Vision grills RL-K17F1M4 Handbuch
Step 1a:
Loosen the (4) outer bolts slightly so
as to allow for the Holster body to
slide into the gap between the bolt
heads and the leg bars.
• Remove bolts, washers and
locking washers from the three “X”
connectors.
• Remove paper washers and begin
assembling the “X” connectors and
legs.
• Please Note: Top, Middle & Bottom
“X” connectors must be assembled
simultaneously.
• Assemble cart by inserting the three “X” connectors into leg
ends and install bolts and washers in the same order they were
removed from “X” connectors.
• While assembling, only nger-tighten bolts to allow for
adjustment in cart. Otherwise it can be difcult to get all the
bolts inserted.
• Screw in Standard Rubber Wheels to rear Cart Legs and the
Locking Rubber Wheels to the front Cart Legs.
• Once Cart is assembled, ip cart over so that bolts are exposed.
ENGLISH
SET UP
Model #s RL-K17F1M4 / RL-W20D1L5-1 / Laguna
SIGNATURE SERIES
GOURMET
Parts for Assembly:
3 pcs. - “X” Leg Connectors
A
B
C
I
J
F
H
K
L
1 pc. - Electric Starter
Holster
M
E
2 pcs. - Side Shelves
N
4 pcs. - Cart Legs
1 pc. - Charcoal Grate
1 pc. - Fire Bowl
1 pc. -
Top Flip Grate
1 pc. - Wood Handle
1 pc. - Top Vent
D
Grate Lifting Tool
1 pc. - Kamado Grill
G
1 pc. -
Cast Iron Grate
Cooking Stone &
Bracket
Grill Light
Step 1: Cart Assembly STEP 1STEP 1
Shown here is
the bottom of the
cart, flipped upside down
Step 1b:
With opening of Holster facing the
front of the cart (the Locking Wheels)
slide.
Step 1c:
Slide Holster back into place.
Step 1d:
Using provided T-Handle Wrench,
tighten bolts again through hole
openings in bottom of Holster.
• Once
Holster is secure, ip cart back over to proper position
so that it is resting on Wheels. Continue Grill Assembly.
Tools Included:
T-Handle Wrench
Flat WrenchBox Wrench:
For shelf assembly
G*
1 pc. -
Bottom Flip Grate
*Laguna Only
Step 6: Lava Stone & Bracket Assembly
• Open grill and take off grill grates to expose re bowl.
• Spread bracket so it makes an “X” shape and lower into re bowl,
allowing the bracket to rest on edge of re bowl.
• Lower Lava Stone onto the bracket.
STEP 6
Step 3: Handle and Side Shelf Mounting
• To assemble handle, remove nuts and washers from bolts welded on the top
banding opposite the hinge.
• Remove paper washers and attach handle bracket over studs. On each stud
place a at washer and an acorn nut, then tighten (Step 3).
•
Mount side shelves by inserting the shelf rod into the shelf bracket. Tilting the shelf
up slightly and sliding in or out allows you to deploy the shelves.
STEP 3
Step 4: Grill Assembly
• Take all parts out of grill before lifting. The grill is heavy and will require two people
to lift and guide the Kamado into cart.
• Be sure the ProZoneTM is centered between the two front legs and the grill is resting
against the two back legs.
• Lower re bowl into grill with the ash drawer opening lined up with the opening in the
main ceramic body. Place cast iron charcoal grate with attached starter pocket into
re bowl (Step 4). Align tabs of starter pocket with electric starter port in re bowl.
Step 2: Shelf Brackets
• Remove nuts and washers from bolts welded on the bottom banding
and remove paper washers.
• Mount shelf brackets over studs with bracket slots facing up. Brackets
are stamped on the back with letters indicating their position (e.g.,
LF=Left Front and RB=Right Back).
• Mount at washer then acorn nut on each stud and tighten with wrench
provided.
STEP 2
STEP 4
Step 5: Install Grill Light
• Remove nut and washer from the rst bolt
on right side of bottom banding.
•
Slide exible light bracket over bolt, then
replace washer and bolt and tighten (Step
5a) and
insert exible light into bracket
and tighten knob (Step 5b).
STEP 5a STEP 5b
STEP 9b
• Place cooking grates onto grill with hinged section facing
towards front of grill.
• Close lid and press top vent onto grill with calibrations
facing the front (Step 7).
STEP 9a Step 9: Ash Drawer Usage
• Once grill is cool, it is safe to remove ash from Ash Drawer.
• (Step 9a) Using bottom knob on ProZoneTM, lift slightly and (Step 9b) pull
drawer out.
• Once ashes are emptied, reinstall by pushing ProZoneTM back into grill
body until it drops down back into place.
WARNING: ALWAYS WAIT FOR ASHES TO COOL BEFORE REMOVING ASH
DRAWER. NEVER PULL OUT ASH DRAWER WHILE GRILL IS HOT.
