Vintec VWCM149FAB Bedienungsanleitung
Quickstart Guide
Before turning your cabinet on
SPACER
Install spacer at the back of the cabinet.
LEVEL
Level your wine cabinet before loading. Un-levelled cabinets
can be noisy, and doors may not close or seal properly.
FILL
Fill the cabinet with bottles before you turn it on. If you don’t
have enough bottles, spread them evenly throughout the cabinet.
TEMPERATURE
Check desired temperature setting (43°F-46°F or 6°C-8°C for serving white, 54°
F-57°F or 12°C-14°C for all cellaring, and 61°F-64°F or 16°C-18C° for serving red).
after transport to allow refrigerant gases to settle.
DO NOT SWITCH ON FOR
AT LEAST 24 HOURS
FOR ALL MODELS:
DO NOT place a door in front of
cabinets or put them in a closed
conned space (eg. small rooms such
as pantries, closets or under staircases)
DO NOT place cabinets near heat
sources such as ovens
DO NOT place cabinets outdoors
DO NOT expose cabinets to moisture
or rain
DO NOT put cabinets in direct sunlight
Installation and ventilation
WARNING: You MUST
refer to model-specic
ventilation requirements
listed in the user
manual or on the Vintec
website when installing
your cabinet.
See user manual for
model-specic dimensions
FREQUENT FAN CYCLE
This ensures slow and even distribution of cool air
throughout the cabinet, limiting temperature variations.
SPACER/STOPPER
Ensures adequate ventilation behind unit.
WATER ON THE DOOR OR FLOOR
In hot/humid climates and particularly on hot days, humidity
in the ambient air can condense on the cabinet’s cold glass door.
ICE FORMING
If the door seal is compromised or left slightly ajar the compressor
will keep running which may cause ice formation on the back wall.
Have you noticed:
Storing and stacking
Different shapes and sizes
When quoting capacity, Vintec refers to all standard
bottle shapes shown below.
Wine producers use a wide range of different
bottles. The unique design of Vintec shelves allow
for storing and stacking of most dimensions and
proportions.
Wine varietal bottle shapes
Stacking for accessibilityStacking for cellaring
Shelf top viewShelf top view
DRINKING
CELLARING
CELLARING
CELLARING
CELLARING
CELLARING
DRINKING
DRINKING
DRINKING
DRINKING
DRINKING
CASE 1
1
1 1
1
1 1
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
CASE 5
CASE 2
CASE 4
CASE 3
CASE 3
CASE 4
CASE 2
CASE 5
CASE 1
CASE 1
Shelf front viewShelf front view
Stack bottles you wish to cellar at the back
of shelves, and wines for consumption at the
front.
Keep bottles from the same case together
in vertical stacks for safe and easy access
to all your different wines.
Getting started
The MODE button toggles through the
temperature zones.
S: Single zone temperature mode sets the upper and
lower zones to a single temperature.
M: In Multi-Temp mode the cabinet creates a
temperature gradient, allowing you to arrange wines
from top-to-bottom at the appropriate serving
temperatures for each bottle in your collection.
CE: Cellaring mode sets the entire wine cellar to a
preset 54° F (shows “CE” in upper and lower temp).
The LIGHT button toggles lights ON and OFF.
Press and hold to toggle for 5 seconds to
change lighting settings when open and closed.
1A: Bright when open. Dim when closed.
2A:Bright when open. Off when closed.
3A:Always On.
4A: Dim when open. Bright when closed.
The perfect serving temperature for wines
43° to 46° F:
Sauvignon Blanc & Champagne
50° to 54° F:
Chardonnay
57° to 59° F:
Pinot Noir & Merlot
62° to 64° F:
Cabernet Sauvignon & Syrah
54° F:
Recommended
temperature for cellaring
all wine varietals
FILTER: The lter icon will illuminate when lter needs to be changed. Simultaneously press and
hold Mode and Lower Zone “∨” buttons for 5 seconds to turn off alert. Consult the Use & Care
Guide for more information.
FILTER
Display
Red
Varietals
64ºF
63ºF
62ºF
61ºF
60ºF
65ºF
Champagnes &
Whites
53ºF
51ºF
49ºF
47ºF
45ºF
55ºF
Champagnes,
Whites & Reds
61ºF
57ºF
53ºF
49ºF
45ºF
65ºF
Store at Serving Temperature
Cellaring
Mode
54ºF
54ºF
54ºF
54ºF
54ºF
54ºF
Multi-Temp provides exibility to store all your varietals at a perfect serving
temperature. In Multi-Temp mode, the cabinet creates a vertical temperature
gradient, allowing you to arrange wines from top-to-bottom at the appropriate
serving temperatures for each bottle in your collection. Refer to the diagrams
to understand how the Multi-Temp feature distributes the temperature gradient
based on settings.
Multi-Temp
* Conditions apply to member benets – see vintecclub.com for details.
Welcome,
And Thank You for choosing
a VINTEC Wine Cabinet to store,
display and share your treasured
collection. You’ve made a great
choice.
As a sign of our appreciation, we’d like to
invite you to become a member of the
VINTEC CLUB. A vibrant Wine Community
and Exclusive Club for owners of VINTEC
Wine Cabinets.
VINTEC CLUB members are entitled to very
special wine industry services and benefits,
including intimate dinners and tastings in the
company of Celebrated Winemakers and
Chefs from around the world.
We have created the VINTEC CLUB for
our discerning and valued customers who
invariably love wine, and it will be our
pleasure to welcome you as a member.
Your Vintec Club Concierge.
MEMBER BENEFITS:
• Invitations to VINTEC CLUB Private
Tastings, exclusive to members
• One additional year warranty* if
registration occurs within 60 days
from purchase
• Premium access to our proprietary
OENO Virtual Cellar Management
App
• Access to Member-Only Content
PLUS ACCESS TO:
Exclusive
Wine
Offers
Expert
Advice
Library
Personal
Concierge
Service
