VX-2200(LTR)

SERIES

OPERATING MANUAL

Vertex Standard LMR, Inc.

Unsafe Radiation Distance

Congratulations!

You now have at your fingertips a valuable communications tool: a VERTEX STAN-

DARD two-way radio! Rugged, reliable and easy to use, your VERTEX STAN-

DARD radio will keep you in constant touch with your colleagues for years to come,

with negligible maintenance downtime.

Please take a few minutes to read this manual carefully. The information presented

here will allow you to derive maximum performance from your radio, in case ques-

tions arise later on.

We’re glad you joined the VERTEX STANDARD team. Call on us anytime, be-

cause communications is our business. Let us help you get your message across.

NOTICE !

There are no owner-serviceable parts inside the transceiver. All service jobs

must be referred to an authorized VERTEX STANDARD Service Represen-

tative. Consult your Authorized VERTEX STANDARD Dealer for installa-

tion of optional accessories.

SAFETY/WARNING INFORMATION

WARNING - DO NOT operate the VX-2200 (LTR) radio when any person(s)

(bystanders) outside the vehicle are within the distances shown in the chart at

the bottom of this section.

Safety Training information:

Antennas used for this transmitter must not exceed an antenna gain of 0 dBd.

The radio must be used in vehicle-mount configurations with a maximum

operating duty factor not exceeding 50 %, in typical Push-to-Talk configura-

tions.

This radio is restricted to occupational use, work related operations only where

the radio operator must have the knowledge to control the exposure condi-

tions of its passengers and bystanders by maintaining the minimum separa-

tion distance shown below.

Failure to observe these restrictions will result in exceeding the FCC RF

exposure limits.

Antenna Installation:

For rear deck trunk installation, the antenna must be located at least the fol-

lowing distance away from rear-seat passengers in order to comply with the

FCC RF exposure requirements.

For roof top installations, the antenna must be placed in the center of the roof.

VHF Model

1.64 Feet (0.50 m)

UHF Model

1.35 Feet (0.41 m)

VX-2200 (LTR)SERIES OPERATING MANUAL 1

INTRODUCTION

The VX-2200(LTR)Series are full-featured FM transceivers designed for flexible

mobile and base station business communications in the VHF or UHF Land Mobile

bands. These transceiver are designed for reliable business communications in a

wide variety of applications with a wide range of operating capability provided by

their leading-edge design.

The 250-group memories can each be programmed with a 8-character group name.

Important channel frequency data is stored in EEPROM and flash memory on the

CPU, and is easily programmable by dealers using a personal computer and the

VERTEX STANDARD Programming Cable and CE94 Software.

The pages which follow will detail the many advanced features provided on the VX-

2200(LTR)Series transceiver. After reading this manual, you may wish to consult

with your Network Administrator regarding precise details of the configuration of

this equipment for use in your application.

For North American Users Regarding 406 MHz Guard Band

The U.S. Coast Guard and National Oceanographic and Atmospheric Ad-

ministration have requested the cooperation of the U.S. Federal Communica-

tions Commission in preserving the integrity of the protected frequency range

406.0 to 406.1 MHz, which is reserved for use by distress beacons. Do not

attempt to program this apparatus, under any circumstances, for operation in

the frequency range 406.0 - 406.1 MHz if the apparatus is to be used in or

near North America.

VX-2200 (LTR)SERIES OPERATING MANUAL2

CONTROLS & CONNECTORS

Front Panel

Important! - All buttons located on the Front Panel are Programmable Function

(PF) Buttons, configured according to your network requirements and programmed

by your VERTEX STANDARD dealer. The instructions below describe a typically-

configured radio.

VOL/PWR Knob

Turn this control clockwise to turn the radio on and to increase the volume.

Turn it counterclockwise into the click-stop to turn the radio off.

Microphone Jack

Connect the microphone plug to this jack.

[P1]-[P4]Buttons (Programmable Function Buttons)

These buttons can be set up for special applications, such as High/Low power

selection, Monitor, Talk-Around, etc., as determined by your network require-

ments and programmed by your VERTEX STANDARD dealer.

[]/[]Buttons (Programmable Function Buttons)

In the factory default, pressing either button changes the current group (and

displayed group number or name). Holding in either button for more than 1.5

second causes the radio to begin stepping (repeatedly) upward or downward

through the groups.









VX-2200 (LTR)SERIES OPERATING MANUAL 3

LCD (Liquid Crystal Display)

The display includes a 8-character alpha-numeric section showing group name

tags/identity information and error messages, and an upper icon row displaying

feature status (see below).

