Vuescape 61000101 Bedienungsanleitung

2.4 GHz Wireless Desktop

Keyboard & Mouse

Item Number: 61000101

Installation & User’s Guide

All brand names and trademarks are the property of their respective owners.

Contents

1. Introduction ………………………………………………………………………….....3

2. Package Contents.……………………………………………………………………..3

3. System Requirements…………………………………………………………………3

4. Quick Installation Guide..…………………………………………………………..4-5

4-1. Programming the Hot Keys...…………………………………………………..6

4-2. Programming the Mouse Buttons……………………………………………..6

5. Features and Functions Descriptions……………………………………………..6

5-1. Description of Internet Keys……………………..……………………….……7

5-2. Description of Multimedia Keys.…………..……………………………….....7

5-3. Description of Application Keys.…..…………………………………………7

6. Troubleshooting……………………………………………………………………....8

7. FCC & CE Certification …...………………………………………………………....9

8. Service Procedure……………………………………………………………………10

9. Warranty………………………………………………………………………..………11

1. Introduction:

The 2.4 GHz Wireless Desktop with Keyboard and Mouse:

This keyboard and mouse was developed to provide greater efficiency and productivity

when working with a PC. The keyboard has 8 hot keys including: Internet, Multimedia and

System keys that will increase your productivity by providing direct access to your important

applications by a simple press of the key.

The mouse has 2 keys located on the side which can be programmed in order to work

more efficiently on your computer.

2.4 GHz wireless technology allows you to work up to 33ft away from your computer

without having any interference to the signal.

Instant link technology connects your wireless keyboard and mouse to the USB receiver

automatically. There is no need for you to re-synchronize the devices.

A 1000 DPI optical mouse sensor scans the surface to allow for the finest precision and

accuracy while using your mouse.

The 2.4 GHz Wireless Desktop with Keyboard and Mouse is compatible with Microsoft

Office® 2000 / XP / 2003 or later. It is compatible with Windows® 2000, XP and Vista®

Operating Systems.

2. Package Contents:

•Wireless Keyboard

•Wireless Optical Mouse

•USB Wireless Receiver

•User’s Manual

•Installation CD

•4-AAA batteries to power the mouse and keyboard

3. System Requirements:

•IBM PC or Compatible Computer

•Microsoft Windows® 2000, XP, Vista®.

•CD-ROM or DVD-ROM Drive to install the CD driver.

•An available USB port for the USB Wireless Receiver Connector.

4. Quick Installation and Set Up:

Open the battery compartment located underneath the keyboard

and install the 2 AAA batteries. Note the polarity signs in the battery

compartment.

Open the battery compartment located underneath the mouse and

install the 2 AAA batteries. Note the polarity signs in the battery

compartment.

Turn on the power to your computer and make sure your Windows

operating system is active.

Install the Software CD Driver that has been included and you may

now go on to section 4-

2, Programming the Hot Keys on the

Keyboard and Mouse. Note: Install the Software before pluggi

ng in

the receiver.

Insert the USB Receiver into an available USB port. Your computer

will recognize the USB device and make the proper settings to

enable you to operate your keyboard and mouse. Click on any key

on your keyboard to connect with the receiver. Move the mouse

over the surface to establish a connection with the receiver.

1) If the mouse and/or keyboard do not work, please see the Troubleshooting

information on page 9 of this manual.

2) Caution: Before your mouse and keyboard can be connected, you need to position

the devices within 6 feet of the receiver to establish the initial connection.

Note: The Windows operating systems will search for the new USB HID products and load the

built-in standard USB HID device driver automatically. The system may ask for the Windows

2000 full Operating System CD if it needs the driver to update the operating system. (Windows

XP and Vista Operating System CD is not required).

Follow the instructions and complete the standard USB HID reorganization process. The

keyboards’ basic functions will work properly, the exception may be the Hot Key Functions

which will require you to run the Software CD Driver included with this kit.

