WaterAce WA62UP Bedienungsanleitung

Owner’s Manual

Electric Drill Utility Pump

WA63UP Drill Pump

WA62UP

Drill Pump with Kit

General Safety . . . . . . . . . . . . . . . . . . . . 2

Specications. . . . . . . . . . . . . . . . . . . . . 3

Assembly . . . . . . . . . . . . . . . . . . . . . . . 4

Assembly/Maintenance . . . . . . . . . . . . . 5

Troubleshooting/Warranty . . . . . . . . . . . 6

Warranty . . . . . . . . . . . . . . . . . . . . . . . . .7

TABLE OF CONTENTS

ALWAYS USE EXTREME CAUTION

maintaining this product!

Important Safety Instructions

Carefully read and follow all safety

instructions in this manual and on pump.

SAVE THESE INSTRUCTIONS – This manual

contains important instructions that should be

followed during installation, operation, and

maintenance of the product.

Save this manual for future reference.

Safety Labels

This is the safety alert symbol. When you

see this symbol on your pump or in this manual,

look for one of the following signal words and be

alert to the potential for personal injury!

Indicates a hazard which, if

not avoided, will result in death or serious injury.

Indicates a hazard which,

if not avoided, could result in death or serious

injury.

Indicates a hazard which, if

not avoided, could result in minor or moderate

injury.

NOTICE indicates practices not related to

personal injury.

Keep safety labels in good condition. Replace

missing or damaged safety labels.

General Safety

Risk of burns. Do not

touch an operating motor. Motors are de-

signed to operate at high temperatures. To

avoid burns when servicing pump, allow it to

cool for 20 minutes after shut-down before

handling.

Do not allow pump or any system compo-

nent to freeze. To do so will void warranty.

Pump water only with this pump.

Periodically inspect pump and system com-

ponents.

Wear safety glasses at all times when work-

ing on pumps.

Risk of explosion. Pump

body may explode if used as a booster

pump.

NOTE: Not recommended to use for drinking

water

GENERAL SAFETY

STOP Before you start

Warranty

WHAT IS COVERED

Thi s pump i s guar anteed for 90days from d ate ofpurchase. It will pump clean water and motor oil.

WHAT IS NOT COVERED

Pumping anything other than clean water and motor oil, and if damaged due to misuse from primarilybeing run without water or oil in the

pump (running the pump dry).

Contact the Cu stomer Service Team at1-844-883-1872 or visit www.HomeDepot.com.

Pre-Assembly

PRODUCT SPECIFICATIONS

Maximum Head at 1,200 RPM 45 ft.

Maximum Head at 800 RPM 32 ft.

Rate of Flow at 1,200 RPM 90 GPH

Rate of Flow at 800 RPM 60 GPH

Priming Self-priming up to 8 ft. vertical ly

Lubrication Pressure-lubricated bearings, shaft, and seal

PLANNING OPERATION

Carefully unpack and inspecteach part. Compare parts with the Package Contents list. If any part appears missing or damaged, do not

operate this product. Contact the Customer Service Team.

TOOLS REQUIRED

Drill Garden h ose

Warranty

WHAT IS COVERED

Thi s pump i s guar anteed for 90days from d ate ofpurchase. It will pump clean water and motor oil.

WHAT IS NOT COVERED

Pumping anything other than clean water and motor oil, and if damaged due to misuse from primarilybeing run without water or oil in the

pump (running the pump dry).

Contact the Cu stomer Service Team at1-844-883-1872 or visit www.HomeDepot.com.

Pre-Assembly

PRODUCT SPECIFICATIONS

Maximum Head at 1,200 RPM 45 ft.

Maximum Head at 800 RPM 32 ft.

Rate of Flow at 1,200 RPM 90 GPH

Rate of Flow at 800 RPM 60 GPH

Priming Self-priming up to 8 ft. vertical ly

Lubrication Pressure-lubricated bearings, shaft, and seal

PLANNING OPERATION

Carefully unpack and inspecteach part. Compare parts with the Package Contents list. If any part appears missing or damaged, do not

operate this product. Contact the Customer Service Team.

TOOLS REQUIRED

Drill Garden h ose

SPECIFICATIONS

Maximum Head at 1,200 RPM 45 ft.

Maximum Head at 800 RPM 32 ft.

Rate of Flow at 1,200 RPM 90 GPH

Rate of Flow at 800 RPM 60 GPH

Priming Self-priming up to 8 ft. vertically

Lubrication Pressure-lubricated bearings, shaft and seal

PART DESCRIPTION REPLACEMENT PART NO. QUANTITY

A Oil tube, 30 “ x 1/4” O.D. EF60DRILL003 1

B 3” Adapter tube (3/8” O.D. & 1/4” I.D.) EF60DRILL005 1

C Pump EF60DRILL001 1

D 3’ x 1/2” Garden hose with brass female tting EF60DRILL006 1

TOOLS REQUIRED

Drill Garden Hose

TOOLS REQUIRED

Carefully unpack and inspect each part. Pull oil tube completely out of garden hose. Compare parts with the

Package Contents list. If any part appears missing or damaged, do not operate this product. Contact the

Customer Service Team.