TX/BUSY Indicator

Indicates Transceiver’s Transmit/Receive Status

CONVENTIONAL ZONE

Steady Red: Transmitting in progress

Steady Green: Signaling Off

Blinking Green: Busy Channel/Squelch Off

LTR TRANKING ZONE

Steady Red: Transmission in progress

Steady Green: Zone Busy

CONTROLS & CONNECTORS

“Call” indicator

Low Transmt Power Mode

“Scan” is activated

“Talk-Around” is enabled

Receiver Monitor

“AUX A” Port is activated

8 Character Alpha-numeric Display

“Encryption” is enabled Home Zone/Group

RSSI Indicator (four steps) “Zone Scan” is enabled

on the current Zone

VX-2200 (LTR)SERIES OPERATING MANUAL4

Rear Panel

CONTROLS & CONNECTORS

13.6V DC Cable Pigtail with Connector

The supplied DC power cable must be connected to this 2-pin connector. Use

only the supplied fused cable, extended if necessary, for power connection.

Antenna Socket

The 50-Ohm coaxial feedline to the antenna must be connected here, using a

type-M (PL-259) plug.

D-Sub 15-Pin Accessory Connector

External TX audio line input, PTT (Push To Talk), Squelch, and external RX

audio line output signals may be obtained from this connector for use with ac-

cessories such as data transmission/reception modems, and external Group con-

trol input etc.

External Speaker Jack

An external loudspeaker may be connected to this 2-contact, 3.5-mm mini-phone

jack.

Caution: Do not connect either wire of this line to ground, and be certain that

the speaker has adequate capability to handle the audio output (12 W) from the

radio.









VX-2200 (LTR)SERIES OPERATING MANUAL 5

NOTE

VX-2200 (LTR)SERIES OPERATING MANUAL6

BASIC OPERATION OF THE TRANSCEIVER

Important! - Before turning on the radio the first time, confirm that the power con-

nections have been made correctly and that a proper antenna is connected to the

antenna jack.

Switching Power ON/OFF

Turn the VOL/PWR knob turn on the radio. The display will become illuminated.

Press the []/[]button to choose the desired operating group. A group name

will appear on the display. If you want to select an operating group from a

different zone, press the PF (Programmable Function) button which is pro-

grammed to the Zone Up/Down feature to select the zone you want before se-

lecting the operating group. See page 8 for more information on the Program-

mable Function keys.

Setting the Volume

Turn the VOL/PWR knob clockwise to increase the volume, and counterclock-

wise to decrease it.

Transmitting

CONVENTIONAL ZONE

To transmit, monitor the channel and make sure it is clear.

THIS IS AN FCC REQUIREMENT!

Press the PF button which is programmed to the Monitor feature to listen for

channel activity.

When receiving a call, transmit only after the incoming call ends. The radio

cannot receive a call and transmit simultaneously.

Press the PTT switch.

If the channel is clear, the TX/BUSY indicator will glow red. The radio is now

transmitting. While holding in the PTT switch, speak across the face of the micro-

phone in a clear and normal voice. For best transmission, hold the microphone

about 1-1/2 to 2 inches away from your mouth. Release the PTT switch to receive.

If the Busy Lockout feature has been programmed on a group, the radio will not

transmit when a carrier is present. Instead, the radio will generate a short beep

three times and indicate “ERROR” on the display. Release the PTT switch and

wait for the channel to be clear of activity.

If CTCSS or Digital Coded Squelch (DCS) Lockout has been programmed on a

group, the radio can transmit only when there is no carrier being received or

when the carrier being received includes the correct CTCSS tone or DCS code.

VX-2200 (LTR)SERIES OPERATING MANUAL 7

LTR ZONE

Press the PTT switch.

When a group is available, the TX/BUSY indicator will glow red. The radio is

now transmitting. While holding in the PTT switch, speak across the face of the

microphone in a clear and normal voice. For best transmission, hold the micro-

phone about 1-1/2 to 2 inches away from your mouth. Release the PTT switch

to receive.

If all groups are busy, a continuous tone will be heard from the radio, and the

“BUSY” notation will appear on the display when the PTT switch is pressed.

Release the PTT switch.

If the radio is out of range during the transmitting attempt, slow beeps will be

heard followed by a continuous tone from the radio.

