Watchguard QMS 1000 Bedienungsanleitung

WatchGuard® Technologies, Inc.

WatchGuard® Quarantine Management Server

Appliance Models: QMS 500 and QMS 1000

Quick Start Guide

WatchGuard® Quarantine Management Server

Additional QMS 1000 items

Registration and Conguration

• Find the serial number on your device and record it.

• Go to http://www.watchguard.com/activate

• Log in.

NOTE: If you are new to WatchGuard®, follow the instructions provided at the URL above to create a prole.

• Follow the instructions on the screen to enter your serial number and receive a

feature key.

NOTE: If you will not have an Internet connection during the setup procedure, it is highly recommended to

copy your feature key to a text le during the activation process.

Conguration Checklist

• To congure your WatchGuard device, you must collect the following information

about your network:

Network Information Example Settings Your Settings

Hostname hostname

Domain Name example.com

IP Address 10.0.1.10

Subnet Mask 255.255.0.0

Gateway Address 10.0.1.1

Name Server Address 10.0.2.53

Default User ID admin

Default Password admin

Organization Name example.com

Server Admin Email [email protected]om

Serial Number B0E112345-1234

Connect your WatchGuard® Quarantine Management Server

Connection and Installation

• Install the device in a secure location.

• Connect a monitor and a keyboard (USB or PS/2) to the back of the device.

• Connect the device directly to the LAN (Local Area Network). Use the rst onboard

Ethernet connector (NIC 1) at the left side of the back panel.

• Connect the power cord to the power socket on the back panel of the device.

Console Installation

• To power on your device, press the power button at the right side of the front panel.

When the device is ready, startup options appear on the monitor.

• Select F2, and then select OK.

NOTE: The F2 option is chosen by default after a few seconds.

• Select the Auto installation type. The le system is installed.

• Select OK to begin the network conguration.

• Enter the Network Settings. Use the information from your checklist in Step 2, then

select OK.

NOTE: To connect to your device with a web browser at the end of the console installation, only your LAN

information is required.

• Select a Region, Country and Time zone.

• The initial console conguration is now complete and the system console screen

appears. To continue with the installation, you must connect to the device with a web

browser.

NOTE: After the console installation is complete, this warning message appears: “Mail System is stopped”.

Before you start the mail system, you must congure the spam quarantine settings.

Switch

Ethernet

cable

Ethernet cable

QMS 500

NIC 1

Web UI Setup Wizard

• Open a web browser and type the IP address of the device. Use the address you set for

your device in Step 4, for example: https://10.0.1.10.

NOTE: Because your device uses a self-signed certicate, a certicate warning appears in your browser.

• On the Login page, type the default user ID (admin) and the default password (admin).

• Type the Organization Name and Server Admin Email address. Use the information

from the Conguration Checklist you completed in Step 2.

• Change the default password.

• Select Continue to complete the initialization.

• The Web UI Setup Wizard is now complete, and the feature key page appears.

NOTE: The mail system is initially in a stopped state. Before you start the mail system, you must congure the

spam quarantine settings.

Web Wizard

Next Steps

Congratulations! You have nished the basic setup of your WatchGuard® Quarantine

Management Server. You can use the Web UI to continue all conguration and management

tasks. Before you begin, we strongly recommend that you use the instructions on this page to:

• Add a Feature Key to the WatchGuard Quarantine Management Server

• Download Latest Software Updates

• Install Software Updates

Add a Feature Key to the WatchGuard Quarantine Management Server

• Log in to the Web UI.

• Select Administration > System > Feature Key, and then click Update.

• Copy the text of the feature key le you received in Step 1, and paste it in the text box.

• Click Update Key.

Download Latest Software Updates

The Security Connection feature contacts WatchGuard’s support servers to check for new

software updates.

• Log in to the Web UI.

• Select Administration > Software Updates > Security Connection.

• Select the Enabled option, and then enable the Auto Download option to allow software

updates to be downloaded automatically.

NOTE: These updates are not automatically installed. You must install the updates manually as described in the

next section.

• Click Apply, and then click the Connect Now button to run Security Connection immediately

and check for new software updates.

Install Software Updates

• Select Administration > Software Updates > Updates.

• The Software Updates page shows updates that are Available Updates (loaded onto the

system, but not applied) and Installed Updates (applied and active).

• Updates downloaded by Security Connection appear in the Available Updates section.

NOTE: If you downloaded an update manually, click Browse and navigate to the downloaded software update le on

your local system, then click Upload.

• Select the software update in the Available Updates section, and then click Install.

NOTE: After you apply software updates, you must restart the device.

For more information about how to congure your WatchGuard Quarantine Management

Server:

• See the WatchGuard Quarantine Management Server Installation Guide located on the Product

Documentation CD-ROM.

• From the Web UI, select Support > Online Manual.

• Go to www.watchguard.com/help/documentation and download the WatchGuard Quarantine

Management Server User Guide.

WatchGuard® Quarantine Management Server Quick Start Guide

ADDRESS: 505 Fifth Avenue South, Suite 500, Seattle, WA 98104

WEB: www.watchguard.com • U.S. SALES: 1.800.734.9905 • INTERNATIONAL SALES: +1.206.613.0895

Core, Peak, and LiveSecurity are either trademarks or registered trademarks of WatchGuard Technologies, Inc.

in the United States and/or other countries. All other trademarks and tradenames are the property of their

respective owners. P.N. 352-3676-001 021910

1.877.232.3531 +1.206.613.0456 www.watchguard.com/support

(U.S. and Canada) (all other countries)

WATCHGUARD TECHNICAL SUPPORT
