USER GUIDE FOR
BTRM300 & BTRM400
Battery Test Remote Monitor
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
2
Contents
1. Warnings ................................................................................................................... 4
1.1 BTRM300 ................................................................................................................................... 4
1.2 BTRM400 ................................................................................................................................... 4
2. Supplied Equipment ................................................................................................. 4
3. Overview ................................................................................................................... 4
4. System Description .................................................................................................. 5
4.1 BTRM300 & BTRM400 Overall System Diagram ...................................................................... 5
4.2 System Connector Overview ..................................................................................................... 5
5. Basic Setup ............................................................................................................... 6
5.1 Connecting Unit to a PC ............................................................................................................ 6
5.2 Accessing your host computer’s network settings ..................................................................... 7
5.3 Setting IP Address Information for BTRM Default ..................................................................... 8
5.4 Verify IP Address Information .................................................................................................... 8
5.4.1 For Wi-Fi Connections ...................................................................................................... 9
5.4.2 For Ethernet Connection .................................................................................................. 9
6. Mounting ................................................................................................................. 11
6.1 Wiring Battery Connection ....................................................................................................... 11
6.2 Wiring Power Supply Connections .......................................................................................... 11
6.3 Wiring Battery Charger Connections ....................................................................................... 11
6.4 Alarm Connections .................................................................................................................. 11
6.5 Clearing Battery Test Data ...................................................................................................... 11
7. Web Interface Menus ............................................................................................. 11
7.1 System Status Page ................................................................................................................ 12
7.2 Battery Status Page ................................................................................................................. 14
7.3 Battery Test Page .................................................................................................................... 15
8. Manual Test Page ................................................................................................... 16
8.1 Capacity IO Check ................................................................................................................... 16
8.2 Reset Battery Data and Setting to Defaults ............................................................................. 16
9. Port Options Page .................................................................................................. 17
9.1 IO Test 1 .................................................................................................................................. 17
9.2 IO Test 2 .................................................................................................................................. 18
9.3 Email Configuration Page ........................................................................................................ 18
9.4 Email Test Page ...................................................................................................................... 19
9.5 Network Configuration Page .................................................................................................... 20
10. DNP3 and Modbus RTU Configuration Page ..................................................... 21
10.1 Modbus Addressing ............................................................................................................... 21
10.2 SNMP Configuration Page ..................................................................................................... 23
10.3 Help Page .............................................................................................................................. 24
10.4 Authorization Page ................................................................................................................ 25
10.5 About ..................................................................................................................................... 26
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
3
11. SNMP Functionality .............................................................................................. 27
11.1 Install MIB Browser ................................................................................................................ 27
11.2 Install SNMP MIB File ............................................................................................................ 27
11.3 View BTRM via MIB Browser ................................................................................................. 28
11.4 Configure Trap Receiver ........................................................................................................ 30
11.5 Cannot Bind to Port 162 Error Message ................................................................................ 31
11.6 Open Trap Receiver .............................................................................................................. 33
12. Additional Protocols ............................................................................................ 36
DNP3 ............................................................................................................................................. 36
12.1 Overview ................................................................................................................................ 36
12.2 Data Link Layer ...................................................................................................................... 36
12.3 Application Layer ................................................................................................................... 36
12.3.1 Function Support .......................................................................................................... 36
12.3.2 Enable Disable Unsolicited Event Status ..................................................................... 37
12.3.3 Groups and Variations .................................................................................................. 37
12.3.4 Qualifiers ...................................................................................................................... 37
12.3.5 Binary Input Status Points ............................................................................................ 37
12.3.6 Analog Input Status Points ........................................................................................... 38
12.3.7 Analog Output Status Points ........................................................................................ 38
12.3.8 Binary Output Status Points ......................................................................................... 39
12.3.9 Binary Output Write to Points ....................................................................................... 39
12.3.10 Events ........................................................................................................................ 40
13. Modbus Protocols ................................................................................................ 40
Overview ........................................................................................................................................ 40
13.1 Function 01 Boolean (Coils) | Read Discrete Inputs .............................................................. 40
13.2 Function 02 Input Status | Read Discrete Inputs ................................................................... 41
13.3 Function 03 Holding Registers | Read Single or Multiple ...................................................... 41
13.4 Function 04 Input Registers | Read Single or Multiple ........................................................... 41
13.5 Function 05 Boolean (Coils) | Write Discrete Output ............................................................. 41
13.6 Function 06 Holding Register | Write Single .......................................................................... 42
14. Additional Network Setup .................................................................................... 42
14.1 IP Reset ................................................................................................................................. 42
14.2 Router Ports ........................................................................................................................... 42
14.3 Port Table .............................................................................................................................. 43
15. Specifications and Warranty ............................................................................... 43
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
4
1. Warnings
Carefully observe proper DC polarities connections for batteries, chargers, and loads.
