean the LCD panel:

•Wipe the screen gently with a clean lens brush made of camel hair, or a soft, clean, lint free

cloth. This is to remove dust and other particles without scratching the LCD panel.

•If it is still not clean, then wipe with a damp lint free cloth and blow on it to dry.

Do not clean the panel with a keton-type material (e.g. acetone), or ethyl toluene, ethyl acid, methyl

or chloride. These may damage the LCD panel.

Do not apply pressure to the LCD panel.

17.0 Panel Mount PC 486-0003-01-01

Standard Technical Specifications:

LCD Monitor:

Size / Type 17.0” XGA TFT LCD

Native Resolution 1280 x 1024

Contrast Ratio 800:1

Viewing Angles Horizontal: 160°

Vertical: 160°

Pixel Pitch 0.264mm

Brightness (typical) 300 cd/m²

Response Time (typical) 5ms

Colors Supported 16.7 million

Computer System:

Processor 1.73GHz Intel T5300 Core 2 Duo Processor

System Memory DDR2 533 DIMM 2 GB x 1 (expandable to 4GB)

BIOS AMI BIOS

Hard Drive 120 GB SATA

Operating System Microsoft Windows XP Professional (SP3)

Expansion Slots PCI x 1 (Optional)

Mini PCI x 1

Back Panel I/O Ports PS/2 Keyboard Connector x 1

PS/2 Mouse Connector x 1

AC Power Inlet x 1 (IEC320)

RS-232 Port x 2 (x1 422/485 Optional)

USB 2.0 Port x 6 (x4 on Stainless Steel Models)

RJ45 LAN Port x 2

VGA Port x 1

DVI-D Port x 1

Audio Jacks: Line Out x 1 / Line In x 1

Graphics Integrated Intel 945GME Graphics

LAN Broadcom BCM5787M PCIe GbE controllers

DVD Drive (E-IDE / ATAPI) DVD-R, DVD+R, DVD-RW, DVD+RW, DVD-R DL, DVD+R9 CD-R,

CD-RW,

Touch Screen Resistive

Touch Screen Interface USB

17.0 Panel Mount PC 486-0003-01-01

Power Input 100 - 240 VAC 1.5A 50/60 Hz

12 - 24 VDC (Optional)

6 – 32 VDC without DVD (Optional)

Power Consumption 51W

Temperature Operational: 32°F to 140°F 0°C to 60°C

Storage: -4°F to 149°F -20°C to 65°C

Humidity Operational: 20 to 40°C, 90% RH NC

Storage: 5 to 65°C, 28% RH NC

Installation of Your Panel PC

Packaged with each carton will be:

1 - VTPC170P / PSS

1 - AC Power Cable

1 - #10-32 Mounting Hardware

1 - Users Guide (Printed or on CD)

BEFORE MAKING ANY CONNECTIONS OR APPLYING POWER,

FIRST READ THROUGH THE ENTIRE MANUAL

Panel Mount Procedure

17.0 Panel Mount PC 486-0003-01-01

Panel Mounting Procedure:

1- Cut and drill the panel (refer to the panel mount drawing, Figure A). Measurements are

provided in inches and millimeters.

Panel Mounting Cutout:

1- If access to the bottom of the enclosure is not available following installation, attach the

power and all necessary cables to the bottom side of the enclosure at this time.

2- Install the enclosure in the prepared cutout.

3- Secure the enclosure using the lock nuts and washers, supplied with the unit, behind the

holes running along the sides and the top and bottom of the cutout in the panel. Extra lock

nuts and washers are provided.

NOTE: Use #10-32 nuts for mounting.

4- Tighten all mounting hardware to a torque of 24 inch-pounds.

ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide a

proper panel seal and avoid potential damage. Vartech Systems assumes no responsibility for

water or chemical damage to the monitor or other equipment within the enclosure due to

improper installation.

5- Attach the power, video and system cables to the bottom side of the enclosure if you have

not already done so.

Panel Mount Drawing: Detail –A–

17.0 Panel Mount PC 486-0003-01-01

Connections to the Panel Mount PC

Bottom Rear View

-Connector Panel-

Power Connection (Power In)

The Panel Mount PC includes an AC line cord which is 6ft long. The power input receptacle is

located on the bottom rear panel of the system.

Serial Connections (COM 1-2)

The Panel Mount PC is supplied with two serial connectors configured for RS-232. The

connector is a 9 pin female connectors and can be set up for any baud rate from 300 to 19.2

baud. The connector is located on the bottom rear panel of the system.

Ethernet Connections (LAN 1-2)

The Panel Mount PC is supplied with two integrated Ethernet connectors. The interface will

support 10/100/1000 BaseT connection to a local area network (LAN). The Panel Mount PC is

supplied with two RJ-45 female connectors located on the bottom rear panel of the system.

USB Connections (USB 1-4)

The Panel Mount PC is supplied with four USB 2.0 connectors located on the bottom rear panel

of the system.

VGA Port

The 15-pin female VGA connector can be used to connect to any analog VGA monitor.

DVI Port

DVI 1.0 support for external digital monitor.

17.0 Panel Mount PC 486-0003-01-01

Turning the system On and Off

Before connecting the Panel Mount PC to power, connect any peripheral devices. As a general

rule, any peripheral device should only be connected or disconnected when the Panel Mount PC

is off with the exception of any USB or 1394 peripheral.

The Panel Mount PC is turned on using the main On-Off rocker switch located on the bottom

rear panel. Once the Panel Mount PC main switch is turned on the computer power pushbutton

switch must be depressed for Windows to start. Windows must be properly shut down before

the main power switch is turned off to prevent the chance of corrupting files in the operating

system.

The Panel Mount PC is rated for continuous duty. However, to extend the life of the various

components and conserve power, it is highly recommended that the system be properly shut

down and power turned off when the Panel Mount PC is not in use.

LCD Monitor Warm-up Time

All LCD monitors need time to become thermally stable the first time you turn them on.

Therefore, to achieve more accurate adjustments for parameters, allow the LCD monitor to

warm (be on) for at least 20 minutes before making any screen adjustments.

Maintenance

The Panel Mount PC is designed to provide optimum service and performance with minimal

maintenance including the occasional external cleaning. For cleaning the Panel Mount PC

enclosure follow the suggested guidelines.

General – NEVER use abrasive cleaners or solvent-based cleaners!! Use a clean soft cloth.

The Panel Mount PC should only be opened and serviced by a qualified technician. Keep the

area around the Panel Mount PC clear and free of excessive dirt or other contaminants. Do not

use water or any liquids on the Panel Mount PC.

For Additional Assistance

Contact Your VarTech Sales Representative

Vartech Systems, Inc.

11529 Sun Belt Ct.

Baton Rouge, LA 70809

800-223-8050

Fax: 225-297-2440

www.vartechsystems.com

17.0 Panel Mount PC 486-0003-01-01
