This manual describes the Digital Input Module 751-4501

AS-Interface Module 4OUT 24V/2A Single of the modular WAGO-I/O-

SYSTEM 751.

Handling, assembly and start-up are described in the manual of the Fieldbus

Coupler. Therefore this documentation is valid only in the connection with the

appropriate manual.

8 •751-4501 [AS-Interface Module 4OUT 24V/2A Single]

View

WAGO-I/O-SYSTEM 751

AS-Interface Components IP20

2 AS-Interface Components

2.1 AS-Interface Module IP20

2.1.1 751-4501 [AS-Interface Module 4OUT 24V/2A Single]

Digital I/O-Module 4 OUT 24 V / 2 A Single

2.1.1.1 View

751-4501

4OUT 24V 2A

O4 O3 O2 O1AUX

S 8.0.E

ASIFLT

X1 X3

X2 X4

NTERFACE

Status

outputs

Status

AS-interface,

AUX supply

Error

Actuator connectorsAS-interface and

AUX connectors

Programming device

connector

Fig. 2.1.1-1: View gq45010e

2.1.1.2 Description

The AS-Interface module 751-4501 is an economical solution for a fieldbus-

independent and flexible connection of actuators and sensors from the field

and the control cabinet. The module is in accordance with AS-Interface

specification V.3.0.

The module works in standard address area and can be set to one of 31

addresses ranging from 1 ... 31.

The voltage for the sensors is supplied via the AS-Interface cable and is short

circuit protected.

The voltage for the actuators is supplied via the AUX black cable.

The AS-Interface module 751-4501 provides 4 digital 24 V / 2 A outputs.

Sensors, actuators, AS-Interface power supply and actuator supply are

connected using connectors from the WAGO Multi Connection System Mini.

751-4501 [AS-Interface Module 4OUT 24V/2A Single] •9

Connectors

WAGO-I/O-SYSTEM 751

AS-Interface Components IP20

LEDs indicate the status of inputs and outputs, the AS-Interface and actuator

supply as well as a short circuit or overload condition.

2.1.1.3 Connectors

2.1.1.3.1 AS-Interface Cable and AUX Cable

The connections for AS-Interface cable and AUX cable are 4-pole male

connectors for use with female connectors from the Multi Connection System

Mini.

The following table shows the pin assignment of the sockets.

Tab. 2.1.1-1: AS-Interface and AUX Connectors

Connector Pin Function

X1 --- ASI+ AS-Interface power supply +

X1 --- ASI- AS-Interface power supply –

--- X2 AUX+ External power supply +

X2 X4

OUT3

OUT-

OUT1

OUT-

OUT2

OUT-

OUT4

OUT-

ASI+

ASI-

AUX+

AUX-

Fig. 2.1.1-2: AS-

Interface and AUX

Connectors gqxxxx6x --- X2 AUX- External power supply –

Warning

Connectors must only be mated or unmated in “No Load” condition!

2.1.1.3.2 Actuator Connectors

Actuator connections are 4-pole male connectors, both for use with female

connectors from the Multi Connection System Mini.

The following table shows the pin assignment of the sockets.

Tab. 2.1.1-2: Actuator Connectors

Actuator Connectors

Connector Pin Function

X3 X4 OUT- External power supply –

X3 --- OUT1 Switching output +

--- X4 OUT2 Switching output +

X3 --- OUT3 Switching output +

X2 X4

OUT3

OUT-

OUT1

OUT-

OUT2

OUT-

OUT4

OUT-

ASI+

ASI-

AUX+

AUX-

Fig. 2.1.1-3: Actuator

Connectors gqxxxx6x --- X4 OUT4 Switching output +

10 •751-4501 [AS-Interface Module 4OUT 24V/2A Single]

Display Elements

WAGO-I/O-SYSTEM 751

AS-Interface Components IP20

Warning

The unused connectors X5 ... X8 are DC coupled with the AS-Interface

voltage. They shall not be connected externally!

Warning

Connectors must only be mated or unmated in “No Load” condition!

2.1.1.3.3 Programming Connector

On the left side of the front plate is the programming connector. It is a plug for

a DC socket which is compatible with all popular programming adapters, for

example Pepperl+ Fuchs VAZ-PK-1.5M-V1-G.

Please note manufacturer documentation for the operation of the programming

device..

2.1.1.4 Display Elements

Tab. 2.1.1-3: Display Elements

LED Designation Status Function

off Output 1, reset

yellow

Status

DO1 on Output 1, set

off Output 2, reset

yellow

Status

DO2 on Output 2, set

off Output 3, reset

yellow

Status

DO3 on Output 3, set

off Output 4, reset

yellow

Status

DO4 on Output 4, set

off OK

on Configuration error

FLT

red Error

blinking

Short circuit / sensor

supply overload or actuator

supply is missing or output

driver error message

(Open-Load-Detection)

off AS-Interface supply error

ASI

green

AS-Interface

supply on AS-Interface supply OK

off Actuator supply error

O3 O1O4 O2

FLT ASI

AUX

Fig. 2.1.1-4: Display

Elements gq45012x

AUX

green

Actuator

supply on Actuator supply OK

2.1.1.5 Operating Elements

The AS-Interface module 751-4501 has no operating elements.

Inhaltsverzeichnis

Andere WAGO Steuereinheit Handbücher

WAGO

WAGO 750-429/040-001 Bedienungsanleitung

WAGO

WAGO 750-564 Bedienungsanleitung

WAGO

WAGO SPEEDWAY 767 Series Bedienungsanleitung

WAGO

WAGO 750-451 Bedienungsanleitung

WAGO

WAGO 750-430/040-000 Bedienungsanleitung

WAGO

WAGO 750-654 Bedienungsanleitung

WAGO

WAGO 750-563/040-000 Bedienungsanleitung

WAGO

WAGO 750-606/040-000 Bedienungsanleitung

WAGO

WAGO 750 Series Bedienungsanleitung

WAGO

WAGO I/O-SYSTEM 750 Bedienungsanleitung

WAGO

WAGO 761-113 Bedienungsanleitung

WAGO

WAGO I/O-SYSTEM 751-3002 Bedienungsanleitung

WAGO

WAGO SPEEDWAY 767 Series Bedienungsanleitung

WAGO

WAGO WAGO-I/O-SYSTEM 750 Series Bedienungsanleitung

WAGO

WAGO 767-4803/000-800 Bedienungsanleitung

WAGO

WAGO 751-5702 Bedienungsanleitung

WAGO

WAGO 750-1405/040-000 Bedienungsanleitung

WAGO

WAGO 750 Series Bedienungsanleitung

WAGO

WAGO I/O-SYSTEM 751-4001 Bedienungsanleitung

WAGO

WAGO 750-431/040-000 Bedienungsanleitung

WAGO

WAGO 750-515 Bedienungsanleitung

WAGO

WAGO 750-477 Bedienungsanleitung

WAGO

WAGO SPEEDWAY 767 Series Bedienungsanleitung

WAGO

WAGO 753-1630 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung

Flyron

Flyron FN-BC04 Bedienungsanleitung