*** Unit WILL be damaged by incorrect polarity connections ***
1.1. BTRM300
Maximum rated Voltages for Battery, Charger, Power Supply, and Loads is 30 VDC
Maximum rated Current for Battery, Chargers, Power Supply and Total Load is 20 Amps
*** Unit can be damaged by exceeding these limits ***
*** Use of an Inline fuse is recommended to prevent over current conditions***
1.2. BTRM400
Maximum rated Voltages for Battery, Charger, Power Supply, and Loads is 60 VDC
Maximum rated Current for Battery, Chargers, Power Supply and Total Load is 10 Amps
Alarm Connections CH1, CH2, CH3, CH4 rated for 60 VDC, 80ma max load.
• Observe correct polarity
• Do not exceed these ratings.
• Do not connect to AC line powered loads.
*** Unit can be damaged by exceeding these limits ***
*** Use of an Inline fuse is recommended to prevent over current conditions***
2. Supplied Equipment
Included in box:
• BTRM300 (Tessco SKU 281170) or BTRM400 (Tessco SKU 246962)
• 3ft Ethernet Cable
• BTRM User Guide
3. Overview
As batteries age their capacity slowly deteriorate until they need replacement. Additionally, battery
capacity can be affected by extended operation under adverse conditions of high or low
temperatures, high discharge rates, under charging (in particular if left in a completely discharged
state for weeks or longer), charging voltages higher than recommended (this condition immediately
starts generating surplus hydrogen gas for which even Sealed Lead Acid Batteries are forced to
vent).
Although a battery’s state of charge can be inferred by monitoring the battery terminal voltage while in
standby mode, this voltage will not give an indication of actual capacity. Furthermore, a battery that is
marginal may not be detected until it is called upon to perform, at which point it is too late to prevent a
system failure. For a battery connected to a charger that maintains a float voltage, neither condition
can be checked.
In these cases, the BTRM is designed to evaluate battery capacity transparently to system operation
and provide network-based notification should a battery fail, or its capacity drop below a specified
level. This also has the advantage of allowing batteries that exceed their nominal lifetime to remain in
service, provided they meet capacity requirements.
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
5
4. System Description
BTRM300 & BTRM400 Overall System Connection Diagram
System Connection Overview
4.1. Power Supply (+/-)
The BTRM must be connected to the load Power Supply in order to energize the load while
the Battery Charger is charging the battery. In the above figure, a separate Load Power
Source and Battery Charger are used. Alternatively, a single Power Source can be used. In
this case the Charger + and Power Supply + terminals must be connected together.
4.2. Battery Charger (+/-)
The BTRM must be connected to the battery charger in order to charge the battery bank
after the battery capacity test is performed.
4.3. Battery (+/-)
BTRM300 Allowable system voltages: 12V/24 (Max 32V)
IO Channel 1 +
IO Channel 1 -
IO Channel 2 +
IO Channel 2 -
Battery +
Charger +
Power Supply +
Battery -
Charger -
Power Supply -
Load +
Load -
RJ45
Fuse
BATTERY BANK
+ POS- NEG
PS
SDR-120-12
L
N
DC OK
+V-V
+V ADJ
+
DC OK
3 State
Charger
L
N
DC OK
+V-V
+
Ready
System
Load
- NEG Pos+
Float
BTRM300
25 Amp
To AC source
BTRM400
15 Amp
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
6
BTRM400 Allowable system voltages: 12V/24V/36V/48V (Max 60V).
Remember to select BTRM operation voltage on the Port Options page or selecting via one
of the supported protocols (DNP3/Modbus/Snmp) for proper operation.
The battery bank must be connected directly to the BTRM, such that the BTRM can power
the load from the Battery without any additional power source in circuit in order to perform
the battery capacity test.
4.4. Load (+/-)
The battery bank must be connected directly to the BTRM in order to perform the battery
capacity test.
4.5. Alarm Connector (+/-)
BTRM300 & BTRM400 have 4 Channels of ground referenced IO.
All 4 channels can be used to sense and monitor 0V to 60V.
