Viking RDSOE306SS Bedienungsanleitung
F20701 EN
®
(092909J)
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
ca 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
Viking Installation Guide
Designer Oven Accessory
Flush Mount Kit
2 3
Removing Existing Trim Removing Existing Trim
Remove the two existing side trim pieces from the oven. There shou d be one trim piece on
each side of the oven.
NOTE: Keep the screws that are left after removing the existing side trim pieces. These
screws will be used to install the flush mount accessory trim pieces.
DSOE
Single Oven
DDOE
Double Oven
54
Insta ing F ush Mount Trim Insta ing F ush Mount Trim
After removing the existing side trim pieces, insta the two f ush mount trim pieces to the oven.
1. Remove the protective p astic from the f ush mount trim pieces.
2. Insta the two f ush mount trim pieces to the oven (see diagram for sing e and doub e oven
insta ation.)
NOTE: There will be a designated right and left hand side flush mount trim piece. Install
the corresponding trim piece on the correct side, as they are not interchangeable.
3. After insta ing the f ush mount trim pieces, the oven can be insta ed in the cutout.
DSOE
Single Oven
DDOE
Double Oven
76
