Webasto 533 Bedienungsanleitung
Vorwahluhr 1533
Digital timer 1533
Horloge de programmation 1533
Timer programmabile 1533
Programador 1533
Schakelklok 1533
Timer 1533
Tidur 1533
Tidsur 1533
Ajastin 1533
Programator zegarowy 1533
Программируемый таймер 1533
定时器
定时器定时器
定时器
1533
1301138F04_BA_VWU_1533.BOOK Page 1 Monday, October 1, 2012 11:23 AM
itte ausklappen!
Unfold!
Veuillez rabattre S.V.P. !
Aprire la pagina!
¡Desplegar, por favor!
Svp. uitvouwen!
Fold ud!
Vik ut!
rett ut!
Avaa!
ProszęrozłoŜyć!
Разверните!
请打开
请打开请打开
请打开！
！！
！
1301138F04_BA_VWU_1533.BOOK Page 2 Monday, October 1, 2012 11:23 AM
1301138F04_BA_VWU_1533.BOOK Page 3 Monday, October 1, 2012 11:23 AM
D
13
GB
Legend 14
General Information 15
Operation 17
Switching on 18
Switching off 18
Setting the time 19
Checking the time 19
Setting Mode 19
Program start of heating or ventilation 21
Deactivate preset time 21
Select and activate preset time 22
Setting Operating Time 23
Set remaining time 23
1301138F04_BA_VWU_1533.BOOK Page 13 Monday, October 1, 2012 11:23 AM
14
GB
Operating and Maintenance Instructions
Digital timer 1533 with 3 time settings
1 Time / remaining time
2 Ventilation mode indicator
3 Forward (viewing the time)
4 Program selection
Program number indicator
6 Instant heat
7 Symbol for setting / viewing the time
8 Reverse (viewing the time)
9 Heating operation indicator
1301138F04_BA_VWU_1533.BOOK Page 14 Monday, October 1, 2012 11:23 AM
15
D
GB
General Information
Dear Webasto customer!
We are delighted that you have selected this Webasto product.
We assume that the workshop / service partner that carried out the installation
explained to you the operation and principle of functioning of your digital timer
1 33 to your complete satisfaction.
With these operating and maintenance instructions we would like to provide you
with an overview of the use of the digital timer 1 33.
The digital timer 1 33 complies with the homologation approval in accordance
with the directive 72/24 /EEC (EMC).
1301138F04_BA_VWU_1533.BOOK Page 15 Monday, October 1, 2012 11:23 AM
16
GB
The heater must not be operated:
•In filling stations and tank farms.
•At locations at which highly flammable gases or
dusts can form, and at locations at which highly
flammable liquids or solid materials are stored (e.g.
near fuel, coal and wood dust, grain warehouses,
dry grass and leaves, cardboard , paper, etc.).
•In enclosed rooms (e.g. garages), not even via the
timer or Telestart.
!
Danger of explosion
and suffocation!
1301138F04_BA_VWU_1533.BOOK Page 16 Monday, October 1, 2012 11:23 AM
17
D
GB
Operation
The time for starting heating operation can be preset precisely anywhere between
"1 minute" and "24 hours". Three starts can be programmed, but only one can
be activated.
The heating time can be programmed as desired between 10 minutes and
60 minutes.
NOTE:
Take into account summer time or winter time!
Operation of the timer is designed so that the symbols flash rapidly in setting
mode. If no button is pressed for seconds, the displayed time will be saved.
The display changes at high speed when the buttons or are pressed for
more than 2 seconds.
1301138F04_BA_VWU_1533.BOOK Page 17 Monday, October 1, 2012 11:23 AM
18
GB
Switching on
Manually: by pressing the button "Instant heat" .
The heating time and the symbol for heating operation are displayed.
The heating time disappears after 10 seconds.
Automatically: upon reaching the preset starting time for heating or ventilation.
The program number and the symbol for heating or ventilation are
displayed.
Switching off
Manually: by pressing the button "Instant heat" .
Automatically: via the programmed end time.
The display field goes out when the heating time expires.
1301138F04_BA_VWU_1533.BOOK Page 18 Monday, October 1, 2012 11:23 AM
19
D
GB
Setting the time
This function is not available when heating or ventilation mode is active!
Press and hold the button . Press the button "Forward" or "Reverse"
as well.
Release the button.
The time of day is displayed and the clock symbol flashes.
Set the time via the button "Forward" or "Reverse" .
The set time is saved when the display goes out and by pressing the button.
Checking the time
Press the button "Forward" or "Reverse" .
The remaining time is displayed if heating or ventilation mode is active.
1301138F04_BA_VWU_1533.BOOK Page 19 Monday, October 1, 2012 11:23 AM
