WhatsGPS S5L Bedienungsanleitung

User Manual

S5L

4G GPS Vehicle Tracker

Product Introduction

This user manual has been specially designed to

guide you through the functions and features of your

GPS vehicle tracker.

Start Guide

◆ Main device

◆ Power cord

◆ Relay line, 4-pin relay

◆ SOS cable

◆Fuel cable

◆ User manual

◆ Real-time GPS+AGPS tracking

◆ Track by time interval/distance/direction change

◆ Track through SMS, APP, Web

◆ Remotely fuel/power cut-off control

◆ SOS alarm

◆ Geo-fence alarm

1.1 Accessories

1.2 Main Functions

◆ Vibration alarm

◆ Movement alarm

◆ External power supply cut-off alarm

◆ Over-the Air (OTA)

◆ Low battery alert

Frequency : FDD B1/B2/B3/B4/B5/B7/B8/B28

TDD B40

WCDMA 850/900/1900/2100MHz

GSM 850/900/1800/1900MHz

Networks WCDMA /EDGE/GPRS

Location Time

Operating Voltage 9-36VDC<300mA

Cold Start: ＜35s

Hot Start：＜2s

Location Accuracy :<10 meters

Operating Temperature :-20℃ ~ +70℃

Weight :80g

Dimension: 83(L) x 46(W) x 14.5(H) mm

1.3 Specifications

My device

2.1Cable connection

2.2 LED indicators

1 2 3

1、Purple

2、Blue

3、Green

4、yellow

5、Red

6、Black

6 4 54 5 6 4

Oil Pump

Fuel oil sensor

Earth Wire

Temperature sensor

Relay

Battery

Ignition

321

After-sales service

Light type

Off

Normal flashing (1 time / S)

Slow flashing (1 time / 2S)

Light status

No power / device failure

Slow flashing

The server is connected

Networking

once / 200ms data

sending

Red light (power indicator)

4、Interface definition

2.3 Device Installation

Note: When device is connected with external power,

please turn on the battery switch. The battery will then

connect with the device circuits and its built-in battery

will be charged. If battery is OFF, battery can't be

charged. The device will be power off if no external

power supply.

Power on/ Power off

Power on:Once you insert a valid SIM card and

connect all the wires, turn on the device. Power LED

will flash first. During signal searching process stable

Power off: Just turn off the power switch.

Operation of device

4.4 Vibration alarm(default OFF)

4.1 SOS

4.2 Power cut-off alarm

4.3 Low battery alarm

Main Functions

In emergent case, press SOS for 3 seconds to

activate SOS alarm.

Then the device will send SOS SMS to preset SOS

numbers and

then dial the numbers in a loop for 3 times until the

call is picked up.

Alarm message will also send to platform. (See

command list 7-8)

When the electricity supply of device is cut off, it will

activate cut-off alarm.

When battery is low, the device will activate low

battery alarm.

When vehicle vibrates several times, the vibration

alarm will be triggered. If no ignition after 3 minutes

(ACC OFF), the device will send vibration alarm

message immediately. .

4.5 Oil/Electricity cut-off

Notice

When vehicle is stolen, oil/electricity cut-off

command can be sent by platform, APP or SMS.

1.Make sure ACC is correctly connected.

2.When ACC is OFF, command will be executed

immediately.

3.When ACC is ON, but GPS is not fixed, command

will be postponed.

4.When ACC is ON, GPS is fixed, command will be

executed when

vehicle speed is less than 20km/h.

If you want to cut off/restore oil by SMS command,

you have to set a

center number firstly. Only the center number can

send the cut

off/restore oil command to the device.

Notice

1.Only the SOS number can be used to set center

number.

2.Only the SOS number can be used to delete

center number.

3.There is only one center number can be set.

Platform Operation

5.1 APN & Server setting

4.6 Restore oil/electricity

When alarm is all-clear, you can send restore

oil/electricity command by platform, APP or SMS and

restore vehicle power. (See command list 7-15)

4.7 Restart device

If GPRS is abnormal (device is offline), you can send

SMS command RESET# to restart the device. Device

will reboot after 20 seconds after receiving the

command.

To ensure normal network operation, please confirm

your APN and server setting before login.

In most countries, APN could be automatically

adapted to local

mobile operators. If not, please send SMS to set the

APN.

If username and password is required for APN,

please add it into the command.

Confirm the server address and setting with

distributors. If server is incorrect, please send SMS to

change.

5.2Download APP

Common Command List

SERVER,mode,domainName/IP,port,0＃

E.g. SERVER,1,a.whatsgps.com,6801,0#

SERVER,0,47.75.111.37,6801,0#

mode = 1 means set with domain name

mode = 0 means set with ip address

Please download and install the APP in designated

website, APP

store or Google Play store,www.whatsgps.com .

Edit SMS command in the right column to the device

SIM number to achieve respective function as below:

Set IP1

SERVER ,1,IP/domain,

port#

Upload interval

time setting

SOS phone

number setting

TIMER,10#

SOS,A,number1,number2,

number3#

APN,cmnet#

APN,g.claro.com.br,.claro.

claro#

Set APN

After-sales service

Trouble shooting

If you are having trouble with your device, try these

troubleshooting

procedures before contacting a service professional.

Delete SOS

phone number

Center phone

number setting

SOS,D,number1,number2,

number3#

Set the petrol/

electricity

Reboot

RELAY,T#

RESET#

CENTER,A,phone number#

After-sales service

Causes

problem

Poor signal

Unable to

boot

The signal waves

unable to transmit

when use the GPS

tracker in the places

that have poor signal

reception, such as:

tall building around

or basement.

Using the GPS

tracker in the

places that

have good

signal

condition.

Solutions

Low battery Charge the

device battery
