VelectriX Ascent Bedienungsanleitung
VelectriX Instruction Manual
•Ascent
•
Urban Step Through
Page 1
Contents
Safe Riding Recommendations
Page 2
Pre-Ride Checklist
Page 3
Display and Controls
Pages 4-6
Battery Instructions
Page 7
Battery Charging
Page 8
Maintenance
Page 9
Warranty
Pages 10-12
Model Specification
Pages 13 &14
Page 2
Safe Riding Recommendations
1. Please ensure you are familiar with and follow all traffic laws
and regulations in your locality.
2. Always wear a helmet when riding your bike.
3. Don’t lend your bike to anyone who is unfamiliar with it.
4. As with all bikes it is important that you stay within safe limits
and speeds. If you feel you are travelling too quickly for the
road conditions, then slow down!! High speeds will increase risk
of injury in the event of an accident.
5. Please read and become familiar with the “Pre-Ride Checklist”
in this manual before riding your bike.
6. Switch the lights on your bike on when riding at all times of the
day or night. If your bike doesn’t have lights fitted as standard,
it is recommended that you purchase them and fit before riding.
Page 3
Pre-Ride Checklist
1. Check your bike for any loose nuts, bolts, or fixings.
2. Check tyre pressures on your bike are correct. Please always
refer to the tyre manufactures suggested levels on the side of
the tyre.
3. Check the tyres on your bike for any visible damage, wear and
tear or bald spots.
4. Check that the brake levers have been installed correctly on
your bike. The left-hand brake lever should operate the rear
brake and the right-hand brake lever should operate the front
brakes.
5. Check the brakes are working effectively.
6. Check that your bike is fitted with a working bell and reflectors.
7. Check that the wheel nuts or quick release skewers on your bike
are tight.
8. Check that the electronic functions on your bike are working.
9. Check that the handlebars and stem are tightened.
10. Check that all accessories are securely fastened.
11. Check that your battery has sufficient charge for your ride.
Page 4
LCD Display and Controls
Display Operation
The LCD display is mounted on the left side of the handlebar and is
controlled with 3 easy to use buttons:
Power, (Up) and (Down)
Power On/Off
Press and hold the button down for more than 2 seconds to start the
display. To turn off, repeat this process. The display will turn off
automatically after 10 minutes, if not in use.
Page 5
User Interface
There are 3 display screens available. Screen 1 shows Battery Charge
Indicator, Trip Time, Current Speed, Power Assist Level and Distance.
Screen 1 also shows icons for Walk Mode, Light Operation (for bikes with
lights fitted) and Power Assist Operation.
To move to screen 2, hold the Power button down, when in screen 1.
Screen 2 shows Total Trip Time, Total Trip Distance and Average Speed.
To move to screen 3, hold the Power button down when in screen 2.
Screen 3 shows Maximum Speed and Battery Voltage.
Holding the Power button down in screen 3 will return you to screen 1.
Battery Indicator
Trip Time
Power Assist Level
Current Speed
Distance
Page 6
Walk Mode
Press and hold the button to engage the Walk Assist function. The
icon will appear in the display and the bike will assist to 6 kph. Release the
button to exit the Walk Assist mode.
The walk assist feature is not a riding mode. It is designed to assist with
walking the bike up an incline to a maximum of 6 kph.
Power Assist Level Adjustment
There are 5 pedal assist settings on this bike, level 1 providing the lowest
level of assisted power and level 5 the highest. Simply push the plus or
minus buttons to change between the levels.
Light Operation (for models equipped with lights as standard)
Press and hold the button to turn on, and off, the lights and display
backlight.
Battery Charge Indicator
When the battery charge is above 70%, all 4 bars will display in the
indicator. As charge drops, each bar will turn off in order. If the battery
charge is below 15%, there will be no bars visible.
Trip Data Clearing
To reset the Trip Time and Trip Distance, press and together for
2 seconds. Now briefly press and the data will be cleared.
Page 7
Battery Instructions
Before riding you should check the battery charge by pressing the button
on the battery top. A fully charged battery will display all 4 lights.
Locking & Unlocking the Battery
The bike is supplied with a set of keys, that are required to remove the
battery from the bike. The lock is located in the upper battery mount, in
the frame of the bike.
Removing the Battery from the Bike
The Battery Charger
Only use the battery charger supplied with this bike.
To remove the battery, insert the key and turn fully clockwise. Use the
battery handle to pull the battery from the bike. When reinserting the
battery, place the base in first and push down gently on the top to
engage the lock. You will hear the lock “click” into place.
Always make sure the battery is securely locked in place before riding.
Page 8
Charging the Battery
The battery may be charged on or off the bike.
1. Plug the battery charger into the charging port on the battery
and wall power socket.
2. Only when connected to the battery, should the charger be
turned on at the wall power socket.
3. When charging, both LED lights on the charger will be RED.
One of the lights will turn GREEN when the battery is fully
charged.
4. Charging time is around 4 hours.
Page 9
Maintenance
oYour VelectriX bike should be returned to your servicing dealer for
servicing and a thorough inspection once every 9 months or
1500kms, whichever comes first. Excluding the electronics, motor,
battery and wiring, your VelectriX e-bike is a normal bike, with
normal components. Your dealer will be able to explain to you the
general care and maintenance required for the components of your
bike.
oOnce a month lubricate the chain and all pivot points on your
derailleur and derailleur pulleys with suitable chain lube.
oYou can clean your bike with warm soapy water, however, please do
not submerge any electrical components or use a high pressure
hose. You can wipe dry the bike with a cloth.
oVelectriX encourages all owners to return their new VelectriX bike
to the place of purchase for a service/safety check, within the first
month or so of ownership.
