Venstar T4700 Betriebsanleitung
with Humidity Control
i
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for an
intentional radiator, pursuant to Part 15, subpart C of the FCC rules.These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference in radio communications.
However, there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that of the
receiver.
•Consult the dealer or an experienced radio orTV technician for help.
Notice: Only peripherals complying with FCC limits may be attached to this
equipment. Operation with noncompliant peripherals or peripherals not
recommended by Venstar, is likely to result in interference to radio and TV
reception. Changes or modifications to the product, not expressly approved by
Venstar could void the user’s authority to operate the equipment.
FCC - INDOOR Mobile Radio Information:
To comply with FCC/IC RF exposure limits for general population / uncontrolled
exposure, the antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter.
This Device complies with Industry Canada License-exempt RSS standard(s).
Operation is subject to the following two conditions: 1) this device may not
cause interference, and 2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Follow the Installation Instructions before proceeding. Set the
thermostat mode to “OFF” prior to changing settings in setup
or restoring Factory Defaults.
CAUTION
This Voyager thermostat has the ability to receive updates to its firmware.
Periodically firmware updates are released by the manufacturer to add features
and/or performance enhancements.This manual was produced reflecting the
most current firmware/feature set at the time of publication, firmware rev. 1.0.
Firmware releases after rev. 1.0 may not be adequately depicted in this manual.
Please refer to the appropriate website or contact your place of purchase to learn
about changes to the thermostat after firmware release 1.0.
Under Industry Canada regulations, this radio transmitter may only operate using
an antenna of a type and maximum (or lesser) gain approved for the transmitter
by Industry Canada.To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotropically
radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
Cet appareil est conforme avec Industrie Canada, exempts de licence standard
RSS(s). Son fonctionnement est soumis aux deux conditions suivantes: 1) ce
dispositif ne doit pas causer d’interférences, et 2) ce dispositif doit accepter
toute interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement de l’appareil.
En vertu des règlements d’Industrie Canada, cet émetteur de radio ne peut
fonctionner en utilisant une antenne d’un type et maximale (ou moins) Gain
approuvé pour l’émetteur par Industrie Canada. Pour réduire les interférences
radio potentielles aux autres utilisateurs, le type d’antenne et son gain doivent
être choisis afin que la puissance isotrope rayonnée équivalente (PIRE) ne est pas
plus de ce qui est nécessaire pour une communication réussie.
We, Venstar, declare under our sole responsibility that the device to which
this declaration relates: Complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC ID: MUH-SKYPORT3
IC: 12547A-SKYPORT3
These numbers can be located on the inside of the thermostat backplate,
in the upper right corner.
MUH-SKYPORT3
ii
iii
Glossary of Terms
Auto-Changeover: A mode in which the thermostat will turn on the
heating or cooling based on room temperature demand.
Cool Setpoint: The warmest temperature that the space should rise to
before cooling is turned on (without regard to deadband).
Deadband: The number of degrees the thermostat will wait, once a
setpoint has been reached, before energizing heating or cooling.
Dehumidify: To reduce the amount of moisture in the air.
Differential: The forced temperature difference between the heat
setpoint and the cool setpoint.
Heat Setpoint: The coolest temperature that the space should drop to
before heating is turned on (without regard to deadband).
Humidify: To increase the amount of moisture in the air.
Icon: The word or symbol that appears on the thermostat display.
Mode: The current operating condition of the thermostat (i.e. Off, Heat,
Cool, Auto).
Non-Programmable Thermostat: A thermostat that does not have the
capability of running Time Period Programming.
Override: During programmed unoccupied periods, pressing the
Override button will force the thermostat into occupied settings. During
programmed occupied periods, pressing the Override button will force
the thermostat into unoccpied settings.
Programmable Thermostat: A thermostat that has the capability of
running Time Period Programming.
Reheat: Running the cooling and 2nd stage strip heaters at the same
time in order to dehumidify the air without signicantly cooling down
the room temperature.
Temperature Swing: Same as Deadband.
iv
Table of Contents
GET TO KNOW YOUR THERMOSTAT
Get to Know Your Thermostat.................................................... 1
Quick Start .................................................................................. 6
INSTALLATION INSTRUCTIONS
Installation Instructions .............................................................. 9
Sample Wiring Diagrams........................................................... 13
Test Operation............................................................................ 16
USER SETUP
Backlight Operation................................................................... 17
Scrolling Display Options .......................................................... 18
Emergency Heat ........................................................................ 18
Wireless Modules....................................................................... 19
Service Filter .............................................................................. 23
Runtimes .................................................................................... 24
Available Modes......................................................................... 25
INSTALLER SETUP
Setpoint Limits........................................................................... 26
Timers and Deadbands ............................................................. 27
Humidication & Dehumidication............................................ 28
Dry Contact Operation............................................................... 29
Holiday ....................................................................................... 29
Remote Sensor Operation......................................................... 30
Factory Defaults......................................................................... 32
TECHNICIAN SETUP
Sensor Calibration ..................................................................... 33
Equipment Testing ..................................................................... 33
Advanced Setup Table............................................................... 34
Troubleshooting ......................................................................... 36
INDEX ........................................................................................... 37
WARRANTY.................................................................................. 41
1
Get To Know Your Thermostat
Optional Wireless Module
Backlit, Scrolling Display
Backlit Cooler & Warmer
Buttons
Backlit LCD Display
Override Button
Heat or Cool
Demand Indicator
Red = Heat, Green = Cool
Setup Buttons Behind Door
2
Get To Know Your Thermostat
Setup Buttons
3
Get To Know Your Thermostat
Display Features
1The scrolling display will be used to help you easily navigate
the setup screens in the thermostat.