Step 8: Using the Electric Starter
• Place required amount of charcoal inside re bowl and completely open
bottom and top vents to maximize air ow.
• Flip open electric starter door and insert electric starter as far in as
possible. Plug in electric starter.
• Wait until edges of charcoal turn white and ames are licking the mound
of charcoal. On average it takes 8-12 minutes to start charcoal.
• Unplug starter and remove from ProZoneTM. Be careful when removing
electric starter, the element will be very hot. After use, let element rest on
support and cool completely away from children and pets.
NOTE: Do not plug the electric starter in while it is raining unless you’re in a safe and securely covered area.
Step 7: Complete Assembly
Long-Term Maintenance
• Cover your grill when not in use to extend life and
maintain appearance.
• When moving grill, always pull by the back hinge.
STEP 7
Step 10: Removing Cast Iron Grate
• Use provided Grate Removal Tool to lift out Cast Iron Grate
by centering the prongs of the tool in between the center
grate bars closest to the Vision Grills logo.
• When prongs are pushed all the way forward, lean Tool
back against grate and lift up. Use caution, Cast Iron Grate
is heavy.
Visit
www.visiongrills.com/register
to register your grill.
PARTS
ENGLISH
PART NAMES PART NUMBERS
1 Cast Iron Top Vent
Stainless Steel Top Vent
1.1 Bakelite Tab
1.2 Smoker Knob
2 Ceramic Dome Lid
2.1 Thermometer
3 Top Ring Assembly
4 Ceramic Dome Bottom
5 Bottom Ring Assembly
5.1 Right Front Side Shelf Bracket
(with nuts & washers)
5.2 Right Back Side Shelf Bracket
(with nuts & washers)
5.3 Left Front Side Shelf Bracket
(with nuts & washers)
5.4 Left Back Side Shelf Bracket
(with nuts & washers)
6 Cast Iron Cooking Grate
7 Charcoal Grate
8 Electric Starter Pocket
9 Fire Bowl
10 Top Cooking Grate, Stainless Steel
11 Shock Absorber Assembly
12 “X” Leg Connectors (with bolts,
washers & spring washers) (x3)
13 Wood Shelves, Slatted, Dark (x2)
Solid Stainless Steel Shelves, (x2)
14 Handle (with nuts & washers)
15 Ash Drawer Body, Powder Coat
Ash Drawer Body, Stainless Steel
15.1
Starter Port Flipper Door, Powder Coat
Starter Port Flipper Door,
Stainless Steel
16
Cart Leg, Curved, Powder Coat (x4)
Cart Leg, Curved, Stainless Steel (x4)
17 Felt Gasket
18 Rubber Wheels (x2) Standard
19 Rubber Wheels (x2) Locking
20 Bottom Cooking Grate, Stainless Steel
21 Starter Holster, Powder Coat
Starter Holster, Stainless Steel
22 Grill Cover
23 Lava Stone
24 SS Stone Bracket
25 Electric Starter
26 Flexible Grill Light, White
Flexible Grill Light, Black
VGC TV-CAS
VGC TV-SSS
VGC TV-CAS-T
VGC TV-CAS-SK
VGC CDLSS-1
VGC SSIT
VGC RA1-L
VGC SSDB-L
VGC RA2
VGC SB-RF
VGC SB-RB
VGC SB-LF-L
VGC SB-LB-L
VGC CGB-L
VGC CG-1
VGC ESP-1
VGC FB-1
VGC CGT-L
VGC AC-L
VGC XLC-L
VGC WS-SD-L
VGC SSS-L
VGC HDLSS-L
VGC ADB-PC
VGC ADB-SS
VGC ADB-PCFD-L
VGC ADB-SSFD-L
VGC CLEG-PC
VGC CLEG-SS
VGC FLT-L
VGC WHLS-L
VGC WHL-L-L
VGC CGB-L
VGC HOLST-PC
VGC HOLST-SS
VGC GC-L
VGK-101R
VGK-BRACKET
VGK-ELEC
VGK-FGL-W
VGK-FGL-K
1*
2.1
2
3
14
7
5
5.2
5.1
5.3
5.4
13*
4
15.1*
16*
18
18
22
**
17
11
Vision Grills, LLC • 1531 Fairview Avenue, Suite B, St. Louis, MO 63132 • 877.917.4273 • www.visiongrills.com
1.1
15*
12
13*
1.2
8
16*
16*
16*
12
19
19
23
**
24
**
25
**
9
* Part Material & Style may vary based on Model
Model #s RL-K17F1M4 / RL-W20D1L5-1 / Laguna
SIGNATURE SERIES
GOURMET
26
**
12
6
10
*Laguna Only
20
21*
**
Not included in all Grill packages
