SECTION I. INTRODUCTION
Your new Reverse Osmosis (R.O.) Drinking Water
System uses a combination of ltration technologies
to reduce unwanted contaminants in a water supply.
The following steps combine to give you the best in
clear sparkling drinking water:
MECHANICAL FILTRATION/ACTIVATED
CARBON–The Sediment/Carbon Module has
been designed to reduce the larger particles
such as silt, rust and scale. Its 5 micron
(equal to 0.0002 inch) nominal rating
helps
to give maximum life to the R.O. Membrane.
The activated carbon in the Prelter has been
designed to reduce any chlorine that may be
present in the feed water. This pretreatment is
also necessary for membrane protection.
REVERSE OSMOSIS MEMBRANE–The R.O.
Membrane is the heart of the ltration system.
It is designed to reduce the dissolved mineral
content of the water. Minerals picked up in the
environment by the water are measured as Total
Dissolved Solids (TDS). In the Reverse Osmosis
process, dissolved minerals are separated from
the incoming water (Feed Water) to produce
the product water (the Permeate). The excess
minerals are rinsed to drain (the Reject Water).
The membrane is a specially constructed, fully
aromatic polyamide lm, and is classied as a
Thin Film Composite (T.F.C.).
The spiral wound construction of the R.O.
Membrane provides maximum surface area
for water production and is less susceptible
to fouling by particulate matter, turbidity and
colloidal materials.
ACTIVATED CARBON–The Activated Carbon
Module contains carbon particles with a vast
network of pores. The tremendous surface
area of these pores (typically 800–1200 square
meters per gram of carbon) gives the carbon
very good adsorptive sites for substances that
contribute to tastes and odors.
IN–LINE ACTIVATED CARBON POST FILTER–
The In–Line Activated Carbon Post Filter is
located after the Holding Tank and has been
designed to reduce the tastes and odors that
may pass through the system. It adds a nal
polish to the water.
AUTOMATIC SHUTOFF VALVE–The ASO
Valve senses when the Holding Tank is full and
closes the feed water supply to prevent excess
reject water from going to drain when the unit is
not producing water.
WATER QUALITY MONITOR–The Water
Quality Monitor has been integrated into the
faucet base for instant monitoring at the touch
of a button. The monitor compares the level of
the Total Dissolved Solids in the incoming (feed)
water versus the product water and calculates
the percent rejection. The monitor is preset to
indicate a level of 75% rejection.
A green light indicates that the percent rejection
is at or above the set (desired) value and that
the system is producing quality water.
An amber light indicates that the product water
quality is less than acceptable. Because the
Water Quality Monitor was designed to operate
best while the system is making water, a false
reading may occur if tested when your R.O.
drinking water system is not making water.
Please empty the Holding Tank, wait 15 minutes
for the system to begin making water, and test
your water quality again. If the Water Quality
Monitor light is still amber, please contact a
water treatment professional for service. The
Water Quality Monitor requires a 9 volt battery,
which is included.
IMPORTANT NOTICES:
This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's
responsibility to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the
system is performing satisfactorily. See the test kit(s) for sampling instructions.
This system is acceptable for treatment of inuent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite
in combination measured as N and is certied for nitrate/nitrite reduction only for water supplies with a pressure of
280 kPa (40 psig) or greater.
This system conforms to NSF/ANSI Standard 58 for pentavalent arsenic reduction. See the Performance Data Sheet and
Arsenic Facts section for an explanation of reduction performance.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNkNOWN QUALITY, WITHOUT
ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
Systems certied for cyst reduction may be used on disinfected water that may contain lterable cysts.
