Wahsega Carina PBX Montageanleitung

Carina PBX

Installer’s Guide

Getting Started

This step-by-step guide will help you install your

Wahsega Carina PBX.

Carina PBX Installation Guide Page 2 11.11.2020

What’s in the Box

(1) Carina PBX

(1) 2-Pin male connector

(1) 6-Pin male connector

(1) 8-Pin male connector

(1) Ferrite cable clamp

Carina PBX Installation Guide Page 3 11.11.2020

What You Will Need

PoE power

Power-over-Ethernet (PoE 802.3af) switch

Network cable (Cat 5e or Cat 6)

Carina PBX Installation Guide Page 4 11.11.2020

Wiring

Power

Option A: To use Power-over-Ethernet (POE 802.3af), route a Cat 5e or

Cat 6 Ethernet cable from a PoE switch or injector to the LAN port.

Option B: Alternately, use the included 2-pin male connector to

connect +9-16VDC and Ground wires for power. Use standard

(unpowered) Ethernet for data.

NOTE: Use either POE or 9-16V for power. DO NOT USE BOTH.

Status

The status LED will increase in brightness as the Carina PBX is powering

up and will remain steadily lit when the unit is successfully powered.

Status

LED

Ethernet or POE

If using Power Option A = POE 802.3af

If using Power Option B = Ethernet

Do Not

Use

Power

Option B

Reset

Carina PBX Installation Guide Page 5 11.11.2020

Dimensions

Front

Rear

Carina PBX Installation Guide Page 6 11.11.2020

Side

Carina PBX Installation Guide Page 7 11.11.2020

Standards Compliant

This product is designed and manufactured in the USA.

ROHS compliant

Temperature rating -40C to +60C.

Carina PBX Installation Guide Page 8 11.11.2020

Carina PBX

WL-PBX-CAR

Installation Guide