4-1 Programming the Hot Keys

You can customize your Keyboard Hot Keys by activating the Keyboard Properties. To do this

click Start, then Programs, and choose the Wireless Keyboard & Mouse Properties. Click on

the Keyboard Icon located in the lower right hand corner of your screen. When the following

screen appears, select which Hot Key you would like to change: Music, Home, E-mail, and

Favorites.

Once you click the hot key to change, the following setup screen will appear. Choose a

function from the drop down menu list or select a program by browsing your PC. You can

restore all the settings to their original configurations by pressing the Restore to Default button.

4-2 Programming the Mouse Buttons

You can customize the side buttons of your mouse by activating the Mouse Properties. Click

Start, Programs, and choose the Wireless Keyboard & Mouse Properties. Click the Mouse Icon

located in the right hand corner of your screen. When the following screen appears, select

which button you want to change. There will be many useful functions to choose from including

cut, copy, paste, undo, redo, open my computer, WWW and more. You can restore all the

settings to their original configurations by pressing the Restore to Default button.

Note:

The wireless optical mouse is manufactured with a power management function that

allows it to conserve power and extend battery life. The mouse will go into a suspend or

sleep mode automatically if the mouse is not used for 10 minutes.

To reactivate the battery power to the mouse, the user should left or right click one of the

mouse buttons. Once it enters the suspend/sleep mode, your mouse will not respond to

movement until you re-activate it.

5. Features and Function Descriptions:

Button # 1 .Programmable Button.

Button # 2. Programmable Button.

Button # 3. Left click Button.

Button # 4. Right click Button.

Button # 5. Middle Button with Scroll Wheel Function











5-1. Multimedia Keyboard Button Descriptions

Decrease Volume Press this key to decrease the volume.

Increase Volume Press this key to increase the volume.

Play/Pause

Press this key to Play or Pause Music or Video. Once in Pause mode, press this

key again to resume Play.

Media Play Press this key to activate your Media software in order to Play Music or Videos

5-2. Keyboard Energy Saving Sleep Mode

Sleep

This button will put the computer system into sleep mode if the PC supports

power management and has it enabled. It will protect data and save energy. The

user can put the com

puter into Sleep mode by holding this button down for 3

seconds. Press the key once quickly to awaken the computer from sleep mode.

5-3. Multimedia Keyboard Internet Key Descriptions

Favorites Press this key to open the Internet Explorer Favorites li

sting. This is where you can store

shortcuts to frequently used files, websites or other items for easy access.

Email Press this key to Start the default e-mail program. If you are not sure what the default e-

mail program is, press this key to find out

. You can reassign the Email key to start

another e-mail program or another application.

WWW

Press this key to Start the Worldwide Web browser or go to your Home Web page. If the

Web browser is already activated it opens the Home Web page. You can reas

sign the

WWW key to start another Web browser, another Home Web page or another

application.

6. Troubleshooting:

If you are experiencing problems with your keyboard or mouse please check the

following:

Symptom—No response between the receiver and mouse or keyboard;

1. Remove the USB Receiver from the computer and check to see if the Receiver’s USB plug

is damaged. If the plug appears normal then reinsert the device into a different USB port on

your PC, there may be a conflict with the previous USB port.

2. Check to see if the batteries in the keyboard and mouse are installed correctly. Make sure

the polarity of the batteries corresponds with the polarity signs in the battery compartment.

3. Replace the batteries to make sure the batteries are not low on power.

4. It is strongly recommended that you do not place the USB Receiver near the computer

monitor, as the magnetic field produced by the monitor may interfere with the reception of the

signal from the keyboard or mouse and cause data errors. For best results place the USB

Receiver in front of the monitor in order to prevent signal disturbance from the monitor.

