SUMMIT™475 & 675

Built-in Sleeve

97070 12/96

Serial Number

NOTICE TO INSTALLER: These instructions

must be left with the owner and the owner

should keep them for future use.

WARNING: Follow all leak check procedures

carefully in this manual prior to barbecue

operation. Do this even if barbecue was

dealer assembled.

WARNING: Do not try to light this appliance

without reading "Lighting" instructions section

of this manual.

THIS GAS APPLIANCE IS DESIGNED FOR

OUTDOOR USE ONLY.

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. Open lid.

4. If odor continues, immediately call your

gas supplier or your fire department.

FOR YOUR SAFETY: Do not store or use

gasoline or other flammable vapors and liquids

in the vicinity of this or any other appliance.

REMOVE PACKAGED

PARTS

Back panel

Rail (2)

Right panel

Left panel

Bottom panel

ASSEMBLE BACK PANEL

TO BOTTOM PANEL

ASSEMBLE LEFT PANEL

TO BOTTOM PANEL

8-7/8 screw (22)

Front door

Place the back panel perpendicular to the bottom panel.

Insert screws and tighten. Figure 1.

Place the left panel perpendicular to the bottom panel.

Insert screws and tighten. Figure 2.

Figure 1

Figure 2

Nylon washer (4)

Bushing (2)

Spacer (2)

ASSEMBLE RAILS TO

LEFT PANEL

ASSEMBLE RIGHT PANEL

TO BOTTOM PANEL

ASSEMBLE BACK PANEL

TO SIDE PANELS

Insert the rails into the left panel. Figure 3.

Place the right panel perpendicular to the bottom panel.

Guide the rails into the right panel. Insert screws and

tighten. Figure 4.

Insert screws along the side of the back panel. Tighten.

Figure 5.

View from back

Figure 3

Figure 4

Figure 5

ASSEMBLE DOOR TO

SIDE PANELS

Add two washers on each end of the wire. Insert the

bottom wire of the door into the bushing of the left panel.

Pull the wire up and in to insert it into the bushing in the

right panel. Figure 6.

Once the bottom wire is in place, push it down so it snaps

into the bottom flange to lock it in place. Figure 8. Close

the door. Turn the knob clockwise to close. Figure 9.

View from front

View from top

Close Open

Figure 6

Figure 8

Figure 9

ADD SPACERS AND

BUSHINGS

Push in the bushings into the bottom holes of the side

panels. Insert screw through the spacer and into the

second hole in the middle of the side panels at the cutout.

Tighten. Figure 6.

Spacers

Screws

Bushings

View from front

Washers

Figure 7

Spacer
