Vivotek IP8173H Bedienungsanleitung

User’s Manual
IP8173H Fixed
Network Camera
3MP • Compact Size • WDR Pro
Rev. 1.1

VIVOTEK
2 - User's Manual
Table of Contents
Overview �����������������������������������������������������������������������������������������������������������������������������������������������������4
Revision History �������������������������������������������������������������������������������������������������������������������������������������� 4
Read Before Use������������������������������������������������������������������������������������������������������������������������������������� 5
Package Contents ����������������������������������������������������������������������������������������������������������������������������������� 5
Symbols and Statements in this Document��������������������������������������������������������������������������������������������� 5
Physical Description �������������������������������������������������������������������������������������������������������������������������������� 6
Mounting the Lens to the Camera ����������������������������������������������������������������������������������������������������������� 7
Mounting the Camera to Stand ��������������������������������������������������������������������������������������������������������������� 8
Software Installation ������������������������������������������������������������������������������������������������������������������������������ 14
Ready to Use����������������������������������������������������������������������������������������������������������������������������������������� 15
Accessing the Network Camera ������������������������������������������������������������������������������������������������������������18
Using Web Browsers����������������������������������������������������������������������������������������������������������������������������� 18
Using RTSP Players������������������������������������������������������������������������������������������������������������������������������ 21
Using 3GPP-compatible Mobile Devices����������������������������������������������������������������������������������������������� 22
Using VIVOTEK Recording Software ���������������������������������������������������������������������������������������������������� 23
Main Page�������������������������������������������������������������������������������������������������������������������������������������������������24
Go to����������������������������������������������������������������������������������������������������������������������������������������������������������28
Client Settings ������������������������������������������������������������������������������������������������������������������������������������������29
Conguration��������������������������������������������������������������������������������������������������������������������������������������������33
System > General settings �������������������������������������������������������������������������������������������������������������������� 34
System > Homepage layout ����������������������������������������������������������������������������������������������������������������� 36
System > Logs �������������������������������������������������������������������������������������������������������������������������������������� 39
System > Parameters ��������������������������������������������������������������������������������������������������������������������������� 41
System > Maintenance�������������������������������������������������������������������������������������������������������������������������� 42
Media > Image ������������������������������������������������������������������������������������������������������������������������������������ 46
Media > Video ��������������������������������������������������������������������������������������������������������������������������������������� 54
Media > Video ��������������������������������������������������������������������������������������������������������������������������������������� 55
Media > Audio���������������������������������������������������������������������������������������������������������������������������������������� 60
Network > General settings������������������������������������������������������������������������������������������������������������������� 61
Network > Streaming protocols ����������������������������������������������������������������������������������������������������������� 70
Network > SNMP (Simple Network Management Protocol)������������������������������������������������������79
Security > User Account������������������������������������������������������������������������������������������������������������������������ 80
Security > HTTPS (Hypertext Transfer Protocol over SSL) ����������������������������������������� 81
Security > Access List ������������������������������������������������������������������������������������������������������������������������� 88
PTZ > PTZ settings ������������������������������������������������������������������������������������������������������������������������������� 93
PTZ�������������������������������������������������������������������������������������������������������������������������������������������������������� 97
Event > Event settings������������������������������������������������������������������������������������������������������������������������� 101
Applications > Motion detection����������������������������������������������������������������������������������������������������������� 114
Applications > Digital Input������������������������������������������������������������������������������������������������������������������ 117
Applications > Tampering detection ���������������������������������������������������������������������������������������������������� 117
Recording > Recording settings ��������������������������������������������������������������������������������������������������������� 118
Local storage > SD card management������������������������������������������������������������������������������������������������ 123
Local storage > Content management ������������������������������������������������������������������������������������������������ 124
Appendix ������������������������������������������������������������������������������������������������������������������������������������������������127

VIVOTEK
User's Manual - 3
URL Commands for the Network Camera������������������������������������������������������������������������������������������������ 127
Technical Specications ���������������������������������������������������������������������������������������������������������������������������202
Technology License Notice����������������������������������������������������������������������������������������������������������������������� 203
Electromagnetic Compatibility (EMC)������������������������������������������������������������������������������������������������������� 204

VIVOTEK
4 - User's Manual
Overview
VIVOTEK’s IP8173H network camera features a 3-Megapixel WDR CMOS sensor to cope with
challenging lighting conditions� The WDR feature allows the camera to capture both the dark
and bright parts of an image and combine the differences to generate a highly realistic image
representative of the original scene, enabling it to provide video quality close to the capabilities
of the human eye� The IP8173H can be widely applied in high contrast environments such as
lobby entrances and more� The P-iris lens controls the iris with extreme precision; with its built-
in stepper motor, it maintains the iris opening at an optimal level at all times, resulting in superior
image clarity and depth of eld as well as image quality.
The IP8173H features a mini-box camera design concept with a compact size to t into different
types of enclosures. With the capability to t to a CS-mount lens, it provides exible monitoring
in monitoring all types of environments� With all of these features mentioned above, the camera
is the best choice for retail, government, industrial, hotel security and city surveillance�
Revision History
■ Rev. 1.0: Initial release
■ Rev. 1.1: Added description for the T-bracket for mounting into an enclosure.

