Item # __________________________

C.S.I. Section 11420

VULCAN-HARTCOMPANY,P.O.BOX696,LOUISVILLE,KY40201,TEL.1-800-814-2028

502-778-2791 QUOTE&ORDERFAX:1-800-444-0602

A2780

ISO9001

Vulcan-Hart

Co.

F-32629(6-07)

MODEL: 1GR35M FREE STANDING FRYER

1GR35M

FREE STANDING GAS FRYER

STANDARDFEATURES

Stainless steel fry tank, 35 - 40 lb. capacity.

1" full port ball type drain valve.

Stainless steel front top, sides and door.

Set of four 6" adjustable casters.

Twin fry baskets with plastic coated handles.

90,000 BTU/hr. input.

Behind the door millivolt thermostat control adjusts from 200°

to 400°F.

Three heat exchanger tubes positioned for easy cleaning.

Hi-limit shut-off.

Combination gas shut-off valve and pilot ignition system.

Tank brush, stainless steel crumb scoop and clean-out rod.

One year limited parts and labor warranty.

ACCESSORIES

FRYMATE VX15 add-on frymate.

Stainless steel tank cover.

Grease protector strips.

11/4" Rear Gas Manifold Pipe with Shutoff Valves to connect

single fryers in the field - up to four

Single large basket - 13"w x 131/4"d x 51/2"h.

Set of twin baskets - 61/2"w x 131/4"d x 6"h.

Set of tri baskets - 41/4"w x 131/4"d x 51/2"h

3/4"Flexible gas hose with quick disconnect.

SPECIFICATIONS:

35 - 40 lb. capacity free standing model gas fryer, Vulcan-Hart

Model No. 1GR35M. Stainless steel front top, sides and door.

Set of four 6" adjustable casters. Stainless steel fry tank with

threeheat exchangertubesanda "V"shapedcold zone. 1" full

port ball type drain valve. Twinfrybaskets with plasticcoated

handles. 90,000 BTU/hr. input. Behind the door millivolt

thermostat control adjusts from 200° to 400°F.

Overall dimensions: 151/2"w x 301/4"d x 471/8"h. Working height

361/4".

CSA design certified. NSF listed.

SPECIFY TYPE OF GAS WHEN ORDERING.

SPECIFYALTITUDEWHENABOVE2,500FT.

OPTIONS

Second year extended limited parts and labor warranty.

Printed On Recycled Pap

VULCAN-HARTCOMPANY,P.O.BOX696,LOUISVILLE,KY40201,TEL.1-800-814-2028

502-778-2791 QUOTE&ORDERFAX:1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

F-32629(6-07)

1GR35M

FREE STANDING GAS FRYER

OVERALL WORKING TANK FRY COMP. APPROX.

MODEL WIDTH DEPTH HEIGHT HEIGHT SIZE BTU/HR. CAPACITY SHP.WT.

1GR35M 15

"30

"47

"36

" 14" x 14" 90,000 35 - 40 lbs. 200 lbs./91 kg

IMPORTANT

1. A combination valve with pressure regulator is provided with

this unit.

Natural Gas 4.0" (102 mm) W.C.

Propane Gas 10.0" (279 mm) W.C.

2. An adequate ventilation system is required for Commercial

Cooking Equipment. Information may be obtained by writing

to the National Fire Protection Association, Batterymarch

Park, Quincy, MA 02269. When writing refer to NFPA No. 96.

3. All models require a 6" (152 mm) clearance at both sides and

rear adjacent to combustible construction.

4. All models require a 16" (407 mm) minimum clearance to

adjacent open top burner units.

5. This appliance is manufactured for commercial installation

only and is not intended for home use.

SERVICECONNECTIONS:

P1 1/2" (13 mm) rear gas connection (single units).
