Vestfrost VR-FB492-2H0P Bedienungsanleitung

No Frost Fridge-Freezer

Operation manual

Chłodziarko-zamrażarka

No Frost

Instrukcja obsługi

Vestavná chladnička

No Frost s mrazákem

Návod k obsluze

Vstavaná chladnička

No Frost s mrazničkou

Návod na obsluhu

VR-FB492-2H0P

VR-FB492-2H0I

VR-FB492-2H0B

EN-2

INDEX

BEFORE USING THE APPLIANCE ......................................................... 4

General warnings ............................................................................................. 4

Old and out-of-order refrigerators..................................................................... 7

Safety warnings................................................................................................ 7

Installing and operating your refrigerator.......................................................... 8

Before using your refrigerator........................................................................... 9

THE VARIOUS FUNCTION AND POSSIBILITIES ................................... 9

Information about New Generation Cooling Technology .................................. 9

Display and Control Panel.............................................................................. 10

Operating your refrigerator......................................................................................10

Freezer Temperature Settings.................................................................................10

Fridge Temperature Settings...................................................................................10

Super Freeze Mode ................................................................................................11

Temperature Adjustment Warnings ................................................................ 12

Accessories .................................................................................................... 12

The Icematic (In some models) .............................................................................12

The Freezer Box .....................................................................................................13

The Chiller Shelf (In some models) .......................................................................13

The Fresh Dial (In some models) ..........................................................................14

Adjustable Glass Shelf (In some models) .............................................................14

Purebeam Technology ...........................................................................................14

Maxi-fresh (If available)..........................................................................................15

ARRANGING FOOD IN THE APPLIANCE ............................................ 16

Fridge compartment ....................................................................................... 16

Freezer compartment ..................................................................................... 17

CLEANING AND MAINTENANCE ......................................................... 21

TRANSPORTATION AND CHANGING OF INSTALLATION

POSITION ............................................................................................... 22

Repositioning the Door................................................................................... 23

BEFORE CALLING YOUR AFTER SALES SERVICE........................... 23

Tips for saving energy .................................................................................... 27

THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........ 28

Dimensions..................................................................................................... 30

EN-3

Symbol ISO 7010 W021

Warning; Risk of fire / flammable materials

EN-4

BEFORE USING THE APPLIANCE

General warnings

WARNING: Keep the ventilation openings of the Fridge clear

from obstruction.

WARNING: Do not use mechanical devices or other means

to accelerate the defrosting process.

WARNING: Do not use other electrical appliances inside the

Fridge.

WARNING: Do not damage the refrigerant circuit.

WARNING: When positioning the appliance, ensure the

supply cord is not trapped or damaged.

WARNING: Do not locate multiple portable socket-outlets or

portable power supplies at the rear of the appliance.

WARNING: To avoid personal injury or damage this appliance

must be installed in accordance with the manufacturer

instructions.

If your appliance uses R600a as a refrigerant (this

information will be provided on the label of the cooler) you

should take care during transportation and installation to prevent

the cooler elements from being damaged. R600a is an

environmentally friendly and natural gas, but it is explosive. In

the event of a leak due to damage of the cooler elements, move

your freezer away from open flames or heat sources and ventilate

the room where the appliance is located for a few minutes.

• While carrying and positioning the freezer, do not damage

the cooler gas circuit.

• Do not store explosive substances such as aerosol cans with

a flammable propellant in this appliance.

• This appliance is intended to be used in household and

PART - 1.

EN-5

domestic applications

• If the socket does not match the appliance plug, it must be

replaced by the manufacturer, a service agent or similarly

qualified persons in order to avoid a hazard.

• A specially grounded plug has been connected to the power

cable of your appliance. This plug should be used with a

specially grounded socket of 16 amperes. If there is no

such socket in your house, please have one installed by an

authorised electrician.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision.

• Children aged from 3 to 8 years are allowed to load and

unload refrigerating appliances. Children are not expected

to perform cleaning or user maintenance of the appliance,

very young children (0-3 years old) are not expected to use

appliances, young children (3-8 years old) are not expected to

use appliances safely unless continuous supervision is given,

older children (8-14 years old) and vulnerable people can

use appliances safely after they have been given appropriate

supervision or instruction concerning use of the appliance. Very

vulnerable people are not expected to use appliances safely

unless continuous supervision is given.

• If the supply cord is damaged, it must be replaced by the

manufacturer, an authorised service agent or similar qualified

persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes exceeding 2000

EN-6

To avoid contamination of food, please respect the following

instructions:

• Opening the door for long periods can cause a significant increase

of the temperature in the compartments of the appliance.

• Clean regularly surfaces that can come in contact with food and

accessible drainage systems.

