VOX electronics KK-3400 Bedienungsanleitung

KK-3400/3400S

OPERATING INSTRUCTIONS DOUBLE DOOR REFRIGERATOR

UPUTSTVO ZA UPOTREBU FRIŽIDER SA ZAMRZIVAČEM

УПАTСТВА ЗА РАКУВАЊЕ ФРИЖИДЕР СО ЗАМРЗНУВАЧ

NAVODILA ZA UPORABO HLADILNIK Z DVOJNIMI VRATI

UPUTE ZA UPORABU HLADNJAK SA ZAMRZIVAČEM

MANUAL DE INSTRUÇÕES FRİGORİFİCO COMBİNADO DE

DUAS PORTAS

GBR

SRB

MKD

SVN

HRV

EN - 1 -

Index

BEFORE USING THE APPLIANCE .......................................................... 2

General warnings ........................................................................................2

Old and out-of-order fridges ........................................................................4

Safety warnings ...........................................................................................4

Installing and operating your fridge .............................................................5

Before using your fridge freezer ..................................................................6

HOW TO OPERATE THE APPLIANCE ..................................................... 6

Thermostat setting.......................................................................................6

Warnings about temperature adjustments...................................................6

Accessories .................................................................................................7

Ice tray .......................................................................................................................7

Plastic scraper............................................................................................................7

Bottle holder...............................................................................................................7

FOOD STORAGE IN THE APPLIANCE .................................................... 8

Refrigerator compartment............................................................................8

Freezer compartment ..................................................................................8

CLEANING AND MAINTENANCE .......................................................... 12

Defrosting ..................................................................................................13

Replacing the Light bulb ............................................................................14

TRANSPORTATION AND CHANGING OF INSTALLATION POSITION 14

Repositioning the door...............................................................................14

BEFORE CALLING FOR AFTER SALES SERVICE .............................. 15

Tips for saving energy ...............................................................................16

PARTS OF THE APPLIANCE AND THE COMPARTMENTS ................. 17

The operating instructions apply to several models. Differences may therefore occur.

EN - 2 -

BEFORE USING THE APPLIANCE

General warnings

WARNING: Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those recom-

mended by the manufacturer.

WARNING: Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are of the

type recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: In order to avoid any hazards resulting from the in-

stability of the appliance, it must be xed in accordance with the

following instructions:

• If your appliance uses R600a as a refrigerant (this information

will be provided on the label of the cooler) you should

take care during transportation and installation to prevent

the cooler elements from being damaged. R600a is an

environmentally friendly and natural gas, but it is explosive.

In the event of a leak due to damage of the cooler elements,

move your fridge away from open ames or heat sources

and ventilate the room where the appliance is located for a

few minutes.

• While carrying and positioning the fridge, do not damage the

cooler gas circuit.

• Do not store explosive substances such as aerosol cans

with a ammable propellant in this appliance.

• This appliance is intended to be used in household and

domestic applications such as:

- staff kitchen areas in shops, ofces and other working en-

vironments.

PART - 1.

EN - 3 -

- farm houses and by clients in hotels, motels and other resi-

dential type environments.

- bed and breakfast type environments;

- catering and similar non-retail applications.

• If the socket does not match the refrigerator plug, it must be

replaced by the manufacturer, a service agent or similarly

qualied persons in order to avoid a hazard.

• A specially grounded plug has been connected to the power

cable of your refrigerator. This plug should be used with

a specially grounded socket of 16 amperes. If there is no

such socket in your house, please have one installed by an

authorised electrician.

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

• If the supply cord is damaged, it must be replaced by

the manufacturer, an authorised service agent or similar

qualied persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes exceeding

2000 m.

EN - 4 -

Old and out-of-order fridges

• If your old fridge has a lock, break or remove the lock before discarding it, because

children may get trapped inside it and may cause an accident.

• Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC.

Therefore, take care not to harm environment when you are discarding your old

fridges.

Please ask your municipal authority about the disposal of the WEEE reuse, recycle

and recovery purposes.

Notes:

• Please read the instruction manual carefully before installing and using your appliance.

We are not responsible for the damage occurred due to misuse.

• Follow all instructions on your appliance and instruction manual, and keep this manual in

a safe place to resolve the problems that may occur in the future.

• This appliance is produced to be used in homes and it can only be used in domestic

environments and for the specied purposes. It is not suitable for commercial or

common use. Such use will cause the guarantee of the appliance to be cancelled and

our company will not be responsible for losses incurred.

• This appliance is produced to be used in houses and it is only suitable for cooling / storing

food. It is not suitable for commercial or common use and/or for storing substances

except for food. Our company is not responsible for losses to be incurred in the contrary

case.

Safety warnings

• Do not connect your fridge freezer to the mains electricity supply using an extension

lead.

