English - Instruction manual

ENGLISH

MAXIMUS MVXHD

High-spec ex-proof HD camera in a compact design

Manual B

EN - English - Instruction manual

2 MNLCMVXHDCAM_2222_EN

Contents

ENGLISH 1

1 About this manual....................................................................................................................3

1.1 Typographical conventions ................................................................................................................................................ 3

2 Notes on copyright and information on trademarks............................................................3

3 Product description and type designation............................................................................3

3.1 Product marking label.......................................................................................................................................................... 3

4 Installation................................................................................................................................4

4.1 Range of use............................................................................................................................................................................. 4

4.2 Connecting the power supply .......................................................................................................................................... 4

4.3 Ethernet cable connection................................................................................................................................................. 5

4.4 I/O cable connection ............................................................................................................................................................ 5

4.4.1 Alarm and relay connections.............................................................................................................................................................. 5

4.4.1.1 Connecting an alarm with dry contact...................................................................................................................................................................5

4.4.1.2 Relay connection ............................................................................................................................................................................................................6

4.5 Washing system connection.............................................................................................................................................. 6

5 Switching on .............................................................................................................................6

5.1 Before powering the product in an explosive atmosphere ................................................................................... 6

5.2 First start-up............................................................................................................................................................................. 6

6 Conﬁguration............................................................................................................................ 7

6.1 Default IP address .................................................................................................................................................................. 7

6.2 Web interface .......................................................................................................................................................................... 7

6.2.1 First access to the web pages............................................................................................................................................................. 7

7 Accessories................................................................................................................................7

7.1 Inserting an SD Card.............................................................................................................................................................. 7

8 Maintenance .............................................................................................................................8

8.1 Factory Default........................................................................................................................................................................ 8

9 Information on disposal and recycling ..................................................................................9

10 Troubleshooting.....................................................................................................................9

11 Technical data....................................................................................................................... 10

11.1 Cameras.................................................................................................................................................................................. 10

Instruction manual - English - EN

3MNLCMVXHDCAM_2222_EN

1 About this manual

Read all the documentation supplied carefully

before installing and using this product. Keep the

manual in a convenient place for future reference.

This document has been compiled and published

using product descriptions and speciﬁcations

available at the time of publication. The contents

of this document and the speciﬁcations of the

products discussed herein are subject to change

without notice. Pelco Inc. reserves the right to make

any such changes without notice. Neither Pelco Inc.

nor any of its aﬃliated companies: (1) guarantees

the completeness or accuracy of the information

contained in this document; or (2) is responsible for

your use of, or reliance on, the information. Pelco Inc.

shall not be responsible for any losses or damages

(including consequential damages) caused by

reliance on the information presented herein.

For greater certainty, the use of "manufacturer" in

this manual means "VIDEOTEC s.r.l.".

1.1 Typographical conventions

DANGER!

High level hazard.

Risk of electric shock. Disconnect the

power supply before proceeding with any

operation, unless indicated otherwise.

DANGER!

Explosion hazard.

Read carefully to avoid danger of

explosion.

CAUTION!

Medium level hazard.

This operation is very important for the

system to function properly. Please read

the procedure described very carefully

and carry it out as instructed.

INFO

Description of system speciﬁcations.

We recommend reading this part carefully

in order to understand the subsequent

stages.

2 Notes on copyright and

information on trademarks

The mentioned names of products or companies are

trademarks or registered trademarks.

Pelco, the Pelco logo, and other trademarks

associated with Pelco products referred to in this

publication are trademarks of Pelco, Inc. or its

aﬃliates.

Other names or logos mentioned herein may be the

trademarks of their respective owners.

The absence of the symbols ™ and ® in proximity to

each trademark in this document or at all is not a

disclaimer of ownership of the related trademark.

ONVIF® is a trademark of Onvif, Inc.

3 Product description and

type designation

3.1 Product marking label

See the label attached to the product.

