Victure PV530 Bedienungsanleitung
3
Product introduction
1. Photoresistor
2. Lens
3. Microphone
4. Infrared lamp
5. Power indicator
6. Reset button
7. SD card slot
1
2
36
7
5
4
EN
4
Instructions for use of software
IPC360 is an application software for the camera on mobile devices. It
supports both iOS and Android system. You can achieve remote
control and video acquisition on mobile devices through the software.
Scan the QR code below or search "IPC360" in App store (for Apple
users) and Google Play (for Android users) and download the latest
version of APP.
User registration/login
Download APP
or
IPC360
IPC360
Download
EN
5
1
3
4
2
1.Registration
Once the APP is downloaded, you can register an account. Only
mailbox registration is currently supported.
Click Register to select country or region where you are located;
Enter your e-mail address and verification code received in the
mailbox and click Next;
Set your password and repeatedly input the password for confirma-
tion. Make sure the password you entered is consistent with password
you have set. Click Register to complete the registration.
Register, login and retrieve password
Experience
sign in
sign up Forgot password?
·
·
·
EN
6
2.What if you forgot password
If you forget the password or the password is stolen, please modify the
password in time in “Forget Password” .
Click Forget Password and select country or region where you are
located;
Enter your register email address. Click to get verification code, obtain
the verification code from your register email box and enter the code;
Set a new password and repeatedly input the new password to
complete password modification
Log in by using the new password.
·
·
·
·
3.Login
Enter your register email into the column “Account Number” . Input
the corresponding password in the column “Password” . Click
Register and proceed with the next step.
4.Click "Experience Right Now" to experience the imaging effect of
various installation modes in advance, so as to better select the
installation mode and camera model.
EN
7
·
·
·
·
Warm tips:
Passwords can only be 6-16 alphanumeric combinations,
case-sensitive.
You can click “ ” in the password bar and select on/ off
password in visual state.
The mobile phone number and mailbox must be authen-
tic and valid. Currently, the mobile number registration is
not supported temporarily in the areas other than main-
land China.
An exclamation mark in the camera list indicates that the
current mobile phone number and the device are not
logged in on the same server. It is required to click Play
the Device, and the APP will automatically change the
server after confirmation by user, and the device can be
watched normally.
EN
8
Add camera
Camera power startup
Connect the camera with the power adapter by using a USB charging
cable.
After the camera is connected with the power supply, the start-up is
completed (the indicator light will turn red and flash in green). If the
red light does not flash, press RESET button for 3-4 seconds and the
camera will rotate up and down and side to side and the red light will
flash or emit the "Beep" sound, indicating that the camera has been
started.
After the power supply has been successfully started up, the device
can be added by clicking [+] in the upper right corner of "My Camera"
(please select the right adding method according to the actual situa-
tion).
·
·
·
My camera
No camera,add by +
EN
9
Add camera in a wired way
Provide the camera with network access by connecting it to a router
via network cable.
Select the Wired Add. According to the prompt in APP, insert one end
of network cable into the Ethernet interface of machine, and the other
end to the router, and the mobile phone shall be simultaneously
connected with WIFI network sent by the same router.
When connection is completed, perform “Search” . After search is
successful(the list indicating MAC address of the wired equipment),
click MAC address of the device and “Add this device” , and the
device sends sound “Tinkling” , and the indicator light turns green.
The camera broadcasts “Connected to the Internet” (green light flash-
es), indicating that the addition is successful. To name the device, you
can name it or skip the step (the name cannot contain a special
symbol).
Make 360 ° panoramic shooting or skip this step. If 15 pictures had
been taken, you can then view the pictures on your phone.
·
·
·
·
EN
10
Wireless connection
Pair the camera with WIFI (5G band network pairing is not supported
temporarily).
After confirming that the mobile phone has been provided with stable
WIFI, select the wireless addition. Confirm that the camera has been
successfully started, and then click Next. If starting is not successful,
repeat the above-mentioned power-start steps; enter the password for
the WIFI that mobile phone currently connects (click on “ ” on the
right side of the column Password to show or not show the password),
and click Next.
Select the country where you are currently located. Adjust the volume
of mobile phone and approach the camera as far as possible, and click
Next.
At this time, the mobile phone will emit sound wave for addition, and
click the Next Step after hearing “Tinkling” sound from the camera,
and the wait prompt is provided according to the time at the lower
part of APP.
The camera broadcasts “Connected to the Internet” (green light flash-
es), indicating that the addition is successful. To name the device, you
can name it or skip the step, and if the step is skipped , APP will auto-
matically generate a name for a number.
Make 360 ° panoramic shooting or skip this step, if 15 pictures had
been taken, you can then view the pictures on your phone.
·
·
·
·
·
EN
11
·
·
·
·
·
·
Warm prompt:
The camera currently supports only 2.4GHz Wi-Fi network.
The camera can support (max.) 64G SD card, and is not
allowed to pull out or insert into the SD card when ener-
gized.
If, during wireless connection, the connection fails, repeat
the normal operation without restarting or resetting. You
can try replacing the WIFI network.
When the camera is provided with power supply and SD
card, the monitored motion will be automatically recorded
and stored in the SD card; if no SD card is inserted, the
video can also be recorded directly by the APP (the alarm
function is available even if no SD card is provided).
The name of camera does not allow for special symbols.
The RESET key is located at the SD card slot at the lower
end of the camera.
EN
