CI 383-0 M NF E A++

CI 383-0 M NF E A++ RF

EN NO FROST COMBI REFRIGERATOR

Freezer - Fridge

User manual

DK NO FROST KOMBI KØLESKAB

Fryser - Køleskab

Brugsvejledning

NO FROSTFRI KOMBIKJØLESKAP

Fryser - kjøleskap

Bruksanvisning

Index

BEFORE USING THE APPLIANCE................................. 4

General warnings...................................................................... 4

Old and out-of-order fridges...................................................... 6

Safety warnings ........................................................................ 7

Installing and operating your fridge........................................... 8

Before Using your Fridge.......................................................... 8

Information about New Generation Cooling Technology .......... 9

THE PARTS OF THE APPLIANCE AND THE

COMPARTMENTS .......................................................... 10

THE VARIOUS FUNCTION AND POSSIBILITIES ......... 12

Dsipal and control panel .......................................................... 12

Operating your fridge............................................................... 13

Super freeze mode .............................................................. 13

Super cool mode.................................................................. 13

Economy mode.................................................................... 14

Holliday mode ...................................................................... 15

Drink cool mode................................................................... 16

Screen saver mode.............................................................. 16

Function of Child lock .......................................................... 17

Light cancelling mode .......................................................... 18

Freezer temperature settings............................................... 18

Cooler temperature settings ................................................ 19

Warnings about Temperature Adjustments.............................. 19

Accessories ............................................................................. 21

Freezer box.......................................................................... 21

Chiller Shelf ......................................................................... 21

Humidity controler................................................................ 22

Adjustable door shelf ........................................................... 22

Adjustable glass shelf .......................................................... 22

Accessories ............................................................................. 23

Maxi-fresh preserver............................................................ 23

CLEANING AND MAINTENANCE.................................. 24

Defrosting ................................................................................ 25

Replacing LED Lighting ........................................................... 25

ARRANGING FOOD IN THE APPLIANCE..................... 26

Refrigerator compartment........................................................ 26

Freezer compartment .............................................................. 27

TRANSPORTATION AND CHANGING OF INSTALLATION

POSITION........................................................................ 32

Repositioning the door............................................................. 32

BEFORE CALLING YOUR AFTER SALES SERVICE... 33

Tips for saving energy .................................................. 36

4BEFORE USING THE APPLIANCE

General warnings

WARNING: Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other

means to accelerate the defrosting process, other than

those recommended by the manufacturer.

WARNING: Do not use electrical appliances inside the

food storage compartments of the appliance, unless

they are of the type recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: In order to avoid any hazards resulting from

the instability of the appliance, it must be xed in accor-

dance with the following instructions:

• If your appliance uses R600a as a refrigerant (this

information will be provided on the label of the cooler)

you should take care during transportation and

installation to prevent the cooler elements from being

damaged. R600a is an environmentally friendly and

natural gas, but it is explosive. In the event of a leak

due to damage of the cooler elements, move your

fridge away from open ames or heat sources and

ventilate the room where the appliance is located for

a few minutes.

• While carrying and positioning the fridge, do not

damage the cooler gas circuit.

• Do not store explosive substances such as aerosol

cans with a ammable propellant in this appliance.

• This appliance is intended to be used in household

and domestic applications such as:

- staff kitchen areas in shops, ofces and other work-

ing environments which can be equated with ordi-

nary household

BEFORE USING THE APPLIANCE

- farm houses and by clients in hotels, motels and oth-

er residential type environments which can be equat-

ed with ordinary household

- bed and breakfast type environments which can be

equated with ordinary household

- catering and similar non-retail applications which can

be equated with ordinary household.

• The appliance is supplied with a plug approved in the

EU, which must not be used in a Danish installation, as

the unit thereby is not earthed acc. Local regulations.

Replacing the to Danish plug must be performed by

a qualied electrician. Alternatively, use an adapter

to transition between Schuko plug and Danish earth

system.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

• If the supply cord is damaged, it must be replaced

by the manufacturer, an authorised service agent or

similar qualied persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes

exceeding 2000 m.

6BEFORE USING THE APPLIANCE

Old and out-of-order fridges

• •If your old fridge has a lock, break or remove the lock before

discarding it, because children may get trapped inside it and may

cause an accident.

• •Old fridges and freezers may contain isolation material and

refrigerant with CFC or HFC. Therefore, take care not to harm

environment when you are discarding your old fridges.

Please ask your municipal authority about the disposal of the WEEE

reuse, recycle and recovery purposes.

Notes:

• Please read the instruction manual carefully before installing and

using your appliance. We are not responsible for the damage

occurred due to misuse.

• Follow all instructions on your appliance and instruction manual,

and keep this manual in a safe place to resolve the problems that

may occur in the future.

• This appliance is produced to be used in homes and it can only be

used in domestic environments and for the specied purposes.

It is not suitable for commercial or common use. Such use will

cause the guarantee of the appliance to be cancelled and our

company will not be responsible for losses incurred.

• This appliance is produced to be used in houses and it is only

suitable for cooling / storing food. It is not suitable for commercial

or common use and/or for storing substances except for food.

Our company is not responsible for losses to be incurred in the

contrary case.

BEFORE USING THE APPLIANCE

Safety warnings

• Do not connect your Fridge Freezer to the mains

electricity supply using an extension lead.

• Do not plug in damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• This appliance is designed for use by adults, do not allow children

to play with the appliance or let them hang off the door.

• Never touch the power cord/plug with wet hands as this could

cause a short circuit or electric shock.

• Do not place glass bottles or beverage cans in the ice-making

compartment as they can burst as the contents freeze.

• Do not place explosive or ammable material in your fridge.