VIVOTEK
User's Manual - 5
Read Before Use
The use of surveillance devices may be prohibited by law in your country� The Network Camera
is not only a high-performance web-ready camera but can also be part of a exible surveillance
system� It is the user’s responsibility to ensure that the operation of such devices is legal before
installing this unit for its intended use�
It is important to first verify that all contents received are complete according to the Package
Contents listed below� Take note of the warnings in the Quick Installation Guide before the Network
Camera is installed; then carefully read and follow the instructions in the Installation chapter to
avoid damage due to faulty assembly and installation� This also ensures the product is used
properly as intended�
The Network Camera is a network device and its use should be straightforward for those who
have basic networking knowledge� It is designed for various applications including video sharing,
general security/surveillance, etc� The Configuration chapter suggests ways to best utilize the
Network Camera and ensure proper operations� For creative and professional developers, the URL
Commands of the Network Camera section serves as a helpful reference to customizing existing
homepages or integrating with the current web server�
Package Contents
■ IP8173H
■ Screws / Plastic Anchors
■ CS-mount Lens
■ Camera Stand
■ Software CD
■ Warranty Card
■ Quick Installation Guide
■ L-type Hex Key Wrench
■ T-shape mount bracket
Symbols and Statements in this Document
i
INFORMATION: provides important messages or advices that might help prevent
inconvenient or problem situations�
NOTE: Notices provide guidance or advices that are related to the functional integrity of
the machine�
Tips: Tips are useful information that helps enhance or facilitae an installation, function,
or process�
WARNING: or IMPORTANT: These statements indicate situations that can be dangerous
or hazardous to the machine or you�
Electrical Hazard: This statement appears when high voltage electrical hazards might
occur to an operator�

VIVOTEK
6 - User's Manual
Physical Description
Front Panel
Rear Panel
Item LED status Description
LED Denitions
1 Steady Red Powered and system booting, or network failed
2Green LED blinks every 1 sec� Connected to network
3 Blink Red every 0�15 sec� + Blink Orange
every 1 sec�
(Red on for 0�15 sec and off for 0�15 sec,
and so on)+(Green on for 1 sec and off for
1sec, and so on�
Upgrading rmware
4Orange blinks every 0�15 sec� Restoring defaults
Ethernet 10/100 RJ45
Socket
Recessed Reset Button
General I/O Terminal Block
Iris Control Cable Socket
1 2 3 4 5 6 7
GND
DI
RS485_N
RS485_P
GND_AUDIO
MIC_IN
AUDIO_OUT
Mounting Hole
Status LED
Lens
Mount ring adjustment
Light sensor
MicroSD/SDHC/SDXC
Card Slot
Micro SD

VIVOTEK
User's Manual - 7
Lens
Focus Controller
Zoom Controller
Mounting the Lens to the Camera
1�Mount the lens by turning it clockwise onto the camera mount until it stops�
2�Connect the iris control cable to the socket� Connect the iris control cable before
power-on. Otherwise, you will not be able to access the exposure-related settings.
2
1

VIVOTEK
8 - User's Manual
1�Use the holes on the camera stand to mark drill holes on the wall� Drill holes on your
preferred location�
2�Hammer in the included plastic anchors�
3� Install the camera stand to wall or ceiling
by driving screws through it�
4�Attach the camera to stand by turning the
stand and the fastening rings�
Mounting the Camera to Stand
Shown below is the mechanical drawing
of the camera stand�
M4x25 tapping
screws�
28mm anchors�

VIVOTEK
User's Manual - 9
Digital Input Diagram
Please refer to the following illustration for the connection method�
3.3V
Digital input
DI+
DI-: Ground
DI-
Max. voltage: 40V
Connect a digital input device to the input pins of the camera� From the Applications > Digital In-
put page on page 117, you can let camera report the current signal status as High or Low, Open
or Grounded, to determine the signal’s Normal status during operation�
IMPORTANT:
0002D10766AD
IP8173H
Record the MAC address before installing the camera�

VIVOTEK
10 - User's Manual
Hardware Reset
The reset button is used to reset the system or restore the factory default settings�
Sometimes resetting the system can return the camera to normal operation� If the system
problems remain after reset, restore the factory settings and install again�
Reset: Press and release the reset button. Wait for the Network Camera to reboot.
Restore: Press and hold the recessed reset button until the status LED rapidly blinks. Note
that all settings will be restored to factory default� Upon successful restore, the status LED
will blink green and red during normal operation�
Reset Button
Network Deployment
Power over Ethernet (PoE)
When using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data via a
single Ethernet cable� Follow the below illustration to connect the Network Camera to a
PoE-enabled switch via Ethernet cable�
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
PoE Switch