Automatic Time-Out Timer

If the selected channel has been programmed for automatic time-out, you must limit

the length of each transmission. While transmitting, a beep will sound 10 seconds

before time-out. Another beep will sound just before the deadline; the red “TX”

indicator will disappear and transmission will cease soon thereafter. To resume trans-

mitting, you must release the PTT switch and wait for the “penalty timer” to expire

(if you press the PTT switch before this timer expires, the timer restarts, and you

will have to wait another “penalty” period)

BASIC OPERATION OF THE TRANSCEIVER

VX-2200 (LTR)SERIES OPERATING MANUAL8

ADVANCED OPERATION

Programmable Function (PF) Buttons

The VX-2200(LTR)Series includes six Programmable Function (PF) Buttons. The

PF button functions can be customized, via programming by your VERTEX STAN-

DARD dealer, to meet your communications/network requirements. Some features

may require the purchase and installation of optional internal accessories. The pos-

sible PF button programming features are illustrated below, and these functions are

explained on the pages to follow. For further details, contact your VERTEX STAN-

DARD dealer. For future reference, check the box next to the function that has been

assigned to each PF button on your particular radio, and keep it handy.

:Requires FVP-35 Optional Unit

PF Button (PRESS KEY/PRESS AND HOLD KEY)

Function

MONI

NSQ

Lighting

Group Up

Group Down

Continuous Group Up

Continuous Group Down

Zone Up

Zone Down

Continuous Zone Up

Continuous Zone Down

SCAN

SCAN A/D

LOW

TA (Talk Around)

Emergency

CALL 1

CALL 2

Code Up

Code Down

Call/Reset

Phone

Public Address

EXT. ACC1

EXT. ACC2

Short Cut to GP1

Short Cut to GP2

Short Cut to GP3

Short Cut to GP4

AF Min Vr

HORN

Key Lock

Option SW

Encryption

--- /---

---/---



--- /---



--- /---

Inhaltsverzeichnis

Andere Vertex Standard Transceiver Handbücher

Vertex Standard

Vertex Standard VX-2200 Series Bedienungsanleitung

Vertex Standard

Vertex Standard VX-3R Bedienungsanleitung

Vertex Standard

Vertex Standard VX-520U Bedienungsanleitung

Vertex Standard

Vertex Standard VX-2000V Bedienungsanleitung

Vertex Standard

Vertex Standard VX-3R Bedienungsanleitung

Vertex Standard

Vertex Standard GX1500S Bedienungsanleitung

Vertex Standard

Vertex Standard VXA-220 Bedienungsanleitung

Vertex Standard

Vertex Standard VX-146 Bedienungsanleitung

Vertex Standard

Vertex Standard VX-6000V Bedienungsanleitung

Vertex Standard

Vertex Standard VX-2200 Series Bedienungsanleitung

Vertex Standard

Vertex Standard VX-1700 Series Bedienungsanleitung

Vertex Standard

Vertex Standard DMU-2000 Allgemeine Anweisungen

Vertex Standard

Vertex Standard VX-420 Series Bedienungsanleitung

Vertex Standard

Vertex Standard VX-7200 Bedienungsanleitung

Vertex Standard

Vertex Standard VX-180U Bedienungsanleitung

Vertex Standard

Vertex Standard VX-350 series Bedienungsanleitung

Vertex Standard

Vertex Standard VXR-9000U Bedienungsanleitung

Vertex Standard

Vertex Standard VXA-220 Bedienungsanleitung

Vertex Standard

Vertex Standard VX-920ATEX Series Bedienungsanleitung

Vertex Standard

Vertex Standard VX-600v Bedienungsanleitung

Vertex Standard

Vertex Standard GX1256S Bedienungsanleitung

Vertex Standard

Vertex Standard VX-456 Bedienungsanleitung

Vertex Standard

Vertex Standard VX-210AU Bedienungsanleitung

Vertex Standard

Vertex Standard VX-4200 Series Bedienungsanleitung

Beliebte Transceiver Handbücher anderer Marken

Yaesu

Yaesu FT-7B Bedienungsanleitung

Kenwood

Kenwood ProTalk TK-3201 Bedienungsanleitung

Texas Instruments

Texas Instruments TLK10232 Bedienungsanleitung

Mizuho

Mizuho MX-2 Produkthandbuch

Kenwood

Kenwood TK-3180 Bedienungs- und Wartungshandbuch

Blitz

Blitz MJ-398U Bedienungsanleitung

Utilicom

Utilicom LongRanger 2050 Bedienungsanleitung

Standart

Standart HX290UKA Bedienungsanleitung

Altronix

Altronix Pace1PTM Bedienungsanleitung

Kirisun

Kirisun PT2208 Bedienungsanleitung

ELECRAFT

ELECRAFT KX2 Bedienungsanleitung

Zodiac

Zodiac K3 Bedienungsanleitung

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Bedienungsanleitung

Kenwood

Kenwood TK-2217 Bedienungsanleitung

Siemens

Siemens PSO 4000 Bedienungsanleitung

Kenwood

Kenwood TS-590SG Bedienungsanleitung

Midland

Midland G8E-BT Handbuch

ComNav

ComNav Mariner X2 Bedienungsanleitung