• Do not plug in damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• This appliance is designed for use by adults, do not allow children to play

with the appliance or let them hang off the door.

• Never touch the power cord/plug with wet hands as this could cause a short

circuit or electric shock.

• Do not place glass bottles or beverage cans in the ice-making compartment

as they can burst as the contents freeze.

• Do not place explosive or ammable material in your fridge. Place drinks

with high alcohol content vertically in the fridge compartment and make

sure that their tops are tightly closed.

• When removing ice from the ice-making compartment, do not touch it. Ice may

cause frost burns and/or cuts.

• Do not touch frozen goods with wet hands! Do not eat ice-cream and ice cubes

immediately after you have taken them out of the freezer department!

EN - 5 -

• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes immediately

after you have taken them out of the ice-making compartment.

• Do not cover the body or top of fridge with lace. This affects the performance of your

fridge.

• Secure any accessories in the fridge during transportation to prevent damage to the

accessories.

Installing and operating your fridge

Before starting to use your fridge freezer, you should pay attention to the following points:

• The operating voltage for your fridge is 220-240 V at 50Hz.

• The plug must be accessible after installation.

• Your fridge freezer may have a smell when it is operated for the rst time. This is normal

and the smell will fade away when your fridge freezer starts to cool.

• Before connecting your fridge freezer, ensure that the information on the data plate

(voltage and connected load) matches that of the mains electricity supply. If in doubt,

consult a qualied electrician.

• Insert the plug into a socket with an efcient ground connection. If the socket has no

ground contact or the plug does not match, we recommend that you consult a qualied

electrician for assistance.

• The appliance must be connected with a properly installed fused socket. Power supply

(AC) and voltage at the operating point must match with the details on the name plate of

the appliance (name plate is located on the inside left of the appliance).

• We do not accept responsibility for any damages that occur due to ungrounded usage.

• Place your fridge where it will not be exposed to direct sunlight.

• Your fridge should never be used outdoors or exposed to rain.

• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores,

and at least 5 cm away from electrical ovens.

• When your fridge is placed next to a deep freezer, there should be at least 2 cm between

them to prevent humidity forming on the outer surface.

• Do not place heavy items on the appliance.

• Clean the appliance thoroughly, especially the interior, before use (see

Cleaning and Maintenance).

• The installation procedure into the kitchen unit is given in the installation

manual. This product is intended to be used in proper kitchen units only.

• Before using your fridge freezer, wipe all parts with a solution of warm water

and a teaspoon of sodium bicarbonate, then rinse with clean water and dry. Place all

parts in the fridge after cleaning.

• Install the plastic distance guide (the part with black vanes at the rear)

by turning it 90° (as shown in the gure) to prevent the condenser from

touching the wall.

• The refrigerator should be placed against a wall with a free space not

exceeding 75 mm.

EN - 6 -

Before using your fridge freezer

• When using your fridge freezer for the rst time, or after transportation, keep

it in an upright position for at least 3 hours before plugging into the mains.

This allows efcient operation and prevents damage to the compressor.

• Your fridge freezer may have a smell when it is operated for the rst time. This is normal

and the smell will fade away when your fridge starts to cool.

HOW TO OPERATE THE APPLIANCE

Thermostat setting

Warnings about temperature adjustments

• It is not recommended that you operate your fridge in environments colder than 10°C in

terms of its efciency.

• Temperature adjustments should be made according to the frequency of door openings

and the quantity of food kept inside the fridge.

• Your fridge should be operated up to 24 hours according to the ambient temperature

without interruption after being plugged in to be completely cooled. Do not open doors

of your fridge frequently and do not place much food inside it in this period.

• A 5 minute delaying function is applied to prevent damage to the compressor of your

PART - 2.

The fridge freezer thermostat automatically regulates the inside temperature of the

compartments. By rotating the knob from position 1 to 5, colder temperatures can be

obtained.

Important note: Do not try to rotate knob beyond 1 position it will stop your appliance.

1 – 2 : For short-term storage of food in the freezer compartment, you can set the knob

between the minimum and medium position.

3 – 4 : For long-term storage of food in the freezer compartment, you can set the knob to

the medium position.

5 : For freezing fresh food. The appliance will work for longer. So, after the desired

condition is reached, return the knob to the previous setting.

When lighting and thermostat are

positioned on side

When lighting and thermostat are

positioned on top

Thermostat control Thermostat control

EN - 7 -

fridge, when you take the plug out and then plug it in again to operate it or when an

energy breakdown occurs. Your fridge will start to operate normally after 5 minutes.

• Your fridge is designed to operate in the ambient temperature intervals stated in the

standards, according to the climate class stated in the information label. We do not

recommend operating your fridge out

of stated temperatures value limits in

terms of cooling effectiveness.

• This appliance is designed for use at an

ambient temperature within the 16°C -

38°C range.

