Webasto SmarTemp Control fx Bedienungsanleitung

SmarTemp Control fx

(Timer Programming Functionality)

SmarTemp fx Overview

29.08.2018 Webasto Presentation 2

Instant heat button

Select button

Rotary knob

Status indicator light(s)

Heater on

Run time

Manual Operation

29.08.2018 3

Webasto Presentation

This is the main screen of the

SmarTemp Control fx. If it shows

“Manual” on the screen no timers

are set to run. The heater can be

started by pressing the “Webasto”

button

Press to start heater

Menu Operation

29.08.2018 4

Webasto Presentation

Menu feature:

Pressing the “Select” button

will get you into the menu

area of the SmarTemp fx. This

is where you can set the

different timer settings and the

run time duration just as an

example.

Select button

Rotate knob to move

through the menu

Mode Selection

29.08.2018 5

Webasto Presentation

Mode:

There are two different modes,

Manual andAuto.

Manual: the heater will only start

when the “Webasto” button is

pressed.

Auto: All set timers will run as

programmed throughout the

week.

Timer Programming

29.08.2018 6

Webasto Presentation

Timer Programming:

The SmarTemp fx allows you to have up

to 4 preset programs per day for the 7

days of the week.

Rotate knob until the “timer” feature is

highlighted and then press the select

button the screen shown on this slide will

appear.

selection

Once you are in the timer feature there will be a

selection square that appear. When you rotate

the knob it will scroll through the days of the week

first and then into the timer for each day. While

scrolling through the days you can press the

select button to get down to the timer for that day

that you want. T1 –T4

29.08.2018 7

Webasto Presentation

Setting a timer:

When you pick the day and timer number

that you want press the select button and

the time and duration screen will appear.

The time can be set for any timer during

that day.

The duration can be between 10 –120

minutes in 10 minute increments only.

Repeat these steps for all timers to be

set. T1-T4, Sunday thru Saturday

Time and duration screen

Timer Programming

29.08.2018 8

Webasto Presentation

Timer Programming

Turning a timer off:

Rotate the knob and use the select

button to pick the timer you want to turn

off.

Once you have the time and duration

screen open for the timer, by pressing the

select button, rotate the knob on the

duration until “OFF” is displayed for the

duration. Press the select button and the

check that was in that timer position will

go away.

Time and duration screen

29.08.2018 Webasto Presentation 9

Timer Skip Function

Skip feature:

To use the skip feature rotate the knob

until you get to the timer selection that

you want to skip. Once on that timer,

press the select button and an “S” will

appear in place of the check mark.

The skip feature will only skip the

selected time once.After that time has

passed the “S” will return to a check

mark.
