Visual engineering MFR-TI Bedienungsanleitung

visualengineering.co.uk Page 1

MFR-TI April 2022

MFR-TI

User Manual

User Guide for the MFR-TI

Thermal PTZ Camera

visualengineering.co.uk Page 2

MFR-TI April 2022

Document History � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Warranty and Support � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Introduction� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4

Connections � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5

Conguring the Camera � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6

• Boot Menu � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6

• Comm Port Options � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6

• Motor Options � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7

• Camera Options� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7

Software Control� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8

Camera Communications � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10

• Additional Commands � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10

• Flir-Pass-Through� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11

Specications � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13

Dimensions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14

• Overall Dimensions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14

• Base Plate Hole Centres � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14

Table of Contents

visualengineering.co.uk Page 3

MFR-TI April 2022

Document History

Warranty and Support

All Visual Engineering products are supplied as standard with a 12 month ‘Return to Base’ warranty�

Please note: Any unauthorised product disassembly, modication or the removal of tamper

proof labels will void the warranty.

In the event of a suspected product failure, users should contact the Visual Engineering support

team on the telephone number +44 (0) 1206 211842 or please email us at:

support@visualengineering�co�uk

Should the fault persist or if the support team are unable to resolve the fault, it may be necessary

to return the equipment�

Equipment should only be returned using the RMA (Returns Management Authorisation) process�

Users should contact the support team on the above number and request an RMA number�

Version Date Change Summary

v1�0 11/04/2022 Initial Release

visualengineering.co.uk Page 4

MFR-TI April 2022

Introduction

The MFR-TI is a thermal PTZ camera which is housed in a very rugged environmentally sealed casing

making it ideal for use in harsh environments�

The Flir thermal camera incorporates radiometric technology which delivers high precision

temperature monitoring� It supports an 8x digital zoom and spot metering to further optimise the

exposure control for each particular scenario�

Speeds are zoom factor corrected, giving ne control over the entire range of the lens with pan

speeds up to 100º per second�

The MFR-TI has absolute position feedback and therefore has the ability to self correct its actual

position if external forces act upon it. User presets can be saved allowing PTZ framing proles to be

easily recalled�

There is the option to have the video output as an encoded ONVIF compliant stream for use in IP

networks� Remote control of the camera is through VISCA protocol over USB or a RS232/RS485

serial connection�

The output video signal is HD-SDI which is available on the Fischer MiniMax connector on the

camera’s base, which also supports connections to power and data�

The outer casing is manufactured from aluminium� All external mating surfaces are gasket sealed

to maintain its IP67 rating�

visualengineering.co.uk Page 5

MFR-TI April 2022

Connections

The MFR-TI kit includes a power comms break out cable, part number 110-3562�

The cable assembly connects to the Fischer MiniMax connector on the base of the camera�

All signals are then split out to their relevant connectors� The connections are described below�

*Only active if the MFR-TI

includes an IP encoder�

Connector Signal

Micro USB Comms

EXT 232/485 RS232/485

DC Coax Power

RJ45 *Ethernet

Connector Signal

BNC HD-SDI

MFR-TI communications are supported via the

micro USB and EXT 232/485 connectors�

The EXT 232/485 connector supports RS232 and

RS485 comms, the pinout of the connector is

described on the right�

EXT 232/485 Pinout

RS232 RS485

RX (to cam) B

TX (from cam) A

GND

visualengineering.co.uk Page 6

MFR-TI April 2022

Conguring the Camera

The MFR-TI can be congured for a specic user prole, to include; communication settings, motor

control, and camera options. Once congured the camera will retain the settings.

The camera is congured using a menu structure on its control interface which is only accessible

at power on� To access the control menu it is necessary to connect the camera to a serial comms

software application, such as TeraTerm set to 9600 baud 8n1�

• Connect the power comms cable to a USB

port on a PC�

• Open the PC serial comms application

• Power on the camera, a > character will

appear and shortly after a ! character�

• As soon as the ! appears type v e in quick

succession�

• The Main Menu shown on the right will then

be displayed�

• Select the required option�

• The function options are described in the

following tables�

Boot Menu

Comm Port Options

Sub Menu Description Options

Mode The serial comms standard

RS485, No Parity , RS232, No Parity,

RS485, Odd Parity, RS232, Odd Parity

RS485, Even Parity, RS232, Even Parity

Baud Rate The serial comms baud rate 1200, 2400, 4800, 9600, 19200,

38400, 57600, 115200

Protocol The PTZ control protocol Auto Detect, VISCA,

PelcoD, PelcoP

Unit Address

The camera’s unit address, this allows

several cameras to be connected on the

same comms bus

1, 2, 3, 4, 5, 6, 7

MFR-TI

Software: v2.0.0

MAIN MENU:

1 = Comm Port

2 = Motor

3 = Camera

t = Start Diagnostic Test

x = Exit

visualengineering.co.uk Page 7

MFR-TI April 2022

Motor Options

Sub Menu Description Options

Auto Position

Correction

Whether the camera automatically corrects

its actual position if external forces

act upon it

Disabled, Enabled

Stall Detection Detects a stall in the motor drive Disabled, Enabled

Motor Speed The speed at which the motors are driven High, Medium, Low

Hold Torque The torque force which the camera uses to

hold position High, Medium, Low

Camera Options

Video Options

Sub Menu Description Options

Output Mode The output video format

PAL, NTSC, 720p/25, 720p/29�97, 720p/50,

720p/59�94, 1080i/50, 1080i/59�94, 1080p/25,

1080p/29�97, 1080p/50, 1080p/59�94

On Screen

Display The OSD in the camera’s video Disabled, Enabled

Flip on Tilt

The video picture will automatically invert

when the camera head it tilted over the top

of its travel

Disabled, Enabled

visualengineering.co.uk Page 8

MFR-TI April 2022

Software Control

The MFR-TI camera’s serial communication supports the Sony VISCA protocol�

The user may choose to use a software controller of their choice or use the VE Camera Controller�

This software application can be downloaded from the Visual Engineering website:

www�visualengineering�co�uk/supportdownload/9

The user should install the Software application on a PC� The screen below shows the software

application�

visualengineering.co.uk Page 9

MFR-TI April 2022

It is necessary to connect the camera to a USB port on the PC� The operating system of the

computer will allocate this a COM port number� Once this connection has been made the user can

go ahead and connect the application to the COM port� In the example below the port COM3 has

been selected�

Once the software application is connected the functions of the software can be used� In the

example below the pan right command has been selected� Similar commands for pan left, tilt up &

down and zoom functions can also be sent using the intuitive software user interface�

visualengineering.co.uk Page 10

MFR-TI April 2022

Camera Communications

To maintain the same control protocol across the MFR range of cameras the adopted control

protocol is Sony VISCA� This standard is used to communicate with the Flir thermal camera and

for PTZ control� Flir camera communications uses a Flir-Pass-Through format, which incorporates

standard Flir protocol commands contained within a VISCA wrapper, as described later�

Additional Commands

Additional commands adopting the VISCA protocol format have been developed by Visual

Engineering for use with the MFR-TI camera� These commands also allow control of a limited set of

parameters in the Flir thermal camera when using standard VISCA controllers�

Commands such as unit type, PTZ control and thermal palette switching are included, as described

in the following tables�

Additional Commands

Cmd Set Command Command Packet Comments

PAN TILT

DRIVE

Move 8x 01 06 01 <aa> <bb> <cc> <dd> FF

<aa> = Pan Speed

(0x01-0x18)

<bb> = Tilt Speed

(0x01-0x14)

<cc> = Pan Direction

(0x01 = Left, 0x02 = Right, 0x03 = Stop)

<dd> = Tilt Direction

(0x01 = Up, 0x02 = Down, 0x03 = Stop)

Absolute

Position

8x 01 06 02 00 00 0p 0p 0p 0p 0t 0t 0t 0t FF

<pppp> = Pan Position

<tttt> = Tilt Position

The value sent is a 16-bit signed

integer calculated as below where <x>

is equal to the required angle

(-180° to +180°)

Value = x*20

THERMAL

COLOUR

PALETTE

Set Palette 81 01 04 63 <xx> 01 FF <xx> = Palette Selection

(0x00 – 0x0D)

THERMAL


FREEZE

On/O 81 01 04 62 <xx> 01 FF

<xx> = On/O

0x02 = On (Freeze Image)

0x03 = O (Real-Time)