2Clock with Day of the Week
Indicates the current time and day. This clock is also used to
program the time period schedules.
3Mode Indicators
Selects the operational mode of the equipment.
HEAT - Indicates the heating mode.
COOL - Indicates the air conditioning mode.
HEAT & COOL - Indicates the system will automatically change-over
between heat and cool modes as the temperature varies.
OFF - Indicates heating and cooling is turned off.
4RoomTemperature Display
Indicates the current room temperature and displays the outdoor
temperature when selected.
5Outdoor icon
Indicates the temperature displayed is from the optional
outdoor sensor.
HI
Lo
Outdoor
Fan On
COOL
AUXHEAT
Override
Day Night
Morning
Evening
Setup Step
2nd
Stage
Am
Pm
18:88
188
188
88
188
1
3
3
4
5
2
4
Get To Know Your Thermostat
Display Features
6 Desired SetTemperature
Indicates desired room temperature(s). Also displays
the highest and lowest temperatures for the day.
7 Wi-Fi icons
One dot indicates the thermostat recognizes the wireless module.
The “pull” icon indicates the thermostat is currently connected to
the Local access point, via the optional Wi-Fi Module.
8 Setup Step icon
Indicates the step number when the thermostat
is in the setup mode.
9 2nd Stage icon
Indicates what stage of cooling or heating is currently energized.
10 icon
Indicates the keypad has been locked.
Outdoor
Fan On
C
OO
L
A
UX
H
EAT
Override
Day Night
Morning
Evening
Setup Step
2nd
Stage
Am
Pm
18:88
188
188
88
188
10
6
6
7
8
9
5
Get To Know Your Thermostat
11 AuxHeat icon
Indicates 2nd stage electric strip heat is being used when the
thermostat is programmed for Heat Pump operation. Only the
Aux icon will appear during Cool to Dehumidify to indicate
Reheat operation.
12 Fan On icon
Indicates constant, continuous fan operation.
When Fan On is not lit - indicates the fan will only
operate when necessary to heat or to cool.
HI
Lo
Outdoor
Fan On
C
OO
L
A
UX
H
EAT
Override
Day Night
Morning
Evening
Setup Step
2nd
Stage
Am
Pm
18:88
188
188
88
188
11
12
Display Features
Inhaltsverzeichnis
Andere Venstar Thermostat Handbücher
Venstar
Venstar T1050 Bedienungsanleitung
Venstar
Venstar T3900 Kurzanleitung
Venstar
Venstar ACC0433 Bedienungsanleitung
Venstar
Venstar T4950-IAQ Betriebsanleitung
Venstar
Venstar T1035 Bedienungsanleitung
Venstar
Venstar EXPLORER Mini T2100 Bedienungsanleitung
Venstar
Venstar ColorTouch T8900 Fehlerbehebungshandbuch
Venstar
Venstar T2700 Bedienungsanleitung
Venstar
Venstar T1 900 Bedienungsanleitung
Venstar
Venstar ColorTouch T6800 Betriebsanleitung
Venstar
Venstar T2800 Bedienungsanleitung
Venstar
Venstar T1100FS Bedienungsanleitung
Venstar
Venstar T1075 Betriebsanleitung
Venstar
Venstar Residential T7900 Fehlerbehebungshandbuch
Venstar
Venstar TSTATEZ Bedienungsanleitung
Venstar
Venstar T1800 Bedienungsanleitung
Venstar
Venstar T1070 Betriebsanleitung
Venstar
Venstar T2800 Bedienungsanleitung
Venstar
Venstar T1900 Bedienungsanleitung
Venstar
Venstar ColorTouch T6900 Betriebsanleitung
Beliebte Thermostat Handbücher anderer Marken
EWELLY
EWELLY EW-181 Bedienungsanleitung
Prolon
Prolon T1100 Montageanleitung
Computherm
Computherm Q20 Bedienungsanleitung
Heatmiser
Heatmiser neoStat Bedienungsanleitung
Aube Technologies
Aube Technologies TH111GFCI-NP 240 VCA Bedienungsanleitung
Mars
Mars HEAT CONTROLLER IR Wireless Thermostat Bedienungsanleitung