Place drinks with high alcohol content vertically in the fridge

compartment and make sure that their tops are tightly closed.

• When removing ice from the ice-making compartment, do not

touch it. Ice may cause frost burns and/or cuts.

• Do not touch frozen goods with wet hands. Do not eat ice-cream

or ice cubes immediately after you have taken them out of the

ice-making compartment.

• Do not re-freeze frozen goods after they have melted. This may

cause health issues such as food poisoning.

• Do not cover the body or top of fridge with lace. This affects the

performance of your fridge.

• Secure any accessories in the fridge during transportation to

prevent damage to the accessories.

8BEFORE USING THE APPLIANCE

Installing and operating your fridge

Before using your fridge, you should pay attention to the following

points:

• The operating voltage for your fridge is 220-240 V at 50Hz.

• We do not accept responsibility for any damages that occur due

to ungrounded usage.

• Place your fridge where it will not be exposed to direct sunlight.

• Your appliance should be at least 50 cm away from stoves, gas

ovens and heater cores, and at least 5 cm away from electrical

ovens.

• Your fridge should never be used outdoors or exposed to rain.

• When your fridge is placed next to a deep freezer, there should

be at least 2 cm between them to prevent humidity forming on

the outer surface.

• Do not place anything on your fridge, and install your fridge in

a suitable place so that at least 15 cm of free space is available

above it.

• Use the adjustable front legs to make sure your appliance is

level and stable. You can adjust the legs by turning them in either

direction. This should be done before placing food in the fridge.

• Before using your fridge, wipe all parts with a solution of warm

water and a teaspoon of sodium bicarbonate, then rinse with

clean water and dry. Place all parts in the fridge after cleaning.

• Install the plastic distance guide (the part with black vanes at

the rear) by turning it 90° (as shown in the gure) to prevent the

condenser from touching the wall.

• The refrigerator should be placed against a wall with a free space

not exceeding 75 mm.

Before Using your Fridge

• When using your fridge for the rst time, or after transportation,

keep it in an upright position for at least 3 hours before plugging

into the mains. This allows efcient operation and prevents

damage to the compressor.

• Your fridge may have a smell when it is operated for the rst time.

This is normal and the smell will fade away when your fridge

starts to cool.

BEFORE USING THE APPLIANCE

Information about New Generation Cooling Technology

Fridges with new generation cooling technology have a different

working system than static fridges. In normal fridges, humid air that

enters into fridge and the water vapor that comes out from the foods,

accumulates frost formation in freezer compartment. In order to melt

this frost, in other words defrost, the fridge has to be stopped. During

the stopping period, to keep the foods cold, user has to extract the

food to outside of fridge and user has to clear the ice during this

period.

In the fridges with new generation cooling technology, situation in

the freezer compartment is completely different. With the aid of fan,

cold and dry air is blown out through many points into the freezer

compartment. As a result of the homogenously blown cold air, even in

the spaces between shelves, foods are frozen equally and correctly.

On the other hand there will be no frost formation.

In the refrigerator compartment, there will be nearly same conguration

with freezer compartment. Air, that is emitted with the fan, located at

the top of refrigerator compartment, is cooled while passing through

the gap behind the air duct. At the same time, air is blown out through

the holes on the air duct so that cooling process is successfully

completed in the refrigerator compartment. Holes on the air duct are

designed such that the air distribution becomes homogenous in this

compartment.

As there is no air passage between freezer and refrigerator

compartment, there will be no odor mixing.

As a result of these, your fridge with new generation cooling

technology, gives you, ease of use beside the huge volume and

esthetic appearance.

This presentation is only for information about the parts of the appliance.

Parts may vary according to the appliance model.

THE PARTS OF THE APPLIANCE AND THE

COMPARTMENTS

Inhaltsverzeichnis

Sprachen:

Andere Vestfrost Kühlschrank Handbücher

Vestfrost

Vestfrost VC 21186 UF ZeroZone Bedienungsanleitung

Vestfrost

Vestfrost VCF 10180 NoFrost Bedienungsanleitung

Vestfrost

Vestfrost VR-FW916-1E0I Bedienungsanleitung

Vestfrost

Vestfrost VIC 11177 S Bedienungsanleitung

Vestfrost

Vestfrost VLS174A AC Bedienungsanleitung

Vestfrost

Vestfrost FW M Series Bedienungsanleitung

Vestfrost

Vestfrost VW18NFE00LX Bedienungsanleitung

Vestfrost

Vestfrost VCF 10144 TF Bedienungsanleitung

Vestfrost

Vestfrost VCF 13200 NoFrost Bedienungsanleitung

Vestfrost

Vestfrost CI 397 R Bedienungsanleitung

Vestfrost

Vestfrost VCF 10186 X Bedienungsanleitung

Vestfrost

Vestfrost VCF 10186-L Bedienungsanleitung

Vestfrost

Vestfrost VIUC 1082 Bedienungsanleitung

Vestfrost

Vestfrost VICF 11177 DOD NoFrost Bedienungsanleitung

Vestfrost

Vestfrost HOF KF 186 Bedienungsanleitung

Vestfrost

Vestfrost VC 1084 TT Bedienungsanleitung

Vestfrost

Vestfrost VW18NFE01B Bedienungsanleitung

Vestfrost

Vestfrost VR-FB373-2E1BG Bedienungsanleitung

Vestfrost

Vestfrost VC 20186 Bedienungsanleitung

Vestfrost

Vestfrost VF 473 EB Bedienungsanleitung

Vestfrost

Vestfrost VF566MSLV Bedienungsanleitung

Vestfrost

Vestfrost VR-FF375-2H0I Bedienungsanleitung

Vestfrost

Vestfrost R-138 Bedienungsanleitung

Vestfrost

Vestfrost MK 304 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