Channels 1 and 2 can be used to activate relays, audible indicators, or lamps by pulling the
IO pin to ground under certain alarm conditions.
Both Channels 1 and 2 contacts are normally open when power is off. The user can select
normally open or normally closed under an alarm condition.
Do not exceed the contact maximum relay ratings of 60 Volts, 80 ma. Do not use to directly
operate AC line connected equipment.
5. Basic Setup
Connecting unit to a PC
Notes on accessing a BTRM over Ethernet: Technically you should be able to plug the device into
your current network, regardless of how your current network IP addressing is set up and be able to
reach the BTRM’s Status and Setup web page by entering its IP address (found on the BTRM front
label) in a Web Browser on a local computer. However, in practice, not so easy, due to a wide variety
of possibly incompatible network addressing and firewall configurations. These difficulties occur most
often if someone else has set up the network settings, and in particular where these settings are
“managed” by software installed on your computer by your internet provider or corporate IT
departments.
To avoid these potential network issues at the initial evaluation stage it is best to connect both your
computer and the device to a hub/network switch (one that is not connected to the rest of your
network) or directly connect your computer to the BTRM with a cross-connected Ethernet cable.
Initial Power up to set IP address
To power up the device, connect the battery to the BTRM. Power up the power supply and battery
charger. The BTRM starts in self-test mode for 5 to 15 seconds. PB1 and PB2 push button LEDs will
blink.
Once the device is power up and cabled to the Ethernet, the GREEN LED will illuminate on the
Ethernet connector and startup should be complete within 30 sec.
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
7
Accessing your host computer’s network settings
From the start button select Control Panel -> Network and Internet -> Network Connections
• Select the adapter that you plan to use and from the File menu, select properties.
• This will bring up the properties window, shown on the right.
• Scroll down to the Internet Protocol Version 4 (IPv4) item, select it, and then select “properties”.
• This will bring up the window to allow manual configuration of the network adapter’s IP addresses.
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
8
Setting IP address information for BTRM default
Using a direct connection to the device with a cross connected cable or using a network switch (hub),
use the manual IP settings shown on the right. This property dialog can be found in the TCP/IP
properties, which is a sub dialog of the Network Connections Properties, both found in Control Panel
Network Connections.
(Typically, the default gateway and DNS server need not be entered.)
If using a router, check your local area connection settings to see if the router gateway address is the
same as the default device gateway of 192.168.1.1. If it’s not, you will need to use a direct connection
as described above to change the device gateway address to match the router’s gateway address.
Verify IP address information
For the initial configuration of the BTRM and to change Network IP settings for placement in an IP
based network you will need to connect the BTRM directly to your PC. Once connected to your PC
you will be able to configure the BTRM to match your network settings.
You will need the following information from your network administrator to add the BTRM to your IP
Network:
• IP Address – we recommend using a static IP address for the BTRM
• Gateway – what is the IP address of the Gateway of your network
• Subnet Mask – what is the mask of your network
• Primary DNS – IP address of the primary DNS server for your network
Once you have your connection made with laptop or PC you will need to record your IP address and
verify connection to the BTRM.
NOTE: It may be necessary to give your PC or Laptop a static address to access the BTRM default
network.
Example: IP Address: 192.168.1.200
Subnet mask: 255.255.255.0 Finding your IP address in Windows 10
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
9
For Wi-Fi connection
On the taskbar, select the Wi-Fi network icon
• Under the Wi-Fi network you're connected to, select Properties.
Under Properties, look for your IP address listed next to IPv4 address.
For Ethernet connection
On the taskbar, select the Ethernet network icon
1. Select the Ethernet network connection
2. Under Ethernet, select the Ethernet network connection.
3. Under Properties, look for your IP address listed next to IPv4 address.
Verify connectivity to the BTRM by sending a Ping command to the BTRM’s default IP address: PING
192.168.1.214 <Enter> you should receive four REPLY messages from the BTRM.
BTRM Battery Test Remote Monitoring System – User Guide V3.2 | ã2021 Ventev | LIT SKU: 09834
10
Command window available from Windows 10 by searching for cmd.exe
Open a New Web Browser Session (Microsoft Edge, Firefox, Chrome) and type in the address of the
BTRM (default is 192.168.1.214) and click <Enter>.
If everything is set up correctly you should see the System Status of the BTRM.
Note: The Green Status Indicator should be blinking when the BTRM is active and connected.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Ventev Monitor Handbücher