• Store raw meat and fish in suitable containers in the refrigerator,

so that it is not in contact with or drip onto other food.

• Two-star frozen-food compartments are suitable for storing pre-

frozen food, storing or making ice cream and making ice cubes.

• One-, two- and three-star compartments are not suitable for the

freezing of fresh food.

• If the refrigerating appliance is left empty for long periods,

switch off, defrost, clean, dry, and leave the door open to

prevent mould developing within the appliance.

EN-7

Old and out-of-order fridges or freezer

• If your old fridge or freezer has a lock, break or remove the lock before discarding it,

because children may get trapped inside it and may cause an accident.

• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,

take care not to harm environment when you are discarding your old fridges.

Disposal of your old appliance

The symbol on the product or on its packaging indicates that this product may not

be treated as household waste. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment. By ensuring

this product is disposed of correctly, you will help prevent potential negative

consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city office, your household

waste disposal service or the shop where you purchased the product.

Notes:

• Please read the instruction manual carefully before installing and using your appliance.

We are not responsible for the damage occurred due to misuse.

• Follow all instructions on your appliance and instruction manual, and keep this manual

in a safe place to resolve the problems that may occur in the future.

• This appliance is produced to be used in homes and it can only be used in domestic

environments and for the specified purposes. It is not suitable for commercial or common

use. Such use will cause the guarantee of the appliance to be cancelled and our company

will not be responsible for the losses to be occurred.

• This appliance is produced to be used in houses and it is only suitable for cooling / storing

foods. It is not suitable for commercial or common use and/or for storing substances

except for food. Our company is not responsible for the losses to be occurred in the

contrary case.

Safety warnings

• Do not connect your refrigerator to the mains electricity supply using an

extension lead.

• Do not use damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• Do not use plug adapter.

• This appliance is designed for use by adults. Do not allow children to

play with the appliance or hang off the door.

• Never touch the power cord/plug with wet hands. This may cause a short

circuit or electric shock.

EN-8

• Do not place glass bottles or cans in the ice-making compartment as

they will burst when the contents freeze.

• Do not place explosive or flammable material in your fridge. Place drinks

with high alcohol content vertically in the fridge compartment and make

sure their tops are tightly closed.

• When removing ice from the ice-making compartment, do not touch it. Ice may

cause frost burns and/or cuts.

• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes

immediately after they are removed from the ice-making compartment.

• Do not re-freeze thawed frozen food. This may cause health issues such as food

poisoning.

Installing and operating your fridge freezer

Before using your fridge freezer for the first time, please pay attention to the following points:

• The operating voltage for your fridge freezer is 220-240 V at 50Hz.

• The plug must be accessible after installation.

• Your refrigerator may have an odour when it is operated for the first time. This is normal

and the odour will fade when your refrigerator starts to cool.

• Before connecting your fridge freezer, ensure that the information on the data plate

(voltage and connected load) matches that of the mains electricity supply. If in doubt,

consult a qualified electrician.

• Insert the plug into a socket with an efficient ground connection. If the socket has no

ground contact or the plug does not match, we recommend you consult a qualified

electrician for assistance.

• The appliance must be connected with a properly installed fused socket. The power

supply (AC) and voltage at the operating point must match with the details on the name

plate of the appliance (the name plate is located on the inside left of the appliance).

• We do not accept responsibility for any damages that occur due to ungrounded usage.

• Place your fridge freezer where it will not be exposed to direct sunlight.

• Your appliance must never be used outdoors or exposed to rain.

• Your appliance must be at least 50 cm away from stoves, gas ovens and heater cores,

and at least 5 cm away from electrical ovens.

• If your fridge freezer is placed next to a deep freezer, there must be at least 2 cm between

them to prevent humidity forming on the outer surface.

• Do not cover the body or top of fridge freezer with lace. This will affect the performance

of your fridge freezer.

• Clearance of at least 150 mm is required at the top of your appliance. Do

not place anything on top of your appliance.

• Do not place heavy items on the appliance.

• Use the adjustable front legs to make sure your appliance is level and stable.

You can adjust the legs by turning them in either direction. This must be

done before placing food in the appliance.

• Clean the appliance thoroughly before use (see Cleaning and Maintenance).

EN-9

• Before using your fridge freezer, wipe all parts with a solution of warm water and a

teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts

to the fridge freezer after cleaning.

If your refrigerator includes a fan condenser

The condenser of your fridge is placed at the bottom

of cabinet. As a result of that, assemble the spacer

by fixing it to holes on the cover bottom panel and

turn 90° that’s shown below figure for arranging the

distance between the refrigerator and the back wall at

where you place the fridge. You can move the fridge

towards the back wall until that point.

The distance between the appliance and back wall

must be a maximum of 75 mm.

