Veilux VP-ATDNC27X Bedienungsanleitung

SPECIFICATIONS

3015 Eagle Drive, Suite 100, Grand Prairie, Texas 75052

Local Number: (214) 635-4855 / Fax: (928) 437-6270

[email protected]

www.veilux.net

OBJECT AUTO-TRACKING

DAY/NIGHT CAMERA

VP-ATDNC27X

FEATURES

MODEL NUMBERS

VP-ATDNC27XI In-Ceilling

VP-ATDNC27XO Outdoor

VP-ATDNC27XS Surface Mount

In-Ceiling OutdoorSurface

•1/4” VEILUX Super HAD CCD / High Resolution: 480 TV Line

•Stabilized Images by Reducing Flickering

•Motion Auto Tracking, Intelligent Surveillance with Alarm Function

•Preset, Auto Cruise & Pattern Scan Function

•Multi Communication Protocol Supported, Baud Rate Programmable

•360° Continuous Pan

•0° to 9° Tilt From Horizontal Plane Auto Flip 180°

•Iris & Focus, White Balance, Backlight Compensation - Auto / Manual

•Weatherproof (IP-66) - (Outdoor Only)

•Built-in Auto Focus / Auto Iris

•27x Optical Power Zoom Lens / 10x Digital Zoom (Max. 270x)

•TDN (ICR) / On-Screen Menu Control (OSD)

•Nine Backlight Compensation (BLC) Zones

•Video Transmission Distance Adjustable (3 Step)

•RS-232C TTL Interface / Electronic Sensitivity-up (DSS)

•12VDC

ITEM VP-ATDNC27X

Mounting Type Surface, In-Ceiling, Wall, Pole

Signal System NTSC PAL

Scanning System 2:1 Interface

Scanning Freq(H) 15.734 KHz

Scanning Freq(V) 59.94 Hz

Image Sensor 1/4” VEILUX Super HAD CCD

Sync. Sensor Internal

Total Pixels No. 811 (H) x 508 (V) 410K

Effective Pixels 768 (H) x 494 (V) 380K

Hor. Resolution More than 480 TV Lines

Video Output

Level 1.0 Vp-p (75Ω, Composite)

Pan / Tilt Speed Pan: 0.05°~400°/sec;

Tilt: 0.03°~240°/sec

S/N Ratio More than 48dB (AGC Off)

Digital Zoom 10x

Lens 27x Zoom Video AF

(F1.6 (W), F3.2 (T) f=3.6~97.2mm)

Panning Range Pan: 0°~360° Continuous; Tilt: 0°~90°

Track Speed 0°~100°/sec

Min. Illumination

Day Mode 1Lux (30IRE), Night Mode

0.5Lux (30IRE), DSS 0.001Lux

(128FLD, 30IRE)

Day & Night IR Cut FIlter & Digital Slow Shutter

480

TV LINES

VOLTAGE 12DC

24AC

D&N

NIGHT DAY

OPTICAL/

DIGITAL

ZOOM

Auto White

Balance

AWB

AGC

OFF ON

Auto Gain

Control 0.001

LUX

Back Light

Compensation

BLC

OFF ON

FLICKERLESS

PAN/TILT/ZOOM

CONTROLLER

SPECIFICATIONS

3015 Eagle Drive, Suite 100, Grand Prairie, Texas 75052

Local Number: (214) 635-4855 / Fax: (928) 437-6270

[email protected]

www.veilux.net

OBJECT AUTO-TRACKING

DAY/NIGHT CAMERA

VP-ATDNC27X

ITEM VP-ATDNC27X

White Balance Auto / Push Auto / Outdoor / Indoor /

Special

AGC Auto / Manual (0~255)

BLC 9 Backlight Compensation Zones

Flickerless On / Off

Electronic Shutter

Speed 1/60~1/10,000s (Manual, 8 Steps)

Digital Slow Shutter 2FLD~128FLD / Off

OSD Menu On/Off

Focus Mode Auto / Manual

Input / Output

Connector

Power: 2 Pin Terminal / RS-485: 2 Pin

Circle Connector / PTZ Control: 3 Pin

Circle Connector / Video

Preset Position No. 256

Auto Cruise Auto Switch from 0 to 54 Preset Pos’

Sequentially

Pattern Scan P/T/Z Scan from 55 to 63 Preset Pos’

Automatically

Comm. Port RS-485

Spectra Address 0~255

Operating Temp -25°C ~ +70°C (w/o Heater) /

-50°C ~ +70°C (with Heater)

Power Consumption Max. 4.56 W / 380mA

Power Voltage 12VDC (9V~15V)

Dimensions 48 (W) x 51.6 (H) x 86 (D) mm

Weight (Net) Approx. 250g