EN - English - Instruction manual

4 MNLCMVXHDCAM_2222_EN

4 Installation

CAUTION! Device installation and

maintaining must be performed by

specialist technical staﬀ only.

The external multipolar cable shield

(armour) must be earthed.

All disconnected wires must be electrically

isolated.

During installation of the version with

multipolar cable, ensure there is 200mm

of open space at the back of the housing to

guarantee correct curvature of the cable.

4.1 Range of use

For indoors and outdoors installation.

Operating temperature:

• Continuous working: from -50°C (-58°F) up to

+65°C (149°F).

• Cold start: up to -40°C (-40°F).

Relative humidity: from 10% up to 95% (no

condensation).

4.2 Connecting the power supply

Electrical connections must be performed

with the power supply disconnected and

the circuit-breaker open.

When commencing installation make

sure that the speciﬁcations for the power

supply for the installation correspond with

those required by the device.

Check that the power supply is adequately

dimensioned.

The device can be provided with diﬀerent power

supply voltages. The power supply voltage is

indicated on the product identiﬁcation label (3.1

Product marking label, page 3).

Perform the connections following the instructions

reported in the table .

CONNECTING THE POWER SUPPLY

Power supply 24Vac/ 24Vdc/ 12Vdc

Colour/Number Description

24Vac 24Vdc/12Vdc

Black/1 ~V+

Black/2 ~V-

Yellow-Green

Tab. 1

Instruction manual - English - EN

5MNLCMVXHDCAM_2222_EN

4.3 Ethernet cable connection

The Ethernet cable shield must always be

earthed via the connector. Always use a

shielded RJ45 connector.

Use of Ethernet cables with the following

characteristics is highly recommended:

• STP (shielded)

• Category 5E

• RJ45 connector (crimped in compliance with

standard TIA/EIA-568-B)

The product can be directly connected to an

Ethernet switch.

ETHERNET CABLE CONNECTION

Pin number Core colour

1Orange-White

2Orange

3Green-White

4Blue

5Blue-White

6Green

7Brown-White

8Brown

Tab. 2

The example below shows a typical installation.

Switch

Personal

Computer

Fig. 1

4.4 I/O cable connection

CAUTION! TNV-1 installation type. The

installation is type TNV-1, do not connect it

to SELV circuits.

The shielding of the I/O cable must be

grounded.

I/O CABLE CONNECTION

Colour Function

White RS-485 A (+)

Yellow RS-485 B (-)

Pink Relay 1, Terminal A

Blue Relay 1, Terminal B

Brown Alarm/Digital input

Green GND/Common alarm

Grey Reset

Tab. 3

4.4.1 Alarm and relay connections

The unit is equipped with the alarms and relays

indicated in the table (Tab. 3, page 5).

4.4.1.1 Connecting an alarm with dry

contact

In case of free contact alarm make the connection as

shown in the ﬁgure.

AL COM

Dry contact

Fig. 2AL: Alarm. COM: Common alarm.

Clean contact of the alarm can be set NO (normally

open) or NC (normally closed) using the web

interface.

EN - English - Instruction manual

6 MNLCMVXHDCAM_2222_EN

4.4.1.2 Relay connection

Each relay is usable with the speciﬁcations

described below.

• Working voltage: up to 30Vac or 60Vdc.

• Current: 1A max.

Use suitable cable sections with the

following characteristics: from 0.2mm²

(30AWG) up to 1mm² (16AWG).

Due to the absence of polarity, both terminals of the

same relay can be connected either to alternating or

direct current voltages.

4.5 Washing system connection

For further details on conﬁguration and

use, refer to the relative manual.

5 Switching on

Do not turn on the unit when the ambient

temperature is lower than indicated: -40°C

(-40°F).

The full functionality of the product is

guaranteed from the following ambient

temperature: -40°C (-40°F).

