VODA
Pulldown Sink Mixer
VSS13
Voda Plumbingware (NZ) Ltd | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
Congratulations on your purchase of this high quality product from Voda Plumbingware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for Mains Pressure only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa* (As per NZ Building Code AS/NZ 3500.1)
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Install as supplied.
Unequal Low systems This product is not suitable for this type of water pressure.
Equal Low systems This product is not suitable for this type of water pressure.
INSTALLATION
*FOR PRESSURES EXCEEDING 500kPa INSTALL A PRESSURE REDUCING VALVE. THOROUGHLY FLUSH ALL
PIPES TO ELIMINATE ANY REMAINING DIRT AND RESIDUE, AND INSTALL INLINE FILTERS. FAILURE TO DO SO
MAY VOID THE WARRANTY.
• Position tap in 35mm hole, making sure the seal between tap and supporting surface is in place.
• Anchor to bench with fittings pack.
• Thoroughly flush all pipes to eliminate any remaining dirt and residue and install inline filters.
• Connect supply hoses to plumbing connections.
Maximum bend for flexible hose is 35mm radius.
Do not stretch, crush or twist hoses. Do not swage hose ends.
• Turn on mains supply.
• Check for leaks.
Plumbers Note: Do not pressure test this mixer under static pressure.
WARRANTY
PLEASE CALL US BEFORE REMOVING TAPWARE OR UNDERTAKING ANY REPAIR WORK.
Please refer to our website for warranty information: www.vodaplumbingware.co.nz/warranty
In the unlikely event that this product fails during its warranty period, phone our Customer Service team
immediately on 0508 367 366 – as unauthorised removal of the product may void the warranty.
CARE AND MAINTENANCE
SHOULD NOT BE CLEANED WITH ACIDIC, CAUSTIC/ALKALINE, ABRASIVE OR CITRIC CLEANERS.
A so, damp cloth is recommended for cleaning (Not a Micro fibre cloth). Mild soap solutions can also be used on
occasion.
ATTACH PROOF OF PURCHASE HERE
Voda Plumbingware (NZ) Ltd | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
=
PROUD PARTNER AND SUPPORTER OF MASTER PLUMBERS, GASFITTERS AND DRAINLAYERS
