VEVOR 5609 Bedienungsanleitung

Technical Support and E-Warranty Certificate

www.vevor.com/support

SPARE TIRE CARRIER

USER MANUAL

We continue to be committed to provide you tools with competitive price.

"Save Half", "Half Price" or any other similar expressions used by us only represents an

estimate of savings you might benefit from buying certain tools with us compared to the major

top brands and doses not necessarily mean to cover all categories of tools offered by us. You

are kindly reminded to verify carefully when you are placing an order with us if you are

actually saving half in comparison with the top major brands.

- 1 -

Have product questions? Need technical support? Please feel free to

CustomerService@vevor.com

NEED HELP? CONTACT US!

This is the original instruction, please read all manual instructions

carefully before operating. VEVOR reserves a clear interpretation of our

user manual. The appearance of the product shall be subject to the

product you received. Please forgive us that we won't inform you again if

there are any technology or software updates on our product.

SPARE TIRE CARRIER

5609

- 2 -

1. Important Safety Instructions

Warning - To reduce the risk of injury, user must read

instructions manual carefully.

This symbol, placed before a safety comment, indicates a

kind of precaution, warning, or danger. Ignoring this warning

may lead to an accident. To reduce the risk of injury, fire, or

electrocution, please always follow the recommendation

shown below.

Danger!

Risk of personal injury or environmental damage! Risk of

electric shock! Risk of personal injury by electric shock!

Warning- Be sure to wear ear protectors when using this

product.

Warning- Be sure to wear eye protectors when using this

product.

Warning- Be sure to wear dust masks when using this

product.

Warning- Be sure to wear gloves when using this product.

1) Keep this manual for the safety warnings and precautions. The

manual offers important information on how to assemble, use and

maintain this product.

2) Dress appropriately.Never wear loose fitting clothing or jewelry when

working. And keep long hair, clothing and gloves away from moving parts.

3) Use common sense when working. Stay alert and concentrate when

assembling and using the Trailer Spare Tire Caralcohol.Do not assemble

or use when tired or when under the influence of alcohol, drugs or

medication.

- 3 -

4) While assembling and using the Trailer Spare Tire Carrier, keep work

area clean and well lighted. Keep spectators and children out of the work

area.

5) Do not exceed the 160 Lbs load capacity of Spare Tire Carrier .

6) Check wheels of trailer during the installation of this Spare Tire Carrier.

Make sure trailer is on a flat level solid surface

7) Be aware of the danger of “dynamicloading”.This situation arises

when a load is dropped onto the Spare Tire Carrier, resulting in a

short-term excessive load.

8) Dynamic loading can result in damage andfailure of the Spare Tire

Carrier and/or trailer,and personal injury to people in the area.

9) Periodically check the mounted Spare Tire Carrier to make sure all

hardware is tightly secured. Never use a damaged Spare Tire Carrier.

10) Spare Tire Carrier and spare tire location cannot interfere with normal

operation of the trailer.Carrier location cannot interfere with visibility of

trailer lights or license plate.

11) It is the responsibility of trailer’s owner to make sure the use of this

product conforms with all state rules and regulations.

12) Keep in mind that the warning previously discussed cannot cover all

possible events and circumstances.

3. Product Description

1) Name:SPARE TIRE CARRIER

2) Model:5609

3) G.W.: 0.45kg

4) Applicable for 4 or 5,6 cams

5) Load limit:160lbs

6) Zinc plated

- 4 -

4. Operations

1) Check the size:Put the U bolt through the suitable holes of the

wheel.Base width should be no more than 95mm and minimum not

less than 60mm.

2) Put the brackets into the U bolts,and screw it by bolt and nuts. See

picture below.

- 5 -

3) Screw the bending part one by one and get the suitable position,make

the 2 holes together, and you can lock the bending part hole to

prevent lost.

Attention:

1. Not recommended for heavy tires. By using it, please tighten all

screws, and need help. it’s dangerous for one people to finish the

work.

2. Recommended for use in stable places,if you need to use in moving

places, make sure the base have a suitable base size and make safe.

3. You should prepare the lock youself.

- 6 -

Address：Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi

Shanghai

Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD

NSW 2122 Australia

Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim

Place, Rancho Cucamonga, CA 91730

REP

Pooledas Group Ltd

Unit 5 Albert Edward House, The Pavilions

Preston, United Kingdom

REP

SHUNSHUN GmbH

Römeräcker 9 Z2021, 76351

Linkenheim-Hochstetten, Germany

Made In China