The automatic pre-heating procedure

(De-Ice) activates for 2 hours if on device

switch on an ambient temperature is

detected under -10°C (14°F). The procedure

is necessary to guarantee correct

operation of the devices even at low

temperatures.

5.1 Before powering the product

in an explosive atmosphere

Make sure that the unit and other

components of the installation are closed

so that it is impossible to come into

contact with live parts.

Make sure that the device has been

connected to an earth link as described.

Ensure the rear cover plate is correctly

closed.

Ensure the product is correctly closed.

Ensure that the sealing of cable entry

systems (if any) has been performed

properly and the time of glue hardening

has been observed.

Make sure that all parts are fastened down

ﬁrmly and safely.

5.2 First start-up

Ensure the unit and the other components

of the system are appropriately closed to

prevent contact with live parts.

Make sure that all parts are fastened down

ﬁrmly and safely.

The unit is switched on by connecting the power

supply.

To switch oﬀ the unit disconnect the power.

Instruction manual - English - EN

7MNLCMVXHDCAM_2222_EN

6 Conﬁguration

6.1 Default IP address

The unit is conﬁgured to obtain an IP

address from a DHCP server.

The IP address acquired via DHCP is visible in the

DHCP server log ﬁle.

If the DHCP server is not available, the unit

automatically conﬁgures itself with a self-generated

IP address in the 169.254.x.x/16 subnet. Conﬁguring

the IP address of the PC as belonging to the same

subnet (example: IP address: 169.254.1.1, subnet

mask: 255.255.0.0).

Use an ONVIF compliant VMS or the Motorola

Solutions Camera Conﬁguration Tool to ﬁnd the IP

address of the device.

6.2 Web interface

Browsers supported (the latest version):

Microsoft Edge, Google Chrome, Mozilla

Firefox.

6.2.1 First access to the web pages

The ﬁrst operation in conﬁguring the device consists

in connecting to the web interface.

To access the web interface of the product, simply

use a browser to connect to http://ip_address.

On ﬁrst access, the Home page will be displayed.

Additional information about setting up and using

the device is available in:

www.pelco.com/exsite-enhanced-2

7 Accessories

For further details on conﬁguration and

use, refer to the manual of the relevant

accessory or support.

7.1 Inserting an SD Card

For instruction about opening and closing

the camera, please refer to Manual A.

To allow video archiving in the device, insert an

industrial grade microSD card in the slot.

Fig. 3

EN - English - Instruction manual

8 MNLCMVXHDCAM_2222_EN

8 Maintenance

The pre-installed camera can only be

replaced with one of the same brand and

model.

Read the product Manual A before

performing any operation.

Please provide the device serial number when

requesting any replacement parts.

8.1 Factory Default

It is possible to reset to the factory default settings.

Execute the procedure below:

• Power the unit.

• Wait for 3 minutes.

• Connect the I/O cable grey and green wires (Tab.

3, page 5).

• Wait for 3 minutes.

• Switch oﬀ the unit.

• Disconnect the previously connected green and

grey wires.

• Power the unit.

Instruction manual - English - EN

9MNLCMVXHDCAM_2222_EN

9 Information on disposal

and recycling

The European Directive 2012/19/EU on Waste

Electrical and Electronic Equipment (WEEE)

mandates that these devices should not be disposed

of in the normal ﬂow of municipal solid waste, but

they should be collected separately in order to

optimize the recovery stream and recycling of the

materials that they contain and to reduce the impact

on human health and the environment due to the

presence of potentially hazardous substances.

The symbol of the crossed out bin is

marked on all products to remember this.

The waste may be delivered to appropriate

collection centers, or may be delivered free of

charge to the distributor where you purchased

the equipment at the time of purchase of a new

equivalent or without obligation to a new purchase

for equipment with size smaller than 25cm (9.8in).

For more information on proper disposal of these

devices, you can contact the responsible public

service.

10 Troubleshooting

Contact an authorized support centre

if the problems listed below persist or

you have any other issues that are not

described here.