Before Using your refrigerator

• When using your fridge for the first time, or after transportation, keep it

in an upright position for at least 3 hours before plugging into the mains.

This allows efficient operation and prevents damage to the compressor.

• Your fridge may have a smell when it is operated for the first time. This is normal and

the smell will fade away when your fridge starts to cool.

Plastic for distance setting

THE VARIOUS FUNCTION AND POSSIBILITIES

Information about New Generation Cooling Technology

Refrigerators with new-generation cooling technology have a different operating system to

static refrigerators. Other (static) refrigerators may experience a build up

of ice in the freezer compartment due to door openings and humidity in

the food. In such refrigerators, regular defrosting is required; the

refrigerator must be switched off, the frozen food moved to a suitable

container and the ice which has formed in the freezer compartment

removed.

In refrigerators with new-generation cooling technology, a fan blows dry

cold air evenly throughout the fridge and freezer compartments. The

cold air cools your food evenly and uniformly, preventing humidity and

ice build-up.

In the fridge compartment, air blown by the fan, located at the top of the

fridge compartment, is cooled while passing through the gap behind the

air duct. At the same time, the air is blown out through the holes in the

air duct, evenly spreading cool air throughout the fridge compartment.

There is no air passage between the freezer and fridge compartments,

therefore preventing the mixing of odours.

As a result, your refrigerator, with new-generation cooling technology,

provides you with ease of use as well as a huge volume and aesthetic

appearance.

PART - 2.

EN-10

Display and Control Panel

Using the Control Panel

1. Enables the setting of the freezer.

2. Enables the setting of the fridge.

3. Freezer set value screen.

4. Fridge set value screen.

5. Economy mode symbol.

6. Super freeze symbol.

7. Alarm symbol.

Operating your Fridge Freezer

Once you have plugged in the product, all symbols will be displayed for 2 seconds and the

initial values will be shown as -18 °C on the freezer adjustment indicator, and +4 °C on the

fridge adjustment indicator.

Freezer Temperature Settings

• The initial temperature value for the freezer setting indicator is -18 °C.

• Press the freezer set button once.

When you first press the button, the previous value will blink on the screen.

• Whenever you press the same button, a lower temperature will be set (-16 °C, -18 °C,

-20 °C, -22 °C or -24 °C).

• If you continue to press the button, it will restart from -16 °C.

NOTE: Eco mode gets activated automatically when the temperature of the freezer

compartment is set to -18°C.

Cooler Temperature Settings

• The initial temperature value for the cooler setting indicator is +4 °C.

• Press the cooler button once.

• Whenever you press the button, a lower temperature will be set (+8 °C, +6 °C, +5 °C,

+4 °C, or +2 °C).

• If you continue to press the button, it will restart from +8 °C.

3 5 6 7 4

1 2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Vestfrost Kühlschrank Handbücher

Vestfrost

Vestfrost CI 397 R Bedienungsanleitung

Vestfrost

Vestfrost VFC 312 Bedienungsanleitung

Vestfrost

Vestfrost CW 286 WB Bedienungsanleitung

Vestfrost

Vestfrost CLF374E W Bedienungsanleitung

Vestfrost

Vestfrost VIC 11177 S Bedienungsanleitung

Vestfrost

Vestfrost CMR 085 W Bedienungsanleitung

Vestfrost

Vestfrost VF566MSLV Bedienungsanleitung

Vestfrost

Vestfrost R-90 Bedienungsanleitung

Vestfrost

Vestfrost HOF KF 186 Bedienungsanleitung

Vestfrost

Vestfrost VLS200 Installations- und Benutzerhandbuch

Vestfrost

Vestfrost VICF 105177 S Bedienungsanleitung

Vestfrost

Vestfrost CNF 379 X Bedienungsanleitung

Vestfrost

Vestfrost CW 286 W Bedienungsanleitung

Vestfrost

Vestfrost VR-BB27612H1S Bedienungsanleitung

Vestfrost

Vestfrost VCF 13186 NoFrost Bedienungsanleitung

Vestfrost

Vestfrost BBR150 Bedienungsanleitung

Vestfrost

Vestfrost CW 397 R Bedienungsanleitung

Vestfrost

Vestfrost R-138 Bedienungsanleitung

Vestfrost

Vestfrost VF 466 EW Bedienungsanleitung

Vestfrost

Vestfrost VW18NFE00LX Bedienungsanleitung

Vestfrost

Vestfrost CFKS 471 Bedienungsanleitung

Vestfrost

Vestfrost IRF 2761 E Bedienungsanleitung

Vestfrost

Vestfrost CI 383-0 M NF E A++ Bedienungsanleitung

Vestfrost

Vestfrost CX 283 B Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