Climate class Ambient temperature (oC)

TBetween 16 and 43 oC

ST Between 16 and 38 oC

NBetween 16 and 32 oC

SN Between 10 and 32 oC

Accessories

Ice tray

• Fill the ice tray with water and place in freezer compartment.

• After the water completely turned into ice, you can twist the tray as shown below to get

the ice cube.

Plastic scraper

After a period of time frost will build up in certain areas in the freezer compartment.

The frost accumulated in the freezer should be removed periodically. Use the

plastic scraper provided if necessary. Do not use sharp metal objects for this

operation. They could puncture the refrigerator circuit and cause irreparable

damage to the unit.

Bottle holder

In order to prevent bottles from slipping or falling over, you can use the bottle

holder. This will also help to prevent the noise made by bottles when opening

or closing the door.

(Only some models)

All written and visual descriptions in the accessories may vary according to

the appliance model.

EN - 8 -

Refrigerator compartment

The refrigerator compartment is used for storing fresh food for a few days.

• Do not place food in direct contact with the rear wall of the refrigerator compartment.

Leave some space around food to allow circulation of air.

• Do not place hot food or evaporating liquid in the refrigerator.

• Always store food in closed containers or wrapped.

• To reduce humidity and avoid formation of frost, never place liquids in unsealed containers

in the refrigerator.

• Meat of all types, wrapped in packages, is recommended to be placed on the glass shelf

just above the vegetable bin, where the air is colder.

• You can put fruit and vegetables into the crisper without packaging.

• To avoid cold air escaping, try not to open the door too often, and not leave the door open

for a long time.

Some recommendations have been specied below for the placement and storage of your

food in the cooling compartment.

FOOD STORAGE IN THE APPLIANCEPART - 3.

Food Maximum Storing time Where to place in the

fridge department

Vegetables and fruits 1 week Vegetable bin

Meat and fis 2 - 3 Days

Wrapped in plastic foil or bags or in

a meat container

(on the glass shelf)

Fresh cheese 3 - 4 Days In special door shelf

Butter and margarine 1 week In special door shelf

Bottled products

milk and yoghurt

Until the expiry date

recommended by the

producer

In special door shelf

Eggs 1 month In the egg shelf

Cooked food All shelves

NOTE: Potatoes, onions and garlic should not be stored in the refrigerator.

Freezer compartment

The freezer compartment is used for freezing fresh food and for storing frozen food for the

period of time indicated on packaging, and for making ice cubes.

• When freezing fresh food, wrap and seal the food properly; the packaging should be air

tight and shouldn’t leak. Special freezer bags, aluminum foil (heavy grade, if in doubt

double wrap), polythene bags and plastic containers are ideal.

• To get maximum capacity for freezer compartment, please just use glass shelves for

upper and middle section. For bottom section, please use lower basket.

• The maximum amount of fresh foods that can be loaded in the freezer within 24 hours is

indicated on the name plate (see Freezing Capacity).

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere VOX electronics Kühlschrank Handbücher

VOX electronics

VOX electronics NF 3833A Bedienungsanleitung

VOX electronics

VOX electronics NF-3830W Bedienungsanleitung

VOX electronics

VOX electronics SBS6305IX Bedienungsanleitung

VOX electronics

VOX electronics KG 2610 Bedienungsanleitung

VOX electronics

VOX electronics KK3220F Bedienungsanleitung

VOX electronics

VOX electronics KK-3300 Bedienungsanleitung

VOX electronics

VOX electronics LARDER KS-1210 Bedienungsanleitung

VOX electronics

VOX electronics KS2800G Bedienungsanleitung

VOX electronics

VOX electronics KK-3250 Bedienungsanleitung

VOX electronics

VOX electronics IKG-2600F Bedienungsanleitung

VOX electronics

VOX electronics KS1530 Bedienungsanleitung

VOX electronics

VOX electronics KS-325 Bedienungsanleitung

VOX electronics

VOX electronics KG-2500 Bedienungsanleitung

VOX electronics

VOX electronics IKK3410F Bedienungsanleitung

VOX electronics

VOX electronics KS1100F Bedienungsanleitung

VOX electronics

VOX electronics FD458IXE Bedienungsanleitung

VOX electronics

VOX electronics KK3600F Bedienungsanleitung

VOX electronics

VOX electronics IVF2790F Bedienungsanleitung

VOX electronics

VOX electronics KS1530F Bedienungsanleitung

VOX electronics

VOX electronics KG-3300S Bedienungsanleitung

VOX electronics

VOX electronics KS1200F Bedienungsanleitung

VOX electronics

VOX electronics KG3330 Bedienungsanleitung

VOX electronics

VOX electronics IKS1450F Bedienungsanleitung

VOX electronics

VOX electronics KS 3750 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
