VORON 2.4 KIT 5 Bedienungsanleitung
VORON 2.4
KIT 5
∙GANTRY FRAME
∙RAIL
WWW.VORONDESIGN.COM
INTRODUCTION
Before you begin on your journey, a word of caution.
In the comfort of your own home you are about to assemble a robot. This
machine can maim, burn, and electrocute you if you are not careful. Please
do not become the rst VORON fatality. There is no special Reddit air for that.
Please, read the entire manual before you start assembly. As you begin wrenching,
please check our Discord channels for any tips and questions that may halt your progress.
Most of all, good luck!
THE VORON TEAM
WWW.VORONDESIGN.COM
GANTRY
01
WWW.VORONDESIGN.COM
A Idler
B Idler
B Drive
A Drive
Left XY Joint
Right XY Joint
X Linear Rail
OVERVIEW
XY Bridge
02
WWW.VORONDESIGN.COM
PREPARATION
GENERIC CABLE CHAINS
The 3 hole pattern is usually
found on generic cable chains.
IGUS CABLE CHAINS
IGUS chains have 2 mounting
holes.
WHICH TO CHOOSE?
Pick the style that matches the
mounting pattern of your cable
chains.
03
WWW.VORONDESIGN.COM
T- NUT ORIENTATION
Insert the t-nuts as shown in the highlight.
M5 T-Nut
GANTRY
E Extrusion
04
WWW.VORONDESIGN.COM
M5x10 BHCS
GANTRY
05
WWW.VORONDESIGN.COM
M5x10 BHCS
GANTRY
06
WWW.VORONDESIGN.COM
M3 T-Nut
M3x8 SHCS
MGN9 Rail
T- NUT ORIENTATION
Insert the t-nuts as shown in the highlight.
MIND THE CARRIAGE
The carriages are designed to slide along the rail easily.
This unfortunately also includes sliding off the rails.
Dropping the carriage likely irreparably damages it.
CENTRED RAIL INSTALLATION GUIDE
Use the MGN9 guides to position the rail in the
centre of the extrusion prior to fastening the screws.
Y AXIS
C Extrusion
07
WWW.VORONDESIGN.COM
T- NUT ORIENTATION
Insert the t-nuts as shown in the highlight.
M5 T-Nut
Y AXIS
08