CONTENTS

OUT

NOTE: If using a garden hose on the suc-

tion side of pump, then the hose must be

sti walled and be kept as short as pos-

sible. If not, then there is a risk of the hose

collapsing and blocking suction. There

can be no leaks in the suction line or the

pump will not prime.

ASSEMBLY

Preparing to pump motor oil using

adapter and tube 2

Preparing to pump clean water using

garden hose connected to pump

• Remove the dipstick from the engine/motor

from which you plan to remove motor oil.

• Cut at a 60 degree angle one end of tube (A).

• Lubricate the pump impeller by placing several

drops of mineral or vegetable oil on the

impeller at inlet port (1).

• Place the adapter tube (B) into the inlet port (1)

of the pump (C) as far as it will go in.

• Insert the end of the tube (A) with the

60 degree cut into the motor dipstick hole.

• Attach the garden hose (D) to port (2).

• Attach drill pump with tubes and hose to drill.

• Connect drill motor power cord to a 3-wire

grounded plug.

• Inspect the washer in the inlet hose to

make sure it is in good condition and installed

in the hose.

• Lubricate the pump impeller by placing several

drops of mineral or vegetable oil on the

impeller at inlet port (1).

• Connect hose (D) to the port and suction hose

to intlet port on pump (C) outlet.

• Attach the drill pump with hoses to the drill.

• Connect the drill motor power cord to a 3-wire

grounded plug.

Ensure drill is not connected

to electrical service as you begin this process.

Ensure drill is not connected

to electrical service as you begin this process.

Keep the inlet hose as short

as possible

The combined height of the

inlet and outlet hose should be no higher than 8

ft. above the water source and/or not more than

25 ft. horizontally from the water source.

To minimize the pump rotating

on the drill, rmly grip the drill pump and hold it

as you start the drill.

To minimize the pump rotating

on the drill, rmly grip the drill pump and hold it

as you start the drill.

Ensure motor oil is drawn into

the drill pump within 15-20 seconds to avoid

damaging the pump. If it does not, check to en-

sure the tube (A) is rmly inserted in the adapter

(B) and that the adapter (B) is rmly installed in

pump (C), ensure the tube is not crimped and

that the tube is fully inserted in the dipstick hole.

NOTE: Motor oil should be removed when at

room temperature.

Ensure water is drawn into the

drill pump within 15-20 seconds to avoid damag-

ing the pump. If it does not, check to ensure the

hose connections are rmly installed to the pump

pump (C), ensure none of the hoses are crimped

and that the suction hose is fully inserted in the

water source.

NOTE: Water should be removed when it is at

room temperature.

If water has suspended solids,

a strainer should be installed on hose (D )that is

in the water. A piece of door screen tied to end

of hose that is in the water would help keep any

solids out of the hose.

A B

1 C

ASSEMBLY AND MAINTENANCE

Preparing to pump motor oil using

adapter and tube 2

Preparing to pump clean water using

garden hose connected to pump

Risk of electrical shock, per-

sonal injury or death. Never touch or handle

driven pump with wet hands or when standing on

a wet surface or in water.

Be sure the drill is always

electrically grounded to an acceptable electrical

ground.

NOTE: Keep the suction line as short as possible

and lled with water.

NOTE: Never operate the impeller dry.

Operating it dry for as little as 30 seconds can

ruin the pump. The impeller must be oiled to

reduce friction or wear.

NOTE: Never operate the pump dry for prolonged

periods of time, as this will damage the pump.

NOTE: Use a strainer on the end of the inlet

hose, when pumping liquids with small solids to

extend pump life.

NOTE: Oil becomes thick in cold weather. Oil

must be kept thin for the pump to work properly.

NOTE: Electric drills are not intended to be oper-

ated unattended or continuously. Doing either of

these can cause the pump and drill to fail.

NOTE: Any air leaks in the suction line will pre-

vent the pump from priming.

• Use the unit within the liquid temperature

range of 40°F to 120°F.

• Inspect hoses thoroughly before each use,

making surethat all connections are tight and

that the hoses are all in good condition.

• Be sure that the inlet line (1) is airtight and

submerged in uid. The inlet (1) and dicharge

(2) lines should be free of kinks and other ow

restrictions.

• Wet the impeller located inside the pump with

pumped uid and/or cooking mineral oil

before starting the pump. This inproves the

priming process.

• Start the drill pump. Self-priming should

occur within 30 seconds. The pump will self-

prime up to an 8 ft. vertical lift. Be sure

that the liquid enters the pump within 15 to

20 seconds. If not, refer to the assembly

instructions and also the Troublshooting

section.

• If pump fails to prime, ensure that there are no

air leaks or obstructions in suction line.

• Lubricate the impeller with cooking oil or mineral oil.

• Always ush with clear water after using.

• Keep the suction line as short as possible and prime the line (ll with liquid) when possible before

starting the pump.

• Do not use suction hose that can collapse due to vacuum pressure.