Read the product Manual A before

performing any operation.

PROBLEM Video streaming is not

visible.

CAUSE Incorrect IP address settings.

SOLUTION Check the device IP address

and the conﬁguration of the

computer network card.

CAUSE Automatic preheating

procedure (De-Ice) in progress.

SOLUTION Wait until the end of the

pre-heating procedure. If the

ambient temperature is too low

the unit will remain blocked.

PROBLEM The wash system is blocked

and does not respond to

commands.

CAUSE The wash system is not

enabled.

SOLUTION Check the conﬁguration of the

settings.

PROBLEM The wash system settings are

incorrect.

CAUSE Wrong settings in the

conﬁguration.

SOLUTION Check the conﬁguration of the

settings.

MNLCMVXHDCAM_2222_EN

11 Technical data

For the technical data of the housing,

consult Manual A of the product.

11.1 Cameras

Resolution: Full HD 1080p (1920x1080pixel)

Image Sensor: 1/2.8" Progressive Scan CMOS

Focal length: from 4.3mm (wide) up to 129mm (tele)

Zoom: 30x

Max Aperture: F1.6

Horizontal Angle of View Based on Aspect Ratio:

(16:9) 2.3°-66°

Electronic Shutter Control: Automatic, Manual

White balance: Automatic, Manual

Wide Dynamic Range: 120dB

Exposure Control: Automatic, Manual, Priority (Iris

Priority, Shutter Priority), Brightness, Custom

De-fog: On/Oﬀ

Privacy Zones

Day/Night Control: Automatic, Manual

Flicker Control: 60Hz, 50Hz

Backlight Compensation: On/Oﬀ

Headquarters Italy VIDEOTEC s.r.l.

Via Friuli, 6 - I-36015 Schio (VI) - Italy

Tel. +39 0445 697411 - Fax +39 0445 697414

Email: [email protected]

www.videotec.com

Andere Handbücher für MAXIMUS MVXHD

Inhaltsverzeichnis

Andere Videotec Sicherheitskamera Handbücher

Videotec

Videotec ulisse netcam Bedienungsanleitung

Videotec

Videotec ulisse2 Bedienungsanleitung

Videotec

Videotec MAXIMUS MVXHD Bedienungsanleitung

Videotec

Videotec NXPTZ DELUX Bedienungsanleitung

Videotec

Videotec ULISSE COMPACT DELUX Bedienungsanleitung

Videotec

Videotec ULISSE COMPACT Bedienungsanleitung

Videotec

Videotec ULISSE Bedienungsanleitung

Videotec

Videotec MAXIMUS MPX Series Bedienungsanleitung

Videotec

Videotec MAXIMUS MPX SERIES2 Bedienungsanleitung

Videotec

Videotec ULISSE RADICAL PTZ Bedienungsanleitung

Videotec

Videotec Ulisse Compact HD Bedienungsanleitung

Videotec

Videotec Ulisse Evo Bedienungsanleitung

Videotec

Videotec Ulisse Compact HD Bedienungsanleitung

Videotec

Videotec MAXIMUS MPX Bedienungsanleitung

Videotec

Videotec ULISSE MAXI NETCAM Bedienungsanleitung

Videotec

Videotec ULISSE RADICAL 18x Bedienungsanleitung

Videotec

Videotec ULISSE MAXI Bedienungsanleitung

Videotec

Videotec Ulisse Evo Bedienungsanleitung

Videotec

Videotec MAXIMUS MPX Series Bedienungsanleitung

Videotec

Videotec MEDUSA Bedienungsanleitung

Videotec

Videotec MAXIMUS MPX Bedienungsanleitung

Videotec

Videotec PELCO MAXIMUS MPX Series Bedienungsanleitung

Videotec

Videotec MAXIMUS MMX Bedienungsanleitung

Videotec

Videotec EXHC series Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
