USER MANUAL
THERMAL TRANSFER
BAR CODE PRINTER
WAVECOM TT040-50
WAVECOM INSTRUMENTS PTY LTD©
www.wavecom.com.au
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
1
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
2
Table of Contents
Copyright Declaration 3
Introduction 3-4 Introduction
Product Introduction
Compliances
Operations Overview 4-7
Printer purchased as part of Wavecom Test n Print Unit
Unpacking and Inspection
Printer Overview
Front View
Interior View
Rear View
Setup 8
Printer
Printer purchased as part of Wavecom Test n Print Unit
Printer setup when connecting to computer
Loading the Media 8-10
Loading the Ribbon 11-12
LED and Button Functions 13-19
LED Indicator
Regular Button Function
Power on Utilities
Gap/Black mark Sensor Calibration
Gap/Black Mark Calibration, Self-test and Dump Mode
Printer Initialization
Set Black Mark Sensor as Media Sensor and Calibrate the Black Mark Sensor
Set Gap Sensor as Media Sensor and Calibrate the Gap Sensor
Skip AUTO.BAS (not applicable)
Troubleshooting 20-21
LED Status
Print Problem
Maintenance 22-23
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
3
Copyright Declaration
Information in this document is subject to change without notice and does not
represent a commitment on the part of Wavecom Instruments Pty. Ltd.
No part of this manual may be reproduced or transmitted in any form by any means, for
any purpose other than the purchaser’s personal use, without the expressed written
permission of Wavecom Instruments Pty. Ltd.
Introduction
Product Introduction
Thank you for purchasing Wavecom bar code printer. Although the printer has a small
footprint, it delivers reliable, superior performance.
This printer provides direct thermal printing at user selectable speed of: 2.0, 3.0, 4.0 or
5.0 ips. It accepts roll feed and die-cut media with gap or black mark. All common bar
codes formats are available. Fonts and bar codes can be printed in 4 directions, 8
different alphanumeric bitmap fonts and built-in scalable font capability. You will enjoy
trouble free, high throughput for printing labels with this printer.
NOTE: - You can also try SPECIAL WHITE LEADER Wavecom colour labels designed for
easy Barcode colour scanning.
Compliances
CE Class B:
EN55022: 1998+A1: 2000+A2: 2003
EN55024: 1998+A1: 2001+A2: 2003 IEC 61000-4 Series
EN61000-3-2: 2006 & EN61000-3-3: 1995+A1: 2001
FCC Part 15, Class B
UL, CUL: UL60950-1
C-Tick:
CFR 47, Part 15/CISPR 22 3rd Edition: 1997, Class B
ANSI C63.4: 2003
Canadian ICES-003
TÜV/Safety: EN60950-1 / IEC 60950-1
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
4
CAUTION
1. THE MAIN BOARD INCLUDES A REAL TIME CLOCK FEATURE AND HAS A
LITHIUM BATTERY INSTALLED.
2. RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE
3. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER
INSTRUCTIONS
Note：
The maximum printing ratio per dot line is 15% for this printer. To print the full web
black line, the maximum black line height is limited to 40 dots, which is 5mm for
203 DPI resolution printer and 3.3mm for 300 DPI resolution printer.
Operations Overview
Printer purchased as part of Wavecom Test n Print Pack
When TT040-50 is purchased as part of a Wavecom Test n Print Unit,
the Printer is ready and fully setup to use. Owner’s Barcode Label
Artwork may be installed as an option.
Unpacking and Inspection
This printer has been specially packaged to withstand damage during
shipping. Please carefully inspect the packaging and printer upon
receiving the bar code printer. Please retain the packaging materials in
case you need to reship the printer.
Unpacking the System, the following items are included in the carton.
One printer unit
User Manual, quick start guide and Drivers on the WinPATS CD
One quick start installation guide
One power cord
One auto switching power supply
One USB interface cable
One paper core
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
5
If any parts are missing, please contact your Supplier or Wavecom
Instruments.
Printer Overview
Front View
1. LED indicator
2. Feed button
3. Paper exit chute
4. Media view window
5. Top cover open lever
1
2
5
4
3
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
6
Interior View
1. Ribbon access cover 8. Media guide
2. Ribbon rewind hub 9. Top cover support
3. Ribbon rewind gear 10. Black mark sensor
4. Print head 11. Platen roller
5. Ribbon supply hub 12. Gap sensor (transmitter)
6. Gap sensor (receiver) 13. Media guide adjuster knob
7. Media holders 14. Top cover
4
11
6
8
10
7
1
12
5
2
3
9
13
14
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
7
Rear View
1. Power switch
2. Power jack socket
3. USB interface
4. USB host (Factory option)
5. RS-232C interface / Ethernet interface (Option)
6. SD card socket (Not Applicable to this unit)
2
4
3
1
5
6
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
8
Setup
Printer
Printer purchased as part of Wavecom Test n Print Pack
Printer when purchased as part of a Wavecom Test n Print Unit is already fully
setup and ready to use.
Printer setup when connecting to computer
Place the printer on a flat, secure surface.
Make sure the power switch is set to “off”.
Connect the printer to the computer with the provided USB cable.
Plug the power cord into the AC power cord socket at the rear of the printer, and
then plug the power cord into a properly grounded power outlet.
Note: Please switch OFF printer power switch prior to plug in the power cord to
printer power jack.
Loading the Media
Loading the Media
Open the printer top cover by pulling the tabs located on each side towards the front
of the printer, and then lift the top cover to the maximum open angle.
Wavecom Instruments Thermal Transfer Bar Code Printer User Manual
9
Separate the media holders to the label roll width.
Place the roll between the holders and close them onto the core. Place the paper, printing side
face up, through the media guides, media sensor and place the label leading edge onto the
platen roller.