NORMAL USE OF THE PUMP CAUSES WEAR. TO EXTEED PUMP LIFE:

OUT

TROUBLE SHOOTING

PROBLEM PROBABLE CAUSE CORRECTIVE ACTION

The pump will not prime Air is leaking into the inlet hose Replace the washer in the hose

or connection. tting or replace the hose.

The inlet hose is clogged. Clean or replace the hose.

The hose collapsed due to inlet Notch the end of the inlet line

line suction on a at surface. where it meets the at surface, use

suction rated hose

The impeller, body and end cover Replace the pump.

are worn from pumping abrasives.

The impeller blades are missing Replace the pump.

or charred from dry running.

Air leak in at the seal or o-ring. Replace the pump.

The shaft turns but the impeller Replace the pump.

does not turn.

Drill speed is too slow. Increase drill speed

There is a low ow rate. The drill is running too slowly. Increase the drill speed or use

another 1/4” drill or larger.

There is restriction in the inlet Clean or replace the hoses. Check

or discharge hoses. hoses to eliminate any sharp

bends or kinks in the lines. Use

The hose diameter is too small. larger diameter hose of high quality.

Liquid is leaking where The lip seal is damaged. Replace the pump.

the shaft enters the

pump body.

LIMITED WARRANTY

This pump is warranted to be free from defects in material and workmanship and to perform within applicable

specications for a period of 90 days. Obligation under this warranty is limited to repairing or replacing any part thereof,

which shall within two years be returned to us with transportation charges prepaid, and proved to be defective.

The above limited warranty takes the place of all other warranties, express or implied and correction of such defects by

replacement or repair shall constitute a fulllment of all obligations under the terms of the warranty, which specically

EXCLUDES any incidental damages caused by or associated with this product or its use. The warranty does not cover

any unit which has been damaged either in transit or by misuse, accident or negligence. No warranty or representative not

contained herein shall be binding.

1899 Cottage Street

Ashland, Ohio 44805

Telephone: 1-844-394-2604

Dieses Handbuch passt für folgende Modelle

Andere WaterAce Wasserpumpe Handbücher

WaterAce

WaterAce R520C-T7-01 Bedienungsanleitung

WaterAce

WaterAce WA33FPM Bedienungsanleitung

WaterAce

WaterAce WA50RSWW Bedienungsanleitung

WaterAce

WaterAce R25SP-01 Bedienungsanleitung

WaterAce

WaterAce WA50SASW Bedienungsanleitung

WaterAce

WaterAce R200A Bedienungsanleitung

WaterAce

WaterAce WACS Series Bedienungsanleitung

WaterAce

WaterAce R106 Bedienungsanleitung

WaterAce

WaterAce R106 Bedienungsanleitung

WaterAce

WaterAce R7L Bedienungsanleitung

WaterAce

WaterAce R50VLT Bedienungsanleitung

WaterAce

WaterAce R3PGI Bedienungsanleitung

WaterAce

WaterAce R7W Bedienungsanleitung

WaterAce

WaterAce WAPLS Series Bedienungsanleitung

WaterAce

WaterAce RTS5 1/2 HP Bedienungsanleitung

WaterAce

WaterAce R1030 Bedienungsanleitung

WaterAce

WaterAce RPT7 Bedienungsanleitung

WaterAce

WaterAce R5V Bedienungsanleitung

WaterAce

WaterAce WABUP Bedienungsanleitung

WaterAce

WaterAce WAUP Series Bedienungsanleitung

WaterAce

WaterAce R100U Bedienungsanleitung

WaterAce

WaterAce R6S Bedienungsanleitung

WaterAce

WaterAce R33SU-01 Bedienungsanleitung

WaterAce

WaterAce R7PBS Bedienungsanleitung

Beliebte Wasserpumpe Handbücher anderer Marken

Neptun

Neptun NPHW 5500 Bedienungsanleitung

Sensidyne

Sensidyne Gilian BDX-II Montage- und Bedienungsanleitung

Draper

Draper 47808 Bedienungsanleitung

Trolla

Trolla 12820 Bedienungsanleitung

Sunfab

Sunfab SVH Series Bedienungsanleitung

WilTec

WilTec 50740 Bedienungsanleitung

Fieldmann

Fieldmann FVC 5015 EK Bedienungsanleitung

Everbilt

Everbilt EFSUB5-122HD Bedienungsanleitung

Graco

Graco Husky 3300e Bedienungsanleitung

esotec

esotec 101018 Bedienungsanleitung

moyno

moyno 2000 CC Bedienungsanleitung

Becker

Becker BASIC VASF 2.80/1-0.AC230 Bedienungsanleitung

Sykes AmeriPumps

Sykes AmeriPumps GP100M Fehlerbehebungshandbuch

DUROMAX

DUROMAX XP WX Series Bedienungsanleitung

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Bedienungsanleitung

Franklin Electric

Franklin Electric IPS Bedienungsanleitung

Xylem

Xylem e-1532 Series Bedienungsanleitung

Milton Roy

Milton Roy PRIMEROYAL Bedienungsanleitung