Symptom—Keyboard is typing the wrong characters;

5. Replace the batteries to make sure the batteries are not low on power.

Symptom—Mouse pointer or cursor moves erratically;

6. Replace the batteries to make sure the batteries are not low on power.

Symptom---Some Hot Keys do not work properly.

There are some HP, Compaq or special PC system configurations where the Multi-

Media Hot Key Keyboard Driver has been installed previously. This will effect the

performance of the Hot Keys keyboard software function. Please make sure the original

Multi-Media keyboard software drivers have been removed from your PC. Then restart

your computer and reinstall the Software CD Driver that is included with this package.

How to remove the Multi-Media keyboard software driver?

1. Please click the Start button/Control panel, select Add/Remove software and find the

original keyboard software for removal.

2. If you cannot find the original keyboard software driver, you should click the Start

button/Control panel/System/Hardware/Device manager/keyboard and find the

original keyboard device name, then left click the keyboard device name to update

the driver. You can select and use “Standard 101/102 key or Microsoft Natural

keyboard”.

3. Restart your PC system and the keyboard should work properly.

FCC AND CE RADIATION NORM

FCC

This equipment has been tested and found to comply with limits for Class B digital device

pursuant to Part 15 of Federal Communications Commission (FCC) rules.

This equipment has been tested and found to comply with the limits of the European Council

Directive on the approximation of the law of the member states relating to electromagnetic

compatibility (89/336/EEC) according to EN 55022 Class B.

FCC and CE Compliance Statement

These limits are designed to provide reasonable protection against frequency interference in

residential installation. This equipment generates, uses and can radiate radio frequency

energy, and if not installed or used in accordance with the instructions, may cause harmful

interference to radio communication. However, there is no guarantee that interference will not

occur in television reception, which can be determined by turning the equipment off and on.

The user is encouraged to try and correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna

Increase the separation between the equipment and the receiver

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected to.

CAUTION!

The Federal Communications Commission warns the user that changes or modifications to the

unit not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

Customer Service

For information regarding the return or exchange of this item within 14 days of

purchase , please visit your Inkstop store location or go to www.inkstop.net to read the

instructions regarding customer service returns procedures. Click on the Satisfaction

Guaranteed icon on the website.

For technical support in regards to operation and installation of this item please call the toll free

number below to obtain assistance. A customer service representative will assist you and

provide operating information on the product.

Please have the following information available when you contact technical support:

Your Name and Address

Date of Purchase

Model Number

Serial Number

Store Name and Address

Type of problem with the unit

To contact the technical support facility, please call

508-435-4830 or 800-639-3803.

Email Support: te[email protected]

Inhaltsverzeichnis

Andere Vuescape Tastatur Handbücher

Vuescape

Vuescape 61000100 Bedienungsanleitung

Beliebte Tastatur Handbücher anderer Marken

Vortexgear

Vortexgear POK3R Bedienungsanleitung

Razer

Razer RZ03-0188 Bedienungsanleitung

Logitech

Logitech RUGGED LITE Bedienungsanleitung

Honeywell

Honeywell ADEMCO 5839 Montageanleitung

Hama

Hama AK-120 Bedienungsanleitung

Rodgers

Rodgers RK-76 Bedienungsanleitung

Logic Controls

Logic Controls KB5000 Series Bedienungsanleitung

Rapoo

Rapoo E9270P Bedienungsanleitung

iKey

iKey DP-88 Bedienungsanleitung

Logitech

Logitech G413 TKL SE Montageanleitung

Keychron

Keychron C1 Bedienungsanleitung

Dahua

Dahua NKB Bedienungsanleitung

Ultimate Technology

Ultimate Technology 500 POS Bedienungsanleitung

Ducky

Ducky Shine 5 Bedienungsanleitung

Mace

Mace MACALLY MERGOKEY Bedienungsanleitung

iKey

iKey KYB-42-KIOSK Bedienungsanleitung

Akko

Akko MX108 Bedienungsanleitung

Viper

Viper V770 Bedienungsanleitung
